Thrustmaster Ferrari Wireless F430 Cockpit: TROUBLESHOOTING

EXAMPLES OF POSSIBLE USES:

- On PS3, programme L2/R2 or L3/R3 onto the Up and Down gearshift paddles (L1/R1 by default).

- On PS3, programme the Cross/Square buttons onto the pedals (L2/R2 by default).

- Switch different buttons for better access.

Note: The button cannot be programmed or moved.

EEPROM MEMORY

Your wheel has an internal chip that stores all your “MANUAL PRESET” programmes in memory (even

when the wheel is off or disconnected for a long period of time).

You can save a different “MANUAL PRESET” on each support used (PC and PS3).

DELETING A “MANUAL PRESET”

1

Activate your “MANUAL PRESET”

2

Press and hold the MAPPING

Your “MANUAL PRESET” is now blank (and becomes identical to the “AUTOMATIC PRESET”).

RETURN TO “FACTORY SETTINGS”

The aim here is to remove all of your programming or settings in one go.

1

All your “MANUAL PRESETS” (PC + PS3) or settings are now blank.

therefore carry out this operation only when no game is currently playing.

TROUBLESHOOTING

The wheel is not perfectly centred in the games:

- Switch off the wheel (by setting the switch to OFF). Physically centre the wheel. Next, switch the wheel

back on (by setting the switch to ON).

- If the problem persists, you can manually centre the wheel. To do this, position the wheel in perfect

alignment with the centre, and then simultaneously press “SELECT + START + ENGINE START” (this

operation must be carried out each time the wheel is switched on).

- On the PC, if the wheel or pedals are not properly calibrated, download the “Thrustmaster Calibration

Tool v 1.03” manual calibration software available at the following address: http://ts.thrustmaster.com

.

My wheel or pedals do not work correctly:

- Switch the wheel off and back on again (making sure the wheel is centred on start-up).

- Check the condition of the 4 LR6 / AA batteries and that their polarities are correctly positioned.

- If the problem persists, switch off your computer or your console, disconnect the USB receiver as well as

the power cord, reconnect all of them again, then restart and launch your game again.

On PC, my wheel is detected but does not work with my game:

Open the interface for managing your game’s “Options” to configure your wheel. Refer to your game’s

user manual or online help for more information.

On PS3, my wheel is not detected:

- In “1 player” mode: If your official gamepad is turned on, you will have to switch it to “controller port 2” (using

the “PS” button) for your wheel to be functional.

- If the problem persists, switch off your gamepad while leaving only the wheel connected.

My pedals do not work correctly in “Separate Mode”:

(E.g. when the game is running, the selection cursor moves all by itself)

Exit the game and switch the pedals to “combined” mode. Then return to your game to reconfigure the

wheel in your game’s option management interface.

My wheel cannot connect itself to the receiver:

The connection between the wheel and the receiver is made automatically.

In the event of a connection failure, you can force the connection by pressing the LED button of the

receiver (16), then simultaneously on your wheel’s SELECT + START +

buttons.

The

LED flashes continuously:

You must change the batteries.

SAFETY RECOMMENDATIONS AND INFORMATION

During extended periods of non-use, switch off the wheel (by setting the switch to OFF),

remove the wheel from its base and remove the 4 batteries from the battery compartment.

CAUTION: RISK OF EXPLOSION IF BATTERIES ARE REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

For safety reasons, never use the pedal set with bare feet or while wearing only socks on your feet.

®

THRUSTMASTER

DISCLAIMS ALL RESPONSIBILITY IN THE EVENT OF INJURY RESULTING FROM

USE OF THE PEDAL SET WITHOUT SHOES.

TECHNICAL SUPPORT

If you encounter a problem with your product, please go to http://ts.thrustmaster.com and click Technical

Support. From there you will be able to access various utilities (Frequently Asked Questions (FAQ), the

latest versions of drivers and software) that may help to resolve your problem. If the problem persists, you

can contact the Thrustmaster products technical support service (“Technical Support”):

By email:

In order to take advantage of technical support by email, you must first register online. The information you

provide will help the agents to resolve your problem more quickly. Click Registration on the left-hand side

of the Technical Support page and follow the on-screen instructions. If you have already registered, fill in

the Username and Password fields and then click Login.

By telephone (if you do not have Internet access):

08450800942

United Kingdom

Monday to Saturday from 8 a.m. to 7 p.m.

Charged at local rate

1-866-889-5036

United States

Free

Saturday from 8 a.m. to 2 p.m.

(Eastern Standard Time)

Monday to Friday from 6 a.m. to 5 p.m.

