Operating instructions

Premium-Line

Comfort Switch Plus

Introduction

Please read the operating instructions carefully.

Keep the operating instructions and give them to

each user of the multiple socket. For the use of

the multiple socket observe the safety instructi-

ons contained in the operating instructions.

For questions on spare parts or repairs please

contact the manufacturer.

Scope of supply

1 x multiple socket

1 x external hand/foot switch

1 x operating instructions

Safety instructions

Please observe the following safety instructions.

Failure to comply with the instructions can result

in personal injury and damage.

Damages caused by failure to comply with the

operating instructions, especially the safety and

handling instructions, void the warranty.

The manufacturer cannot be held responsible for

any subsequent damage.

10

068611 Premium-Line Comfort-Switch:068611 Premium-Line Comfort-Switch 11.08.11 14:52 Uhr Seite 10

Premium-Line Operating Instructions

For your safety

Danger

Risk of death from electric shock

Do not touch damaged, exposed or energised

parts. Danger from electric shock.

☛ Make sure you check the multiple socket for

damages before use. Do not use the multiple

socket if the cable insulations or the casing are

damaged.

Danger

Uncontrolled starting devices:

In case of fault, connected devices might start

uncontrolled if they have electronically

controlled switches.

Do not use the multiple socket with devices

from which danger might arise in case of

uncontrolled operation.

• To avoid danger, a damaged connecting line of

the multiple socket should be replaced by the

manufacturer, by a Service representative or a

skilled technician only.

• Do not manipulate or alter the multiple socket.

• Repairs should be performed by a skilled

technician only.

• Keep the multiple socket away from children.

11

068611 Premium-Line Comfort-Switch:068611 Premium-Line Comfort-Switch 11.08.11 14:52 Uhr Seite 11

Operating Instructions Premium-Line

• Operate only one device per device.

•

Do not cover the multiple socket during operation.

Proper use

The multiple socket should be used in dry rooms

exclusively for private purposes. Do not use the

multiple socket near liquids that might leak or

spout (e.g. aquarium).

Any other use is not permitted.

Product overview

1. Cable with power plug

2. External hand/foot switch

with control light for swit-

ching status

3. RJ-11 plug/jack for external

hand/foot switch

All sockets are childproof

and are aligned at an angle

of 45°.

12

2

3

1

068611 Premium-Line Comfort-Switch:068611 Premium-Line Comfort-Switch 11.08.11 14:52 Uhr Seite 12

Premium-Line Operating Instructions

Technical data

Designation: Premium-Line

CSP

Supply voltage: 230 V~ / 50 Hz

Total output: max. 16 A /

3500 W

Connecting line: 3 m H05VV-F

2

3G x 1.5 mm

Control line external switch: 1.5 m with RJ-11

connector

Functionality and Operation

Permanent sockets (depending on model)

The permanent sockets are independent from the

status of the external hand/foot switch, always on.

External hand/foot switch

The switchable sockets “ON/OFF” can be two-pole

switched on and off by the external hand/foot

switch. The switching status is shown by the

control light at the hand/foot switch. In this way

the connected devices can be switched comforta-

ble, while the extension socket can be in a hidden

position.

To get a simple installation, the external hand/foot

switch is supplied with a connector. With a push on

the clip of the RJ-11 plug it can be released from

the extension socket, positioned comfortable, if

necessary put through a small hole and start

operating with just plug in again. If the 1.5 m

13

068611 Premium-Line Comfort-Switch:068611 Premium-Line Comfort-Switch 11.08.11 14:52 Uhr Seite 13

Operating Instructions Premium-Line

control line on the external switch is too short for

your application, you can extend it by using a RJ-11

extension line (6p4c with 1:1 pinning) out of the

telephone accessories market just between

extension socket and external switch.

Caution

It is allowed to connect on the RJ-11 jack of

the extension socket the external hand/foot

switch and a RJ-11 extension line (6p4c with

1:1 pinning) only

When connecting other devices, these devices

and the extension socket could be damaged.

Maintenance and cleaning

The multiple socket is maintenance-free.

Danger

Risk of death from electric shock

Do not touch damaged, exposed and energised

parts of the multiple socket and of the cable.

Danger to life from electric shock.

☛ Never clean the multiple socket when it is

energised.

☛ Remove the plug from the outlet before

cleaning.

☛ Never immerse the multiple socket in water.

14

068611 Premium-Line Comfort-Switch:068611 Premium-Line Comfort-Switch 11.08.11 14:52 Uhr Seite 14

Premium-Line Operating Instructions

Clean the multiple socket with a dry cloth.

Disposal

Do not dispose of electrical appliances

together with household waste!

According to the European Directive

2002/96/EC on waste electrical and electronic

equipment, used electric equipment should be

disposed of separately and environmentally-

friendly recycled.

For information on the disposal of old equipment

please contact your local authority.

Declaration of conformity

The CE mark has been affixed in compliance with

the following European directives:

• 2006/95/EC Low voltage directive

• 2004/108/EC EMC Directive

The declaration of conformity has been lodged

with the manufacturer.

Manufacturer:

H. Brennenstuhl GmbH u. Co. KG, Seestraße 1-3,

72074 Tübingen, Germany

15
