Indesit DFP 2727: Start-up and use

EN

20

Start-up and use

Measuring out the detergent

A good wash result also depends on the correct

amount of detergent being used; exceeding the stated

amount does not result in a more effective wash and

increases environmental pollution.

Only use detergent which has been specifically

designed for dishwashers.

     DO NOT USE washing up liquid.

Using excessive detergent may result in foam

residue remaining in the machine after the cycle has

ended.

The use of tablets is only recommended for

models which offer the MULTI-FUNCTIONAL TABLETS

option.

To achieve the best results from each washing

and drying cycle, powder detergent, rinse aid liquid

and salt should be used.

Compartment A:

 Washing detergent

Compartment B:

 Pre-wash detergent

1. Open cover C by pressing

button D.

2. Pour in the detergent after

consulting the

Table of wash

cycles:

• For powder detergent use

compartments A and B.

• For detergent in tablet form:

when the cycle requires 1 tablet, place it in compartment

A and close the cover; when it requires 2, place the

second tablet at the bottom of the appliance.

3. Remove detergent residues from the edges of the

compartment and close the cover until it clicks.

A

B

D

C

*

 Only available in selected models.

Starting the dishwasher

1. Turn the water tap on.

2. Press the ON/OFF button:  all the indicator lights on

the control panel will  light  up for a few seconds.

3. Open the door and pour in a suitable amount of

detergent (

see below).

4. Load the racks (

see Loading the racks) and shut the

door.

5. Select the wash cycle by turning the WASH CYCLE

SELECT knob in a clockwise direction: align the notch

on the knob with the number or symbol representing

the desired wash cycle. The START/PAUSE indicator

light will flash.

6. Select the wash options

*

 (

see adjacent

information).

7. Start the cycle by pressing the START button; the

indicator light will light up and remain lit in a fixed

manner.  The indicator light corresponding to the

wash

 phase will switch on, signalling that the wash

cycle has begun.

8. At the end of the wash cycle the

END

 indicator light

will switch on

(fixed light).  Switch off the appliance by

pressing the ON/OFF button, shut off the water valve

and unplug the appliance from the electricity socket.

9. Wait for a few minutes before removing the

crockery, in order to avoid burns. Unload the racks,

beginning with the lower level.

- The machine will switch off automatically

during certain periods of inactivity, in order to

minimise electricity consumption.

Modifying a wash cycle in progress

If a mistake was made during the wash cycle selection

process it is possible to change the cycle, provided that

it has only just begun: once the wash cycle has started,

switch off the machine by pressing and holding the ON/

OFF/Reset button. Switch it back on using the same

button and select the desired wash cycle and options.

Adding extra crockery

Press the Start/Pause button (the corresponding

indicator light will flash). Open the door, taking care to

avoid the escaping steam, and place the crockery inside

the appliance. Press the Start/Pause button (fixed light):

the cycle starts from the point at which it was interrupted.

If the Start/Pause button is pressed so as to pause the

machine, the wash cycle or the Delayed Start

*

 function

(if selected) is interrupted.

At this stage it is not possible to change the wash cycle.

Accidental interruptions

If the door is opened during the wash cycle, or if there is

a power cut, the cycle stops. It starts again from the point

at which it was interrupted once the door has been shut

or once the electricity supply is restored.

EN

21

Half load

If there are not many dishes to be washed, a half load

cycle may be used in order to save water, electricity and

detergent. Select the wash cycle and press the HALF

LOAD button: the indicator light will illuminate.

Remember to halve the amount of detergent.

 It is better to use powder detergent in this case.

This option is incompatible with the following wash

cycle: Rapide wash.

Delayed start

It is possible to delay the start time of the wash cycle by

3, 6 or 9 hours.

1: After selecting the desired wash cycle and any other

options, press the DELAYED START button. the indicator

light will illuminate.

2: Select the desired delay time by pressing the Delayed

Start button repeatedly; the wash phase (3 hours), the

drying phase (6 hours) and end (9 hours) indicator lights

will illuminate in succession.

If the Delayed Start button is pressed again, the option is

deselected and the indicator light switches off.

3. The countdown will begin once the Start/Pause button

has been pressed. The selected delay period indicator

light flashes and the Start/Pause button stops flashing

(the light becomes fixed instead).

3. Once this time has elapsed, the DELAYED START

indicator light switches off and the wash cycle begins.

 The Delayed Start function cannot be set once a

wash cycle has been started.

*

 Only available in selected models.

Wash options

The OPTIONS may only be set, modified or reset

after the wash cycle has been selected and before

the Start/Pause button has been pressed.

Only the options which are compatible with the type of

wash cycle set may be selected. If an option is not com-

patible with the selected was cycle

(see Table of wash

cycles), the corresponding LED flashes rapidly 3 times.

If an option is selected which is incompatible with an-

other option or wash cycle selected previously, the in-

compatible option light will flash 3 times and switches

off, while the most recently selected setting remains lit.

To deselect an option which has been set by mis-

take, press the corresponding button again.

A

B

Table of

options

Delayed

Start

Half

Load

1. Intensive

Yes Yes

2. Normal

Yes Yes

3. Smart Sixty

Yes Yes

4. Soak

Yes Yes

5. Eco

Yes Yes

6. Rapid

Yes No

7. Delicates

Yes Yes
