LG 24MT35S: instruction

SMART TV

Quick Setup Guide

Please read this manual carefully before operating

your set and retain it for future reference.

www.lg.com

P/NO: MFL67883501 (1402-REV03)

Printed in Korea

*MFL67883501*

ENG

ENGLISH

2

Wireless Network Connection

Wired Network Connection

* Image shown may differ from your TV.

* Image shown on a PC or mobile phone may vary depending on the OS(Operating System).

Internet connection

Wired router

wireless router

ENG

ENGLISH

3

Network Setting

Premium Apps are pre-installed on the TV. These may vary by country.

1  Press the

SMART

REC

 button to access the

Smart Home menu. Select

Settings

 and press

Wheel(OK)

.



Settings

More

More

Settings

2  Select the

NETWORK

 →

Network Connection

menu.

Network Connection

Network Status

Soft AP

Wi-Fi Direct

NETWORK

Miracast

TM

/ Intel's WiDi

My TV Name      : **

3  Select the

Start Connection

.

Connect to your wired or wireless network.

Network Connection

To connect to a wired network:

Connect a LAN cable to the back of TV.

To connect to a wireless network:

Requires a wireless router or access point.

Start Connection

or

Enjoy various Smart TV features through network.

4  The device automatically tries to connect to the

network available(wired network first).

Cancel

Connecting to the network.

Network Connection

If you select

Cancel

 or it fails to connect to the

network, the network list available is displayed.

Choose the network you want.

Choose the network you want.

Wired Network

Wireless : AAA

Wireless : BBB

Wireless : CCC

Wireless : 11111

Wireless : 22222

Manual Setup

Refresh List

Network Connection

If you want to connect your TV to a wireless router,

select the network you want and enter the password.

Network Connection

Wireless : AAA

Forgot your password? Contact your AP manufacturer.

Enter security key of network.

5  The connected network is displayed.

Select

Complete

 to confirm the network connection.

If you select the

Other Network List

, the network

list available is displayed.

Network is connected.

Wireless:AAA

Select [Other Network List] to connect to another network.

Complete

Other Network List

Network Connection

ENG

ENGLISH

4

1  Press the

SMART

REC

 button to access the Smart

Home menu. Select

Settings

 and press

Wheel(OK)

.



Settings

More

More

Settings

2  Select the

NETWORK

 →

Network Status

menu.

Network Connection

Network Status

Soft AP

Wi-Fi Direct

NETWORK

Miracast

TM

/ Intel's WiDi

My TV Name      : **

Follow the instructions below that correlate to your

network status.

Check the TV or the router.

Network Status

TV             Gateway           DNS            Internet

When an

✔

appears TV.

1

Check the connection status of TV, AP and cable

modem.

2

Power off and power on TV, AP and cable modem.

3

If you are using a static IP, enter IP directly.

4

Contact internet companies or AP companies.

y

 Additional points to check when using a

wireless connection

1

Check the password for the wireless

connection in the router settings window.

2

Change the router SSID (network name) or

the wireless channel.

Check the router or consult your Internet

service provider.

Network Status

TV             Gateway           DNS            Internet

When an

✔

 appears TV and Gateway.

1

 Unplug the power cord of the AP, cable modem

and try to connect after 5 seconds.

2

 Initialize(Reset) the AP or cable modem.

3

 Con

tact internet companies or AP companies.

Network Status

TV             Gateway           DNS            Internet

When an

✔

 appears TV, Gateway and DNS.

1

Unplug the power cord of the AP, cable modem

and try to connect after 5 seconds.

2

Initialize(Reset) the AP or cable modem.

3

Check that the MAC address of the TV/router is

registered with your Internet service provider. (The

MAC address displayed on the right pane of the

network status window should be registered with

your Internet service provider.)

4

Check the router manufacturer’s website to make

sure your router has the latest firmware version

installed.

Troubleshooting Network Problems

ENG

ENGLISH

5

Install the

 programme on your PC.

1  Go to

www.lg.com

 Then, select your region.

2  Select

SUPPORT

. Then, Search for your model.

3  Select

Drivers & Software

or

 SOFTWARE UPDATE

. Then, select

.

4  You can run the programme when installation is complete.

 NOTE

y

DLNA service is only available if TV and other devices are connected via a single router.

SmartShare PC SW Installing & Setting

DLNA Connection to Smartphone

1  Check that Wi-Fi is enabled on your smartphone.

2  Install/run the app for sharing content on your smartphone (It's called SmartShare on LG phones).

3  Enable your smartphone to share content files with other devices.

4  Select the file type you want to play (movie, audio or photo).

5  Select a movie, music or photo file to play on the TV.

6  Add the selected file to the playlist.

7  Select a TV model name on which to play the files. (The TV model name is labelled on the rear side of the

panel.)

8  Play the media file to view and enjoy it on your TV.

ENG

ENGLISH

6

SMART

REC

 →  Settings → SUPPORT

→

Software Update

Uses Software Update to check and obtain the latest version. If not updated, certain functions may not work

properly. It is also possible to check manually for available updates.

