Thrustmaster Ferrari Wireless F430 Cockpit: GENERAL

GENERAL

WHEEL POWER BUTTON

- OFF position = the wheel is off (and does not use the batteries).

- ON position = the wheel is on.

The wheel and receiver are automatically connected.

If the connection fails, you can force the connection by pressing the LED button of the receiver (16), then

the SELECT + START +

buttons simultaneously on the wheel.

STANDBY MODE

The wheel automatically switches off:

- After 5 minutes of inactivity.

- After 5 seconds if the connection fails or is lost.

or operating the wheel’s ON/OFF switch.

“PC / PS3” SWITCH (17) OF THE RECEIVER

This switch must always be set to the correct position before you connect your receiver to the USB port of

your PlayStation®3 or PC.

LED AND RECEIVER LED (16)

- Both LEDs are on = connection set up between the wheel and the receiver.

- Both LEDs flash quickly = no connection between the wheel and the receiver.

-All the LEDs on the Manettino are off = the wheel is in standby mode or off.

- The

LED flashes slowly and continuously = you must change the batteries.

AUTOMATIC CALIBRATION OF THE WHEEL AND PEDALS

- The centre of the wheel is preset as soon as you turn it on: it is therefore vital for the wheel to be perfectly

aligned on its axis when you switch it on.

- Nevertheless, you can manually adjust the centre of the wheel. To do this, position the wheel in perfect

alignment with the centre, and then simultaneously press “SELECT + START + ENGINE START” (this

operation must be carried out each time the wheel is switched on).

- The steering of the wheel and the pedals automatically self-calibrate.
