Fein RS 12-70E: Cleaning and care.

RS 12-70 E

11

EN

Carry out a test run for approx. 20 sec-

onds when using a new sanding belt. Push

the swiveling extension arm (b) firmly

outwards to tension the sanding belt

ready for use.

Cleaning and care.

Risk of injury

by switching the tool ON unintentionally.

Before cleaning, pull out the mains plug.

Carry out the following once a week, or

more often if the power tool is used more

frequently:

■

Clean and lubricate the joint and the

surface of the tension spring on the

swiveling extension arm.

■

Clean the venting openings.

■

Blow out the motor space from outside

with dry compressed air.

Maintenance and repairs.

Risk of injury

Service, testing and repairs may only be car-

ried out by electrical engineers in conformity

with the regulations valid in the respective

country.

Maintenance and repairs.

We recommend our customer service

department (repair centre), FEIN author-

ised service centres and agencies.

Addresses can be found at the end of

these operating instructions and in the

enclosed safety instructions.

Please hand these operating instructions

to the repair centre. An overview of spare

parts can be found at the end of these

operating instructions.

Only use original FEIN spare parts.

Spare parts.

The overview of spare parts is at the end

of these operating instructions. Quoting

the parts no. (1), reference no. (2) as well

as the number of spare parts (3) facilitates

the ordering procedure.

Accessories.

Illustrations and reference numbers can be

found at the end of these instructions.

Description of the accessories:

A Sanding belt, pack of 10.

B Fleece belt, pack of 5.

C Pre-polishing cream, 200 ml.

D Final polishing cream, 200 ml.

E Polishing belt, pack of 3.

F Idlers of Ø 35 mm, for working in

places difficult to access.

G Basic set, each consisting of 10 sanding

belts 20 x 815 mm, grain 120,

20 x 815 mm, grain 180,

40 x 815 mm, grain 120,

40 x 815 mm, grain 180 and 5 fleece

belts 20 x 815 mm, grain 280.

H Polishing set, each consisting of

10 sanding belts 20 x 815 mm,

grain 320 and 20 x 815 mm,

grain 400, and each with 1 tube of

pre-polishing cream and final polishing

cream and 3 polishing belts

20 x 815 mm.

I

Metal carry case

(690 x 240 x 160 mm).

When using application tools other than

those listed here, the user must check

whether additional protective measures

have to be taken.

!

!
