Thrustmaster HOTAS Warthog: инструкция

Compatible: PC

Hardware User Manual

U.S. Air Force A-10C attack aircraft HOTAS™(**) (Hands On Throttle And Stick) replica

joystick pack, including:

1 Replica JOYSTICK

• Innovative new H.E.A.R.T HallEffect AccuRate Technology(*):

- 3D magnetic sensors (Hall Effect) on the stick

- 16-bit resolution (65536 x 65536 values)

- 5 coil spring system(*)

• USB connection with upgradeable firmware

• Super-stable, weighted base (over 3kg)

• New detachable handle, crafted entirely of metal:

- also compatible with HOTAS COUGAR™ handle (and vice-versa)

- new replica shape

- detachable metal plate for desk- or cockpit-style use

- new, realistic pressure on buttons and trigger

- 19 action buttons in total + one 8-way “point of view” hat:

. 1 x 8-way “point of view” hat

. 2 x 8-way hats

. 1 x 4-way hat with push button

. 1 x metal dual trigger

. 2 x push buttons

. 2 x pinkie push buttons

1 Replica CONTROL PANEL

- Weighted base (over 3,5kg) incorporated underneath the throttles

- Backlit functions

- 5 programmable LEDs

- Realistic pressure on buttons and switches

- 15 action buttons in total + 1 TRIM wheel:

. 1 x TRIM wheel

. 2 x push buttons

. 5 x 2-position switches (2 permanent)

. 2 x 3-position switches (1 momentary + 2 permanent)

. 2 x 3-position switches (3 permanent)

Dual Replica THROTTLES

• Innovative new H.E.A.R.T HallEffect AccuRate Technology(*):

- 3D magnetic sensors (Hall Effect) on the 2 throttles

- 14-bit resolution (16384 values) on each throttle

• USB connection with upgradeable firmware

• Dual throttles, featuring:

- metal hand rest

- locking system

- adjustable friction system

- realistic IDLE detent with “Pull & Push”(*) system

- realistic and disengageable AFTERBURNER detent with “Pull & Push”(*) system

- realistic pressure on buttons and switches

- 17 action buttons in total + 1 mouse hat with push button + one 8-way “point of view” hat:

. 1 x mouse hat with push button and 3D magnetic sensor (Hall Effect)

. 1 x 8-way hat

. 1 x 4-way hat with push button

. 1 x push button

. 1 x 3-position switch (2 momentary + 1 permanent)

. 2 x 3-position switches (3 permanent)

. 1 x 3-position switch (1 momentary + 2 permanent)

(*) Patent pending.

(**) HOTAS™ is a trademark of Guillemot Corporation S.A.

CONFIGURATION OF BUTTONS AND AXES

On the JOYSTICK:

On the THROTTLE:

On the CONTROL PANEL:

“A-10C” AIRCRAFT FUNCTIONS

On the JOYSTICK:

On the THROTTLE:

INSTALLING THE JOYSTICK IN A COCKPIT OR OTHER FIXED SUPPORT

To attach the joystick in a cockpit:

- Unscrew the 4 screws located underneath the joystick’s metal base plate, and remove the

metal base plate.

- Use the 4 screw threads located on the underside of the joystick to attach the joystick

directly to your fixed support.

You can also use the 4 holes located in the corners of the metal base plates of the joystick

and the throttle to attach both elements to a fixed support.

THROTTLE ADJUSTABLE FRICTION SYSTEM

- To increase the friction: turn the wheel to the right.

- To decrease the friction: turn the wheel to the left.

IMPORTANT NOTES:

- Friction on the dual throttles is set to the minimum value by default.

- In order to allow for precise adjustment according to your taste, roughly ten full turns must

be made to go from minimum friction to maximum friction.

- You can use the white mark, found on the wheel, to help count your turns, if necessary.

BACKWARDS-COMPATIBILITY

The new “HOTAS Warthog” handle is backwards-compatible with the base of the “HOTAS

Cougar” (and vice versa).

Only the CMS push button (button 19) will be non-functional, as it was not originally featured

on the HOTAS Cougar.

CONTROL PANEL BACKLIGHTING

The intensity of the control panel's backlighting can be adjusted directly via T.A.R.G.E.T

(Thrustmaster Advanced pRogramming Graphical EdiTor). Five different levels of intensity

are available: from 1 (minimum intensity) to 5 (maximum intensity), with the default level set

at 2.

MANAGING THE 5 PROGRAMMABLE LEDS

You can manage the Control Panel’s 5 programmable LEDs directly via T.A.R.G.E.T.

(Thrustmaster Advanced pRogramming Graphical EdiTor).
