Indesit VRA 640 X: Start-up and use

9

GB

Start-up and use

!

 The glue applied on the gaskets leaves traces of

grease on the glass. Before using the appliance, we

recommend you remove these with a special non-

abrasive cleaning product. During the first few hours

of use there may be a smell of rubber which will

disappear very quickly.

!

 A few seconds after the hob is connected to the

electricity supply, a buzzer will sound. The hob may

now be switched on.

!

 If the

-

 or

+

 button is pressed for an extended

period of time, the display scrolls quickly though the

power levels and timer minutes.

Switching on the hob

To switch the hob on, press and hold the

 button

for approximately one second.

Switching on the cooking zones

Each cooking zone is controlled using a selector button

 and a power adjustment device consisting of a

double

-

 and

+

 button.

•  To begin operating a cooking zone, press the

corresponding control button and set the desired

power level (between 0 and 9) using the buttons

-

and

+

.

Power function

The power function for the cooking zones may be used

to shorten heating-up times. Activate and set the power

level for the desired cooking zone

 as described

in the previous paragraph. Press and hold the selector

button corresponding to the desired cooking zone

for at least 2 seconds. The display, the power level

indicator, will alternately show the letter “P” and the

power level set previously until the desired power level

has been reached. Once this level has been reached,

the display will revert to showing the set power level.

To deactivate this function, press and hold – for at

least 2 seconds - the selector button corresponding to

the cooking zone on which the

 function has been

activated; alternatively, select a different power level

using the buttons

-

 and

+

.

Switching off the cooking zones

To switch off a cooking zone, select it using the

corresponding selector button

 and:

• Press the

-

 button: the power of the cooking zone

will progressively decrease until it is switched off.

Heating elements

Two types of heating element may be installed,

depending on the appliance model: halogen and

radiant elements.

Halogen elements emit heat via radiation from the

halogen lamps they contain.

They have similar properties to gas burners: they are

easy to control and reach set temperatures quickly,

allowing you to see the power level instantly.

Radiant elements consist of a series of coils which

allow heat to be distributed evenly at the base of

the cookware, so that all slow-flame cooking may be

performed successfully, for example stews, sauces or

reheated dishes.

Control panel lock

When the hob is switched on, it is possible to lock the

oven controls in order to avoid accidental changes

being made to the settings (by children, during

cleaning, etc.). Press the

 button to lock the control

panel: the indicator light above the button will switch

on.

To use any of the controls (e.g. to stop cooking), you

must switch off this function. Press the

 button for a

few moments, the indicator light will switch off and the

lock function will be removed.

Switching off the hob

Press the

 button to switch the appliance off.

If the control panel lock has been activated, the

controls will continue to be locked even after the hob is

switched on again. In order to switch the hob on again,

you must first remove the lock function.

10

GB

Practical advice on using the appliance

To obtain the best results from your hob:

•  Use pans with a thick, flat base in order to fully

utilise the cooking zone.

•  Always use pans with a diameter which is large

enough to cover the hotplate fully, in order to use all

the available heat.

•  Make sure that the base of the cookware is always

clean and dry, in order to fully utilise and extend the

life of both the cooking zones and the cookware.

•  Avoid using the same cookware which has been

used on gas burners: the heat concentration on gas

burners may distort the base of the pan, causing it

not to adhere correctly.

Safety devices

Pan sensor

Each cooking zone is equipped with a pan sensor

device. The hotplate only emits heat when a pan with

suitable measurements for the cooking zone is placed

on it. If the indicator light is flashing, it may indicate:

•  An incompatible pan

•  A pan whose diameter is too small

•  The pan has been removed from the hotplate.

Residual heat indicators

Each cooking zone is equipped with a residual heat

indicator. This indicator signals which cooking zones

are still at a high temperature. If the power display

shows

, the cooking zone is still hot. It is possible,

for example, to keep a dish warm or melt butter or

chocolate. As the cooking zone cools, the power

display will show

. The display switches off when the

cooking zone has cooled sufficiently.

Overheating protection

If the electronic elements overheat, the hob switches

off automatically and

F

 appears on the display,

followed by a flashing number. When the temperature

has reached a suitable level, this message disappears

and the hob may be used again.

Safety switch

The appliance has a safety switch which automatically

switches the cooking zones off after they have been

in operation for a certain amount of time at a particular

power level. When the safety switch has been

triggered, the display shows “0”.

For example: the right rear hotplate is set to 5 and will

switch off after 5 hours of continuous operation, while

the front left hotplate is set to 2 and will switch off after

8 hours.

Buzzer

This can also indicate several irregularities:

•  An object (a pan, cutlery, etc.) has been placed on

the control panel for more than 10 seconds.

•  Something has been spilt on the control panel.

•  A button has been pressed for too long. All of the

above situations may cause the buzzer to sound.

Remove the cause of the malfunction to stop the

buzzer. If the cause of the problem is not removed,

the buzzer will keep sounding and the hob will

switch off.

Power level

1

2

3

4

5

6

7

8

9

Maximum operating time in hours

9

8

7

6

5

4

3

2

1

11

GB

Practical cooking advice

ª

Pressure cooking

Pressure cooker

Frying

Grilling

Boiling

Very high-flame

cooking

High-flame

cooking

Medium-flame cooking

Low-flame

cooking

Very

low-flame

cooking

• • ¶

Crêpes

Cooking on a high flame and browning

(roasts, steaks, escalopes, fish fillets,

fried eggs)

¶ §

Fast thickening (liquid juices)

Boiling water (pasta, rice, vegetables)

Milk

§ S

Slow thickening (dense juices)

S ¢

Bain-marie cooking

Pressure cooking after whistle

¢ £ ™

Low-flame cooking (stews)

Reheating dishes

™ ¡

Chocolate sauce

Keeping food hot
