SF-2200

SF-2500

GB p. 1

DE p. 5

FR p. 9

NL p. 13

IT p. 17

ES p. 21

PT p. 25

SV p. 29

DA p. 33

NO p. 37

FI p. 41

HR p. 45

PL p. 49

RO p. 53

CZ p. 57

HU p. 61

GR p. 65

RU p. 69

1

SF-2200, SF-2500

SF 2500: Water must be sprayed between the pipe and the head using

the spray bottle to give better contact (Fig 3.1) and will speed the freezing

GB

process.

• Allow sufcient time for the ice plug to form (see table for approximate

freezing times) indicated by a sharp cracking sound from the pipe.

SF-2200, SF-2500

• Test the pipe for pressure by opening a valve or tting downstream by

installing a line tap. The pipe can now be serviced.

• The Super Freeze should be kept running during the service period.

Operating Instructions

• When the work is completed, switch off unit and remove line cord from

socket.

WARNING! Read these instructions and

Do not force the heads from the pipe to avoid damaging them.

• Let hoses defrost before storing in case.

the accompanying safety booklet carefully

• Wipe any moisture from the heads and the hoses before storing in the

before using this equipment. If you are un-

case.

certain about any aspect of using this tool, contact

your RIDGID distributor for more information.

To obtain the best freezing times:

• Check for good contact between head and pipe.

• Add Cool gel between adapter and pipe — head and adapter.

Failure to understand and follow all instructions

• Check if hose orientation is perpendicular towards pipe and the freeze

may result in electric shock, re, and/or serious

head is in one line with the hoses. (Fig 4.1 and Fig. 4.2) This is vital for

personal injury.

obtaining optimal freeze times.

• Connect freezing head to the top of a horizontal pipe section

SAVE THESE INSTRUCTIONS!

• Wrap insulation around head and pipe.

Note: Approximate freezing times shown in tables give an approximate guide

Specications:

for system temperatures between 15°C and 25°C.

The Super Freeze is designed for use as a pipe-freezing tool. We strongly

Faster freeze times will be obtained with Copper tubes.

recommend that it NOT be modied and/or used for any other application.

Any paint or dirt on the tube will increase the freeze time.

Physical characteristics, capacity and standard equipment: see g 1.1

(SF 2500) and 1.2 (SF 2200).

Troubleshooting:

• If heads do not become frosted:

Transport and handling:

Check power, check free air ow for fan and clean if required. Switch off

Avoid shocks or violent movements. Secure the unit rmly during transport.

power and wait 3-5 minutes before restarting.

Inspect the unit for signs of damage and fully uncoil hoses before connecting

• If heads get cold but will not freeze:

line cord to power supply.

Check for water ow in pipe.

• If unit stops: Wait 30 seconds before restarting.

Safety:

Note: The compressor is thermally protected and will reset automatically after

Caution: The freezing heads become very cold. Wear gloves to avoid risk of

an overload. If unit still does not function correctly and for all other maintenance

frostbite.

contact your RIDGID distributor.

Ground machine. Always plug the cord into a properly grounded socket.

Set up, positioning and operation:

• Stop water ow otherwise unit will not freeze ice plug.

• If possible allow the system to cool before freezing.

Warm water will cause circulation increasing the freeze time.

• Clean pipe and remove paint and insulating material.

• Connect freezing heads at same point for single ice plug or a suitable

distance for two separate plugs (Fig 2.1 and 2.2) using the cavity that

best ts the outside diameter of pipe.

Do not twist or kink hoses

• Switch on unit after ensuring there is unrestricted air circulation for the

fan.

After 2-3 minutes the heads will be at operating temperature.

SF 2200: Cool gel (cat.nr. 74946) must be applied:

1. Between the cylinder freezing head and the adapter.

2. Between the pipe and the adapter.

Cool gel will help speed up the process. (Fig. 3.2) Allows better contact for

faster freezing process.

2

SF-2200, SF-2500

Fig. 1.1 SF-2500 Fig. 1.2 SF-2200

Fig. 2.1 Fig. 2.2

Fig. 3.1 Spray bottle Fig. 3.2 Cool gel

Fig. 4.1 Fig. 4.2

3

SF-2200, SF-2500

Approximate freezing times SF-2200

Approximate freezing times SF-2500

-

T amb = 32 °C

-

T amb = 26 °C

-

T amb = 21 °C

4

SF-2200, SF-2500

SF-2200

SF-2500

23 kg.

31 kg

230V ~ 50.Hz 2.0 A 387W.

230V ~ 50 Hz - 2.4A - 505W

Pe1 = 20 bar

Pe1= 21 bar

Pe2 = 35 bar

Pe2= 34 bar

R 507 0,380kg.

R 507 0,487kg

ø max: Fe 2”. Cu 65 mm

ø max: Fe 2”. Cu 65 mm
