Milwaukee C12 RAD: 14 15 ENGLISH ENGLISH

TECHNICAL DATA Cordless Drill Driver

C 12 RAD

EC-DECLARATION OF CONFORMITY

SYMBOLS

Drilling capacity in wood ..........................................................

...........................25 mm

We declare under our sole responsibility that this product is

Wood screws (without pre-drilling) ..........................................

..........................6,5 mm

in conformity with the following standards or standardized

Please read the instructions carefully before

-1

No-load speed ........................................................................

......................0-800 min

documents.

starting the machine.

Torque max (Li-Ion Battery 1.5 Ah) *1 .....................................

...........................12 Nm

EN 60745-1:2009 + A11:2010

Torque max (Li-Ion Battery 3.0 Ah) *1 .....................................

...........................15 Nm

EN 60745-2-1:2010

Battery voltage.........................................................................

...........................12 V

EN 60745-2-2:2010

Drill chuck range ......................................................................

.....................1,0-10 mm

EN 55014-1:2006 + A1:2009 + A2:2011

Remove the battery pack before starting any

Weight according EPTA-Procedure 01/2003

EN 55014-2:1997 + A1:2001 + A2:2008

work on the machine.

with battery 1.5 Ah ................................................................

..........................1,1 kg

in accordance with the regulations

with battery 3.0 Ah ................................................................

..........................1,3 kg

2011/65/EU (RoHs)

2006/42/EC

2004/108/EC

Noise/vibration information

Do not dispose of electric tools together with

Measured values determined according to EN 60 745.

household waste material! In observance of

Typically, the A-weighted noise levels of the tool are:

European Directive 2002/96/EC on waste

Sound pressure level (K = 3 dB(A)) .......................................

........................64,5 dB (A)

electrical and electronic equipment and its

Sound power level ................................................................

........................75,5 dB (A)

implementation in accordance with national law,

Winnenden, 2012-09-11

Wear ear protectors!

electric tools that have reached the end of their

life must be collected separately and returned to

Total vibration values (vector sum in the three axes)

an environmentally compatible recycling facility.

determined according to EN 60745.

Vibration emission value a

h

Rainer Kumpf

2

Drilling into metal ..................................................................

.......................< 2,5 m/s

Director Product Development

2

Uncertainty K= ......................................................................

..........................1,5 m/s

2

Authorized to compile the technical le

Screwing ...............................................................................

.......................< 2,5 m/s

2

Uncertainty K= ......................................................................

..........................1,5 m/s

BATTERIES

New battery packs reach full loading capacity after 4 - 5

chargings and dischargings. Battery packs which have not

WARNING

been used for some time should be recharged before use.

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

Temperatures in excess of 50°C (122°F) reduce the

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.

performance of the battery pack. Avoid extended exposure

to heat or sunshine (risk of overheating).

The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained, the vibration emission may differ. This may signicantly increase

The contacts of chargers and battery packs must be kept

the exposure level over the total working period.

clean.

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

For an optimum life-time, after use, the battery packs have

when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.

to be fully charged.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

To obtain the longest possible battery life remove the battery

accessories, keep the hands warm, organisation of work patterns.

pack from the charger once it is fully charged.

For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C

and away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

Do not store the battery pack together with metal objects

BATTERY PACK PROTECTION

WARNING! Read all safety warnings and all

(short circuit risk).

instructions, including those given in the accompanying

In extremely high torque, binding, stalling and short circuit

brochure. Failure to follow the warnings and instructions

Use only System C12 chargers for charging System C12

situations that cause high current draw, the tool will vibrate

may result in electric shock, re and/or serious injury.

battery packs. Do not use battery packs from other systems.

for about 5 seconds, the fuel gauge will ash,and then the

Save all warnings and instructions for future reference.

Battery acid may leak from damaged batteries under

tool will turn OFF. To reset, release the trigger.

extreme load or extreme temperatures. In case of contact

Under extreme circumstances, the internal temperature of

SAFETY INSTRUCTIONS

with battery acid wash it off immediately with soap and

the battery pack could raise too much. If this happens, the

water. In case of eye contact rinse thoroughly for at least 10

Wear ear protectors. Exposure to noise can cause hearing

fuel gauge will ash until the battery pack cooled down. After

minutes and immediately seek medical attention.

loss.

the lights go off, the work may continue.

Hold power tool by insulated gripping surfaces, when

SPECIFIED CONDITIONS OF USE

MAINTENANCE

performing an operation where the fastener may

contact hidden wiring. Fasteners contacting a "live" wire

The battery drill/screwdriver may be used for drilling and

The ventilation slots of the machine must be kept clear at all

may make exposed metal parts of the power tool "live" and

screwdriving for independent use away from mains supply.

times.

could give the operator an electric shock.

Do not use this product in any other way as stated for

Do not let any metal parts reach the airing slots - danger of

Hold power tool by insulated gripping surfaces, when

normal use.

short circuit!

performing an operation where the cutting accessory

Use only Milwaukee accessories and spare parts. Should

may contact hidden wiring. Cutting accessory contacting

components need to be replaced which have not been

a "live" wire may make exposed metal parts of the power

described, please contact one of our Milwaukee service

tool "live" and could give the operator an electric shock.

agents (see our list of guarantee/service addresses).

Sawdust and splinters must not be removed while the

If needed, an exploded view of the tool can be ordered.

machine is running.

Please state the Article No. as well as the machine type

When working in walls ceiling, or oor, take care to avoid

printed on the label and order the drawing at your local

electric cables and gas or waterpipes.

service agents or directly at: Milwaukee Electric Tool,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

Remove the battery pack before starting any work on the

machine.

Do not dispose of used battery packs in the household

refuse or by burning them. Milwaukee Distributors offer to

retrieve old batteries to protect our environment.
