COLLEGAMENTO ELETTRICO

ELECTRICAL CONNECTION

Green and Yellow

to Earth

Blue to

Neutral

13 amp

Fuse

Brown

to Live

Cord

Clamp

Controllare che la tensione dell’impianto elettrico corrisponda a quella indicata sulla

targhetta caratteristiche posta sul lato sinistro in basso nella parte interna dello scom-

parto congelatore.

Se la presa a muro è priva di contatto a terra, o se la spina non è adatta al vostro

impianto vi consigliamo di rivolgervi ad un elettricista specializzato.

Non impiegare adattatori o derivatori che potrebbero causare riscaldamenti e brucia-

ture.

Check that the main voltage corresponds to that indicated on the rating plate in the

lower left side inside the freezer compartment.

If the wall socket does not have an earth terminal, or if the plug does not fit into the

socket, it is advisable to consult a qualified electrician. Do not use multiple plugs or

adapters as they could cause heating and burning.

WARNING: THIS APPLIANCE MUST BE EARTHED

If this appliance is fitted with a non rewirable plug for which your socket is unsuitable, the plug

should be cut off and an appropriate plug fitted. The removed plug must be disposed of

Insertion of the plug into a 13 Amp socket is likely to cause an electrical hazard When a

nonrewirable plug ora rewirable 13 Amp (BS1363) plug is used it must be fitted with a 13

Amp ASTA approved (BS1362) fuse. If any other type of plug is used it must be protected by

a 15 Amp fuse either in the plug or at the distribution board

IMPORTANT:

THE WIRES IN THE MAIN LEADS ARE COLOURED IN ACCORDANCE WITH

THE FOLLOWING CODE:

GREEN AND YELLOW - EARTH BLUE - NEUTRAL

BROWN - LIVE

As the colours of the wires in the main lead of your appliance may not correspond with

the coloured marking identifying the terminals in your plug, proceed as follows.

CONNECT GREEN & YELLOW coloured wire to plug terminal marked letter “E” or

earth symbol      or coloured green or green & yellow.

CONNECT BLUE coloured wire to plug terminal marked letter “N” or coloured black.

CONNECT BROWN coloured wire to plug terminal marked letter “L“ or coloured red.

ãO

ãO

ãO

ãO

ãO‰

‰

‰

‰

‰Kã

Kã

Kã

Kã

Kã

˛ ˛ ˛ ˛ ˛
