ENGLISH

2.2 Set up Your Voice Account

Follow these steps to configure your VoIP account.

1 Press the Menu key, then press 6 to enter the Advanced Setting menu.

2 Press 2 to enter the SIP Configuration menu.

SIP Configuration

3 If VoIP 1 Config. does not display Active, select

1 VoIP 1 Config. (On)

its entry and press the Active softkey. If the SIP

2 VoIP 2 Config. (Off)

account is not active, you cannot use it to make

3 VoIP 3 Config. (Off)

or receive calls.

4 VoIP 4 Config. (Off)

Select On Off Back

4 Press 1 to select the SIP 1 Configuration menu. You can configure up to four SIP

accounts on the V500 (see the User’s Guide for details).

Enter the information exactly as given to you by your VoIP service provider.

" If your VoIP service provider did not give you information to use for any of

the fields in this menu, leave them at their default settings.

The following table describes the fields in this menu.

FIELD DESCRIPTION

1 Display Name Choose a name for this SIP account. This name displays in the SIP

account’s tab on the V500’s LCD screen.

2 SIP Number This is your SIP account number. If you have a SIP account like

1234567@voip-provider.com, the SIP Number is 1234567.

3 SIP Local Port This is the port on the V500 used for SIP calls. The default is 5060.

4 SIP Server Addr This is the IP address of the server your VoIP service provider uses for

SIP calls.

5 SIP Server Port This is the port on the SIP server used for SIP calls. The default is 5060.

6 SIP Register

This is the IP address of the server your VoIP service provider uses to

Server

register the V500. If your VoIP service provider did not give you a

specific SIP register server address, enter the SIP Server address

again.

13

ENGLISH

FIELD DESCRIPTION

7 SIP Register

This is the port the SIP register server uses to register the V500. The

Port

default is 5060.

8 SIP Service

If you have a SIP account like 1234567@voip-provider.com, the

Domain

SIP Service Domain is voip-provider.com.

9 SIP Auth ID This is the user name for this SIP account.

10 Auth Password This is the password for this SIP account.

11 Codec Priority Your V500 and the SIP server must use the same voice codec (coder /

decoder). Select the codecs you want the V500 to try using first, second

and third.

12 Voicemail

This is the number you enter to access your voicemail messages for this

Number

SIP account.

13 DNS SRV (Off) Turn this on (select On) to have the V500 use the DNS servers you

configured in section 2.1.2. Turn it off (select Off) if you do not want the

V500 to use DNS. DNS SRV is off by default.

14 Call ID Use this to turn outgoing caller ID on (On) or off (Off).

15 NAT Setting Use this to configure Network Address Translation.

16 Backup SIP

Use this to set up the SIP server(s) the V500 uses if it cannot access the

Server

main SIP server.

5 When you are done configuring SIP 1

11:45 2008-12-12

Configuration, press Back. The upper right

SIP 1

part of the LCD screen displays the SIP account

name you registered (“SIP1”, in this example).

Unused

6 See section 3 for how to test your V500’s

configuration by making a call.

ZyXEL

Unused

Unused

V If your SIP account does not register successfully (Unused or No Reg is

still displayed in the main screen) or you cannot make a call, check your

connections and re-enter your SIP settings. Restart the V500 (turn the

power off, then back on). If this does not help, contact your network

administrator or VoIP service provider.

14
