5

Wiring (fig. 6)

1. Remove the cover from the device

 by unscrewing the six screws

2. Remove the cap

 or unscrew the blanking plug

 depending on the desired point of entry

3. Attach the cable gland (not supplied)

4. If required, re-attach the blanking plug

 and its nut into the empty hole

(tightening torque = 1±0.1 Nm /

0.73±0.07 lb.ft

5. Lift the protective sheet

 without damaging it

6. Connect the electrical cables to the yoke screw terminals (tightening torque = 1±0.2 Nm /

0.73±0.15 lb.ft

7. Check that there are no cables passing through the reset switch area

8. Carefully put back in place the protective sheet

9. Mount the cover onto the device

 using the six screws

 (tightening torque = 1.5±0.1 Nm /

1.1±0.369 lb.ft

)

NOTE: Install a type gG 10A protective fuse

RISK OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH

• Switch off the power supply of the device

• Use a cable gland and an IP65 plastic nut

• Protect the installation against power surges

• Match the figure 7 for versions H4 and H7

• Use appropriate personal protective equipment (PPE) and follow the relevant working instructions for

electrical environments. See NFPA 70E.

• Always use an appropriate electrical measuring device to confirm that the entire installation is powered

down.

Failure to follow these instructions will result in death or serious injury.

RISK OF UNINTENDED EQUIPMENT OPERATION

• Do not remove those components marked with red varnish

• Ensure that the reset switch zone remains empty

• Check that none of the device components is deformed by an electrical cable once the cover is closed

• Check that the cover is securely closed

Failure to follow these instructions will result in death or serious injury.

DANGER DANGER DANGER DANGER
