Fein RS 12-70E: Handling.

10

RS 12-70 E

EN

Do not rivet or screw any name-plates or

signs onto the power tool. The protective

insulation can thereby be rendered inef-

fective. Adhesive labels are recom-

mended.

Only use an undamaged plug and cable.

Damage to property/material

Mains voltage must correspond with the

voltage specifications on the power tool.

Personal protective equipment.

When treating coatings that contain lead,

or some types of wood or metal, injuri-

ous/poisonous dust is produced. Touch-

ing or breathing in this dust could prove

dangerous for the operator or anyone

who happens to be in the vicinity.

Permanent exposure to intensive sound

can lead to deafness.

Use your personal protective equipment.

For protection against dust, use a dust

mask or a respirator that must be capable

of filtering the particles produced during

operation. Irrespective of the application,

wear a protective face mask or glasses,

protective gloves and a hairnet (for long

hair).

Ear protection is recommended when

operating belt sanding machines.

Handling.

Switching ON/OFF (2).

■

First check that the cable and plug are

not damaged.

Switching the power tool ON:

■

Slide switch (2) forwards (I).

Switching the power tool OFF:

■

Press the switch (2) down at the

back (0).

When switching on, the motor starts run-

ning gently after a short delay.

If the power supply is interrupted while

the power tool is switched on, or the

power tool is plugged in when it is in

switched-on mode, a residual current

protective device prevents it from starting

to run automatically. To put the power

tool into operation, briefly switch it off

and on again.

Setting the speed (1).

Using the speed controller (1), the opti-

mum speed for the sanding belt can be set

according to the work piece and the

accessories used.

Operating instructions (5).

The power tool with the sanding belt

should be brought towards the pipe (a) to

be sanded at a right-angle, until at least half

of the pipe is surrounded by the sanding

belt.

Sand the pipe evenly, constantly using a

lengthways movement.

Always hold the power tool at right-

angles to the pipe, even where the pipe is

curved.

Always hold the power tool in both

hands.

Securing or changing the  sanding belt (5).

Risk of injury

by switching the tool ON unintentionally.

Before changing the belt, pull out the mains

plug.

Position the sanding belt on the driving

roller and the idler on the fixed extension

arm. Press the swiveling extension

arm (b) inwards and position the sanding

belt on its idler.

!

!
