WIDE PANEL

This flashgun is equipped with a built-in wide panel,

which can provide an ultra wide 17mm angle of

coverage. Slide out the wide panel and catch light

panel and flip it down to cover the flash’s head. (Be

careful to slide the panels out smoothly.) Then put the

catch light panel back in its place. The coverage angle

setting of the flash will be set to 17mm automatically.

◆

If the built-in wide panel comes off accidentally, the

ZOOM button will not function. In this case please

contact the store where the flash was purchased, or

an authorized .Sigma service station.

LCD PANEL ILLUMINATION

When you press the LIGHT button, the LCD panel will illuminate for about 8 seconds. The illumination

stays on longer than 8 seconds if you press the LIGHT button once again.

SETTING THE ISO FILM SPEED

The ISO film speed is automatically set for the combination of EF-610 DG SUPER NA-iTTL with Digital

SLR Cameras, or the F6, F5, F4 series, F100, F90X/F90/F80 (N90S/N90/N80) series, F75D/N75,

F65/N65, F70/N70, F810S/N8008S, F801/N8008 and Pronea600i. To confirm ISO film speed, press

the MODE button. If your camera is not one of the models listed above,

please follow the procedure below.

1. Press the MODE button until ISO is selected.

2. Press the SEL button. The ISO value will blink.

3. Press

+

or

–

to set ISO film speed.

4. Press the SEL button and make the indicator stop blinking.

TTL MODE

TTL mode can provide the correct exposure for the subject and will control the amount of flash.

◆ Please refer to <<CHART

A

>> which shows the combinations of camera and lens types, exposure

mode, and flash modes.

◆ TTL function does not work when using the following cameras: F3 series, FM10, New FM2, FE10,

Nikonos V.

1. Set the desired exposure mode on your camera. Please refer to

Camera’s Instruction manual.

2. Slide the Flash’s power switch to the ON position.

3. Select TTL/BL or TTL by pressing the MODE button.

◆ When using Digital SLR Cameras, please select TTL/BL. Depending

on the camera model, i-TTL or D-TTL system will be used. The ”

d

”

mark will be displayed on the LCD panel for both systems.

◆ For the following cameras; F5, F4 series, F100, F90X/F90/F80

(N90S/N90/N80) series, F70D/N70, F810S/N8008S, F801/ N8008S

and Pronea 600i, TTL/BL or TTL can be selected. However, cameras

other than those listed above, only TTL can be selected.

4. Focus on the subject.

5. Confirm that the subject is located within the effective distance range, indicated on the LCD panel.

17

◆ Depending on the combination of the camera, lens and selected exposure mode, the method for

shooting the subject with flash may be different. Please see chart “

A

” and set the “F”-number by

referring to the manual for your camera.

6. Confirm the Ready Light is on and press the shutter release button.

◆ When the camera does not receive the appropriate exposure for the subject, the TTL/BL or TTL

mark on the LCD panel will appear for 5 seconds after shooting, which shows that the flash power is

not sufficient for this situation. Please re-take at a closer distance or use a wider aperture. In the

case of F5, F100, F90X/F90/F80 (N90S/N90/N80) series and F70D/N70 cameras, the

underexposure indicator appears for 5 seconds. If you want to see the display for underexposure

again, please depress the LIGHT button.

◆ When the flash is fully charged, the ready light in the camera’s viewfinder will appear. If it does not

appear, the shutter of the camera may operate at a slow shutter speed without triggering the flash.

◆ If you use the AF camera with an AF lens, the AF Auxiliary Light will turn on automatically as you

focus on a subject in a dark area. However the AF Auxiliary Light will not light up if central focus

area is not selected.

<< CHART

A

>>

Exp.

Conf

Camera Lens Type

Metering TTL System Note

Mode

Dist

3-D Multi-Sensor

F5

D, G Type All Modes All Modes

BL

F100

Can switch to TTL Mode. With

1

F90X/N90ser.

AF lens other

F5, F100, F80, series Cameras

All Modes All Modes Multi-Sensor BL

F80/N80ser.

than D, G type

spot metering system is always

F70D/N70

Without Built in

A/M

Center-weighted,

Center Weighted

TTL.

F75/N75

2

CPU

Modes

Spot Metering

/ Spot Fill-Flash

Matrix Pattern TTL BL Can switch to TTL Mode.

With Built-in CPU All Modes

Center-weighted,

Center Weighted

TTL BL can work with only F4

1

F4 Series

Spot Metering

/ Spot Fill-Flash

series, AF F3, Ai-S, Ai, Series E

F-801S/N8008S

lens. Spot metering system of

F-801/N8008

F4 is always TTL.

F65/N65

Without

A/M

Center-weighted,

Center Weighted

Pronea 600i will be TTL, when

2

Pronea 600i

Built-in CPU

Modes

Spot Metering

/ Spot Fill-Flash

exposure mode is “M”. Center

Weighted BL cannot work.

Matrix Pattern TTL BL

With Built-in CPU All Modes

Center-weighted,

Center Weighted

F601/N6006

Spot Metering cannot use with

Spot Metering

/ Spot Fill-Flash

2

F-601M

F-601M

Without

A/M

Center-weighted,

Center Weighted

Built-in CPU

Modes

Spot Metering

/ Spot Fill-Flash

If exposure mode is “M”, it will

P/S

F60D/N60

With Built-in CPU

TTL BL

be Center Weighted / Spot

A/M

F50D/N50

Fill-Flash

2

F-401X/4004S

Without

Center Weighted

M

Built-in CPU

/ Spot Fill-Flash

Built-in CPU lens,

P

TTL Programmed

Ai-S, Ai, Series E,

F501/N2020

AF F3 Lens

A/M TTL

2

F301/N2000

Except above

A/M TTL

lenses

P/S

TTL Programmed

F401S/N4004S

With Built-in CPU

A/M TTL

2

F401/N4004

Without Built-in CPU

M TTL

FA, FE2

With Built-in CPU;

A/M TTL

2

FG, F3, FM3

Without Built-in CPU

Confirm Distance:

1

: Flash’s LCD panel will show the F-number and working distance of flash automatically.

2

: Set the F-number on the flash to be the same as camera, and check the available working distance

range on the LCD panel. To set the F-number on the Flash, push the SEL button until the F-number blinks,

and use + or – button to set the F-number. Then press the SEL button again. The F-number will stop

blinking.

◆ When using Digital SLR cameras, functions will vary depending on the lens type and combinations

of exposure modes, same as F5 and F100 group (in chart A), however, they will use D-TTL (i-TTL).