Software Update

Set it to

On

.

If an update is available, a prompt will appear to perform the update.

Automatic update mode

If an update is available, the update automatically starts without prompting.

Check Update Version

Checks the latest update version installed. When a new update is available, the

download process can be performed manually.

 NOTE

y

When the update starts, a pop-up window is displayed to show the update status and then disappears within

five seconds.

y

The latest version can be obtained via the digital broadcast signal or an internet connection.

y

Changing the programme while downloading the software via a digital broadcast signal interrupts the

download process. Returning to the initial programme allows downloading to resume.

y

If software is not updated, certain functions may not work properly.

y

[For Finland/Sweden/Denmark/Norway models.]

If the software update is performed via the broadcasting signal, you will be prompted to continue the update

regardless of whether the

Automatic update mode

 is enabled or not.

SMART

REC

→

  Settings

→

 NETWORK

→

 Wi-Fi Direct

The

Wi-Fi Direct

 function supports wireless connection technology. With SmartShare

TM

, you can share files or

screens of devices connected to

Wi-Fi Direct

.



[TAAAA]

Do you want to request a connection?

Automatically connect without asking

Yes

No

Connection

Wi-Fi Direct

Device Name

Connection

TAAAA

BBBB

Wi-Fi Direct

a

On

1  If

Wi-Fi Direct

 is set to

On

, a list of available devices

appears.

»

 To use

Wi-Fi Direct

, go to

Settings

→

 NETWORK

and

set

 Wi-Fi Direct

(

a

) to

On

.

2  When you are prompted to request connection, select

Yes

.

Wi-Fi Direct

 is now connected to your TV.

* If you are not using

Wi-Fi Direct

 to minimize the interference between Wi-Fi devices, it is recommended to set

Wi-Fi Direct

(

a

) to

Off

. You can only use devices that support

Wi-Fi Direct

.

Updating the TV Firmware

Wi-Fi Direct Setting

ENG

ENGLISH

7

Miracast

TM

 allows a portable device to securely send video and sound to TV wirelessly.

Connection

Miracast

TM

/ Intel's WiDi

Device Name

Connection

TAAAA

The device which is applied Miracast

TM

and intel's WiDi

technology can be shown on the TV.

Miracast

TM

 / Intel's WiDi

a

On

1  Miracast

TM

 is set to

On

 on your TV or portable device.

Go to the Network settings to set the Miracast

TM

.

2  When your portable device is detected, select the device.

3  For more information about how to connect the portable device, refer to the portable

device manual.

Miracast

TM

Setting

WiDi (Wireless Display) Setting

WiDi represents Wireless Display. Intel’s WiDi (Wireless Display) technology enables easy and fast connection

without wires or internet network for mirrored and dual monitor display on your TV. You can sit back and experience

your favorite movies, videos, photos, online shows and more in full HD on your TV with great image clarity and

sound.

1

Intel's WiDi

 is set to

On

. Connect your laptop to AP. (Without AP, it is possible to this function; it is

recommended to connect to AP.) Your laptap runs the Intel WiDi( ) programme.

2  It detects LG Smart TVs available, which supports WiDi. In the list, select the TV you want and click Connect.

Enter the PIN number(

a

) shown on the screen into the input field(

b

) on your laptop and then click Continue.

 NOTE

y

When you connect the TV and laptop, you should set up TV mode for “Live TV” and “external input”. If not,

your computer cannot detect LG Smart TV.



a

[Intel's WiDi] Request connection

Enter the following Security keys.

* When WiDi is connected, devices connected

with Wi-Fi Direct are disconnected.

MY PIN : ****

Cancel

Remain: 92 second(s)

b

TV Screen

Notebook Screen

3  The wireless environment may affect the screen display. If the connection is poor, the Intel WiDi connection may

be lost.

* LG TV is not need to register.

* For more information on Intel WiDi, visit

http://intel.com/go/widi.

* A list of

Intel's WiDi

 devices does not appear on the TV screen. Please check the list on your laptop.

ENG

ENGLISH

8

»

a

 :

Change Device tab

»

b

 :

Device control buttons

»

c

 :

Expand the ScreenRemote

»

d

 :

Exits the Screen Remote

»

e

 :

 Moves the position of the

ScreenRemote to left or right

Time Machine II

External Device Menu

External Device Menu

Time Machine II

a

b

d

e

c

Universal Control

To use the Universal Control function (for Magic Remote Control only)

With the Magic Remote Control, you can easily control your set-top box, Blu-ray player, home theater system, and

Sound Bar.

1  Check if the device is connected to the TV.

2  After pressing the '

Time Machine II

' button on the Magic Remote Control, select the device you want to control in the

Change Device tab. The Screen Remote that can control the device appears.

3  You can control external devices using the Screen Remote on the screen.

(This may not work with the '

Time Machine II

' button for some models.)

4  Control external devices using the navigation keys, wheel (OK), or BACK button on the Magic Remote Control.

Time Machine II

Time Machine II

Please call LG Customer Service if you experience any problems.