Saturday from 5 a.m. to 11 a.m.

1-866-889-2181

Canada

Free

Saturday from 8 a.m. to 2 p.m.

(Eastern Standard Time)

Monday to Friday from 6 a.m. to 5 p.m.

Saturday from 5 a.m. to 11 a.m.

80887690

Monday to Saturday from 9 a.m. to 8 p.m.

Denmark

Free

(English)

0200884567

Monday to Saturday from 9 a.m. to 8 p.m.

Sweden

Free

(English)

0800 913060

Monday to Saturday from 10 a.m. to 9 p.m.

Finland

Free

(English)

Hours of operation and telephone numbers are subject to change. Please visit http://ts.thrustmaster.com for the most up-to-

date Technical Support contact information.

WARRANTY INFORMATION

Worldwide, Guillemot Corporation S.A. (“Guillemot”) warrants to the consumer that this Thrustmaster product will

be free from material defects and manufacturing flaws for a period of two (2) years from the original date of

purchase. Should the product appear to be defective during the warranty period, immediately contact Technical

Support, who will indicate the procedure to follow. If the defect is confirmed, the product must be returned to its

place of purchase (or any other location indicated by Technical Support).

Within the context of this warranty, the consumer’s defective product will, at Technical Support’s option, be either

repaired or replaced. Where authorized by applicable law, the full liability of Guillemot and its subsidiaries

(including for indirect damages) is limited to the repair or replacement of the Thrustmaster product. The consumer’s

legal rights with respect to legislation applicable to the sale of consumer goods are not affected by this warranty.

This warranty shall not apply: (1) if the product has been modified, opened, altered, or has suffered damage as a

result of inappropriate or abusive use, negligence, an accident, normal wear, or any other cause not related to a

material defect or manufacturing flaw; (2) in the event of failure to comply with the instructions provided by

Technical Support; (3) to software not published by Guillemot, said software being subject to a specific warranty

provided by its publisher.

Additional warranty provisions

In the United States of America and in Canada, this warranty is limited to the product’s internal mechanism and

external housing. Any applicable implied warranties, including warranties of merchantability and fitness for a

particular purpose, are hereby limited to two (2) years from the date of purchase and are subject to the conditions

set forth in this limited warranty. In no event shall Guillemot Corporation S.A. or its affiliates be liable for

consequential or incidental damage resulting from the breach of any express or implied warranties. Some

States/Provinces do not allow limitation on how long an implied warranty lasts or exclusion or limitation of

incidental/consequential damages, so the above limitation may not apply to you. This warranty gives you specific

legal rights, and you may also have other legal rights which vary from State to State or Province to Province.

Statement of Compliance with EU Regulations

Guillemot Corporation S.A. hereby declares that the device Ferrari Wireless GT Cockpit complies with the main

requirements and other relevant clauses of R&TTE Directive 1999/5/EC. The compliance statement can be viewed

at the following site:

http://www.thrustmaster.com/certificates/Ferrari_Wireless_GT_Cockpit/Doc-

ferrari_Wireless_GT_cockpit.pdf

COPYRIGHT

© 2012 G

uillemot Corporation S.A. All rights reserved. Thrustmaster

®

is a registered trademark of Guillemot

Corporation S.A. Ferrari® is a registered trademark of Ferrari Idea S.p.A. PlayStation® is a registered trademark of

Sony Computer Entertainment Inc. Microsoft® Windows® is a registered trademark of Microsoft Corporation in the

United States and/or other countries. All other trademarks and brand names are hereby acknowledged and are

property of their respective owners. Illustrations not binding. Contents, designs and specifications are subject to

change without notice and may vary from one country to another. Made in China.

ENVIRONMENTAL PROTECTION RECOMMENDATION

At the end of its working life, this product should not be disposed of with standard household

waste, but rather dropped off at a collection point for the disposal of Waste Electrical and

Electronic Equipment (WEEE) for recycling.

This is confirmed by the symbol found on the product, user manual or packaging.

Depending on their characteristics, the materials may be recycled. Through recycling and

other forms of processing Waste Electrical and Electronic Equipment, you can make a

significant contribution towards helping to protect the environment.

Please contact your local authorities for information on the collection point nearest you.

Operates with 4 batteries LR6 / AA (1.5V), not included. Do not recharge non-rechargeable batteries. Used

batteries must be removed from the toy. Different types of batteries or new and used batteries must not be mixed.

Only batteries of the recommended type or similar type must be used. Batteries must be inserted with the correct

polarity. The terminals of a battery must not be short-circuited.

www.thrustmaster.com
