Appendix 2

ENGLISH

• Binary Output Object Type

Property Identifier Property Datatype BACnet BNU-BAC

Object_Identifier BACneObjectIdentifier R R

Object_Name CharacterString R R

Object_Type BACnetObjectType R R

Present_Value BACnetBinaryPV W W

Description CharacterString O R

Device_Type CharacterString O -

Status_Flags BACnetStatusFlags R R

Event_State BACnetEventState R R

Reliability BACnetReliability O -

Out_Of_Service Boolean R R

Polarity BACnetPolarity R R

Inactive_Text CharacterString O1 -

Active_Text CharacterString O1 -

Change_Of_State_Time BACnetDateTime O2 -

Chgange_Of_State_Count Unsigned O2 -

Time_Of_State_Count_Reset

BACnetDateTime O2 -

Elapsed_Active_Time Unsigned32 O3 -

Time_Of_Active_Time_Reset

BACnetDateTime O3 -

Minimum_Off_Time Unsigned32 O -

Minimum_On_Time Unsigned32 O -

Priority_Array BACnetPriorityArray R R

Relinquish_Default BACnetBinaryPV R R

Time_Delay Unsigned O4 -

Notification_Class Unsigned O4 -

Feedback_Value BACnetBinaryPV O4 -

Event_Enable BACnetEventTransitionBits O4 -

Acked_Transitions BACnetEventTransitionBits O4 -

Notify_Type BACnetNotifyType O4 -

Event_Time_Stamps

BACnetARRAY[3] of BACnetTimeStamp

O4 -

Profile_Name CharacterString O -

Installation/Owner Manual 101

Appendix 2

• Binary Value Object Type

Property Identifier Property Datatype BACnet BNU-BAC

Object_Identifier BACneObjectIdentifier R R

Object_Name CharacterString R R

Object_Type BACnetObjectType R R

Present_Value BACnetBinaryPV R1 W

Description CharacterString O R

Status_Flags BACnetStatusFlags R R

Event_State BACnetEventState R R

Reliability BACnetReliability R -

Out_Of_Service Boolean R R

Inactive_Text CharacterString O2 -

Active_Text CharacterString O2 -

Change_Of_State_Time BACnetDateTime O3 -

Chgange_Of_State_Count Unsigned O3 -

Time_Of_State_Count_Reset

BACnetDateTime O3 -

Elapsed_Active_Time Unsigned32 O4 -

Time_Of_Active_Time_Reset

BACnetDateTime O4 -

Minimum_Off_Time Unsigned32 O -

Minimum_On_Time Unsigned32 O -

Priority_Array BACnetPriorityArray O5 -

Relinquish_Default BACnetBinaryPV O5 -

Time_Delay Unsigned O6 -

Notification_Class Unsigned O6 -

Alarm_Value BACnetBinaryPV O6 -

Event_Enable BACnetEventTransitionBits O6 -

Acked_Transitions BACnetEventTransitionBits O6 -

Notify_Type BACnetNotifyType O6 -

Event_Time_Stamps BACnetARRAY[3] of BACnetTimeStamp O6 -

Profile_Name CharacterString O -

102 BACnet Gateway

Appendix 2

ENGLISH

• Device Object Type (1)

Property Identifier Property Datatype BACnet BNU-BAC

Object_Identifier BACneObjectIdentifier R R

Object_Name CharacterString R R

Object_Type BACnetObjectType R R

System_Status BACnetDeviceStatus R R

Vendor_Name CharacterString R R

Vendor_Identifier Unsigned16 R R

Model_Name CharacterString R R

Firmware_Revision CharacterString R R

Application_Software_Version CharacterString R R

Location CharacterString O R

Description CharacterString O R

Protocol_Version Unsigned R R

Protocol_Conformance_Class Unsigned(1…6) R R

Protocol_Services_Supported BACnetServiceSupported R R

Protocol_Object_Types_Supp orted

BACnetObjectTypesSupported R R

Object_List

BACnetARRAY[N] of BACnetObjectIdentifier

RR

Max_APDU_Length_Accepted Unsigtned R R

Segmentation_Supported BACnetSegmentation R R

VT_Class_Supported List of BACnetVTClass _1 -

Active_VT_Sessions List of BACnetVTSession _2 -

Installation/Owner Manual 103

Appendix 2

• Device Object Type (2)

Property Identifier Property Datatype BACnet BNU-BAC

Local_Time Time O3, 4 -

Local_Date Date O3, 4 -

UTC_Offset Signed O4 R

Daylight_Saving_Status Boolean O4 -

APDU_Segment_Timeout Unsigned O1 -

APDU_Timeout Unsigned R R

Number_Of_APDU_Retries Unsigned R R

List_Of_Session_Keys List of BACnetSessionKey O -

Time_Synchronization_Recipients

List of BACnetRecipient O5 -

Max_Master Unsigned(1…127) O6 -

Max_Info_Frames Unsigned O6 -

Device_Adress_Binding List of BACnetAddressBinding R R

Database_Revision Unsigned R R

Configuration_Files

BACnetARRAY[N] of BACnetObjectIdentifier

O7 -

Last_Restore_Time BACnetDateTime O7 -

Backup_Failure_Timeout Unsigned16 O8 -

Active_COV_Subscriptions List of BACnetCOVSubscription O9 -

Profile_Name CharacterString O R

104 BACnet Gateway

Appendix 2

ENGLISH

• Multi-state Input Object Type

Property Identifier Property Datatype BACnet BNU-BAC

Object_Identifier BACneObjectIdentifier R R

Object_Name CharacterString R R

Object_Type BACnetObjectType R R

Present_Value Unsigned R1 R

Description CharacterString O R

Device_Type CharacterString O -

Status_Flags BACnetStatusFlags R R

Event_State BACnetEventState R R

Reliability BACnetReliability O2 -

Out_Of_Service Boolean R R

Number_Of_States Unsigned R R

State_Text BACnetARRAY[N] of CharacterString O -

Time_Delay Unsigned O3 -

Notification_Class Unsigned O3 -

Alarm_Values List of Unsigned O3 -

Fault_Values List of Unsigned O3 -

Event_Enable BACnetEventTransitionBits O3 -

Acked_Transitions BACnetEventTransitionBits O3 -

Notify_Type BACnetNotifyType O3 -

Event_Time_Stamps BACnetARRAY[3] of BACnetTimeStamp O3 -

Profile_Name CharacterString O -

Installation/Owner Manual 105

2

3

1

4

D

I

6

7

5

8

L

G

-

N

E

T

1

9

R

T

X

1

0

X

1

1

2

1

L

L

G

G

-

N

-

N

E

E

T

T

2

T

R

X

X

1

1

3

L

G

-

1

4

N

5

E

T

4

3

T

R

T

X

X

1

6

R

X

X

1

8

1

1

7

E

9

x

t

1

T

X

2

0

M

R

X

S

E

E

L

N

U

/

E

x

t

2

T

E

X

C

T

R

X

E

t

h

e

r

n

e

t

1

A

E

C

t

h

T

e

r

n

e

t

2

L

L

A

C

N

N

T

K

K

2

1

C

o

n

s

o

l

4

3

D

O

e

T

R

X

X

R

P

u

o

n

w

e

r
