Milwaukee M28 C: 8 9ENGLISH ENGLISH

TECHNICAL DATA

If it is not used for long periods, the rechargeable battery will

EC-DECLARATION OF CONFORMITY

switch to the non-operative state and needs to be

Voltage range .................................................................28 V

We declare under our sole responsibility that this product is

reactivated before reuse.

Quick charge current .....................................................3.5 A

in conformity with the following standards or standardized

Battery charging time ..........................................approx. 1 h

The state of charge can be read by pressing the button on

documents.

Weight according EPTA-Procedure 01/2003 ................700 g

the rechargeable battery. The battery can be left in the

EN55014-1:2006 + A1:2009 + A2:2011

electric tool while the reading is taken but it must be

EN55014-2:1997 + A1:2001 + A2:2008

WARNING! Read all safety warnings and all

switched off at least one minute beforehand (otherwise the

EN61000-3-2:2006 + A1:2009 + A2:2009

instructions, including those given in the accompanying

display will be inaccurate). The number of LEDs illuminated

EN61000-3-3:2008

brochure. Failure to follow the warnings and instructions

indicates the state of charge.

EN60335-1:2002 + A1:2004 + A11:2004 + A12:2006 +

may result in electric shock, re and/or serious injury.

A2:2006 + A13:2008 + A14:2010 + A15:2011

As a general principle, if the electric tool should fail to work

Save all warnings and instructions for future reference.

EN60335-2-29:2004 + A2:2010

after inserting the rechargeable battery, then the battery

EN62233:2008

should be plugged into the charger. The displays on the

SAFETY INSTRUCTIONS

in accordance with the regulations

battery and charger will then provide information about the

2011/65/EU (RoHs)

Do not dispose of used battery packs in the household

condition of the battery.

2006/95/EC

refuse or by burning them. Milwaukee Distributors offer to

In low temperatures work may continue at reduced output.

2004/108/EC

retrieve old batteries to protect our environment.

For an optimum life-time, after use, the battery packs have

Only the following battery packs can be charged with this

to be fully charged.

charger:

For battery pack storage longer than 30 days:

voltage battery rating No. of

Store the battery pack where the temperature is below 27°C

Winnenden, 2012-10-19

Rainer Kumpf

(of storage battery) battery

and away from moisture

Director Product Development

cells

Store the battery packs in a 30% - 50% charged condition

MAINTENANCE

28 V M 28 BX 3.0 Ah 2 x 7

Every six months of storage, charge the pack as normal.

If the supply cord of this appliance is damaged, it must only

Do not try to charge non-rechargeable batteries with this

To obtain the longest possible battery life remove the battery

be replaced by a repair shop appointed by the manufacturer,

charger.

pack from the charger once it is fully charged.

because special purpose tools are required

Do not store the battery pack together with metal objects

CHARACTERISTICS

Use only Milwaukee accessories and Milwaukee spare

(short circuit risk).

parts. Should components need to be replaced which have

After inserting the battery into the reception of the charger

No metal parts must be allowed to enter the battery section

not been described, please contact one of our Milwaukee

the battery will automatically be charged (red control lamp is

of the charger (short circuit risk).

service agents (see our list of guarantee/service addresses).

illuminated continuously)

Never break open battery packs or chargers and store only

If needed, an exploded view of the tool can be ordered.

When a hot or cold battery pack is inserted into the charger

in dry rooms. Keep dry at all times.

Please state the Article No. as well as the machine type

(ashing red lamp), charging will begin automatically once

printed on the label and order the drawing at your local

The battery clamps of the charger are fed by the mains

the battery reaches the correct charging temperature

service agents or directly at: Milwaukee Electric Tool,

supply. Do not touch the tool with conducting objects.

(0°C...65°C). The max. charging current is owing when the

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

Never charge a damaged battery pack. Replace by a new

temperature of the Li-Ion-battery is between 0°C and 65°C.

one.

The battery’s charging time is between 1 min and 60 min (at

SYMBOLS

Before use check machine, cable, and plug for any

3,0 Ah), depending on the state of discharge.

damages or material fatigue. Repairs should only be carried

Once the battery is fully charged, the LED on the charger

Please read the instructions carefully before

out by authorised Service Agents.

changes from red to green.

starting.

This appliance is not intended for use by persons (including

It is not necessary to remove the battery after charging. The

children) with limited physical, sensory or mental capabilities

battery can be stored permanently in the charger without the

or insufcient experience and/or knowledge unless they are

danger of being overcharged.

supervised by a person who is responsible for their safety or

Do not burn used battery packs.

If both LEDs ash alternately then the rechargeable battery

have been instructed by them in the safe use of the tool.

is either not fully pushed in or there is a fault with the battery

Children should be supervised in order to ensure that they

or charger. Take the charger and battery out of use

do not play with the tool.

immediately for safety reasons and have them inspected by

a Milwaukee customer service centre.

SPECIFIED CONDITIONS OF USE

Do not dispose of electric tools together with

All LED will ash 4x if the machine is overloaded. To

The quick charger can charge Milwaukee M28 Li-Ion

household waste material! In observance of

continue working, switch the machine off and then on again.

batteries System M28 and V28 Li-Ion batteries System V28.

European Directive 2002/96/EC on waste

electrical and electronic equipment and its

Do not use this product in any other way as stated for

implementation in accordance with national law,

normal use.

electric tools that have reached the end of their

life must be collected separately and returned to

MAINS CONNECTION

an environmentally compatible recycling facility.

Connect only to single-phase a.c. current and only to the

system voltage indicated on the rating plate. It is also

possible to connect to sockets without an earthing contact

Never charge a damaged battery pack.

as the design conforms to safety class II.

Replace with a new one.

Li-Ion BATTERIES

This tool is only suitable for indoor use. Never

The rechargeable batteries are partially charged and

expose tool to rain.

supplied in a non-operative state. Prior to initial use it is

necessary to activate the battery by plugging it into the

charger briey. The LED on the battery indicates the state of

charge.

8 9ENGLISH ENGLISH
