Bowers & Wilkins ASW 2500: Ω

II08494 Issue 1

™

ASW

2500

Description

Active closed-box subwoofer

Drive units

One 250mm (10 in) dia long throw

System frequency range

-6dB 20Hz - 50/150Hz adjustable (EQ at ‘B’)

System frequency response

±3dB 23Hz - 40/120Hz adjustable (EQ at ‘B’)

Amplifier

Power output 700W continuous (1kW short term)

Input impedance 15k

Ω

Sensitivity 88dB spl at 1m for 100mV input

(Volume control set to centre position)

Signal/Noise 90dB

Functions Input level

Phase 0/180

Low-pass filter bypass

Low-pass filter frequency

Bass roll-off alignment

Auto-sense on/standby

Inputs Line In (RCA Phono)

Outputs Line Out (RCA Phono, h-p filtered)

Link Out (RCA Phono)

Low-Pass Filter Active 2nd-order, variable cut-off 50Hz - 150Hz

High-Pass Filter Active 2nd-order at 80Hz

Internal Volume

15 litres (0.5 cu ft)

Dimensions

Height: 315mm (12.4 in) not including feet

Width: 315mm (12.4 in)

Depth: 402mm (15.8 in) including controls

Net Weight

23.4kg (51.5 lb)

THX is a registered trademark of Lucasfilm Ltd.

B&W Loudspeakers Ltd. reserves the right to amend details of the specification without notice in line with technical developments.
