Thrustmaster Ferrari Wireless F430 Cockpit: PC

PC

INSTALLATION ON PC

Required configuration: PC (Windows® Xp, Windows® Vista, Windows® 7) equipped with a USB port

The CD-ROM included with this product allows you to install the drivers.

1. Insert the installation CD-ROM into your CD-ROM drive. The install wizard is displayed automatically (if the

installation menu does not run automatically, double-click “Workstation”, then the icon of the CD-ROM and,

“Setup.exe” if necessary).

2. Click on the “DRIVERS” to start installing the drivers.

3. Once the installation is complete, click Finish and restart your computer.

4. Set the PC/PS3 switch (17) of the receiver (14) to the “PC” position.

5. Once your computer has restarted, connect the USB connector (15) of the receiver to one of the USB ports

of your central unit. Windows® will automatically detect the new device.

6. Drivers are installed automatically.

Follow the on-screen instructions to complete the installation.

7. Select Start/Programs/Thrustmaster/Control Panel to access the Control Panel.

The Game controllers dialogue box will display the name of the wheel with the OK status.

8. In the Control Panel, click Properties to test and view the buttons, D-pad and axes of the wheel and

the pedal set.

You are now ready to play!

Important notes on PC:

- The PC/PS3 (17) switch of the receiver must always be set to “PC” before connecting the wheel.

- The wheel name declared on PC (in the Control Panel and in the games) is “F430 Cockpit Wireless”.
