Sigma ELECTRONIC FLASH EF-610 DG SUPER EO-ETTL II (キヤノン用): BOUNCE FLASH

5. After pressing the SEL button again, the flash power level will blink.

6. Press the

+

or

-

button to set the desired power level.

7. Press the SEL button again, the number of flashes will blink.

8. Press the

+

or

-

button to set the desired number of flashes.

9. Press the SEL button again, the display will stop blinking.

10. When the ready light of the flash is illuminated, the unit is ready to use.

Note: Please set the shutter speed longer than; Number of Flashes you want ÷ Firing Frequency

BOUNCE FLASH

When you take a photo with flash in a room, sometimes a strong shadow will appear behind the subject,

if you point the flash head upwards or sideways to reflect the light off the ceiling, wall etc. the subject

will be illuminated softly. Press the lock button and adjust the flash head to set the bounce angle.

UP: 0°, 60°, 75°, 90° DOWN: 0°,7°

RIGHT: 0°, 60°, 75°, 90°

LEFT: 0°, 60°, 75°,90°, 120°, 150°, 180°

When the bounce flash mode is activated, a bounce indicator

will appear on the LCD panel.

Choose a white surface for bouncing the flash, otherwise the

image’s colour may be incorrect.

Depending on the reflecting surface, the subject distance and other

factors, the effective distance range for the TTL AUTO may change.

Please check for correct exposure confirmation (ETTL or TTL mark

on the LCD panel) after releasing the shutter.

CLOSE-UP EXPOSURES

Bounce flash can be tilted 7° downward for close-ups. The Flash will be effective only for the subjects

0.5 meter to 2 meters. When the flash head is tilted 7°,

will blink.

CATCH LIGHT PANEL

This flash is equipped with a built-in catch

light panel, which can create a catch light in

the eyes of the subject when the bounce

flash mode is activated. Slide out the wide

panel and catch light panel, and then put

wide panel back in its place. (Be careful to

slide the panels out smoothly.)

◆ To create a catch light effectively, tilt the flash head upward 90 degrees and take pictures at a close

distance.

WIRELESS FLASH

When using the “Wireless Flash” mode, you can take pictures with a more three-dimensional feeling,

or make natural images by using shadowing depending on the flash position. This can be done without

any extension cord connecting the camera body and flash. In case of the EF-610 DG SUPER,

communication between the camera body and the flash will be achieved by the light produced by the

flash. In the “Wireless Flash” mode, the camera will calculate the correct exposure automatically.

◆The type A camera models can be used with “Wireless Manual Flash” and “Wireless Multi Flash”

functions only. The EOS750 and EOS850 cannot be used with “Wireless Flash”.

◆

In this instruction we call the flash unit which is attached to the camera body the “Master unit ” and

we call a flash unit at a remote position a “Slave unit”.

◆

When setting a slave unit at the desired position, you can use the mini-stand provided. This

mini-stand has a screw hole for a tripod.

◆

Place the slave flash unit at the desired location. Do not place the slave unit within the picture area.

22

◆

Set the flash unit within the range of 0.5m/1.5ft~5m/16ft from the subject and set the camera body

within the range of 1m/3ft~5m/16ft from the subject.

Preparation for Wireless Flash

Channel Setting

When other people are using Wireless Flash mode near you, your flash may be connected with the

other person’s flash and your flash may fire. In this circumstance, please set a different channel for

your flash from that of the other person’s.

Channel setting for Master unit

1. Press the MODE button to Select the

mark.

2. Press the SEL button several times to make the channel indicator

blink.

3. Press the

+

or

-

button to set the channel number. (C1～C4)

4. Press the SEL button several times to stop the blinking.

Channel setting for Slave unit

1. Press the MODE button to Select the ETTL／ ／

mark.

2.

Press the SEL button several times to make the channel indicator blink.

3. Press the

+

or

-

button to set the channel to the same number.

(C1 ～ C4) as the master unit.

4. Press the SEL button several times to stop the blinking.

◆ If the channel number of the Master and Slave flashguns are different, the Slave will not fire. Please set

the same number for Master and Slave.

Slave Unit ID Setting

When you use several Slave units, the Slave ID can be set to distinguish a Slave unit from Main flash.

◆ If you want to all Slave units to fire at the same flash output, this setting is not necessary.

1. Press the MODE button to Select the ETTL／

／

mark.

2. Press the SEL button three times to make the Slave ID indicator blink.

3. Press the

+

or

-

button and set the ID number. (1, 2 or 3)

4. Press the SEL button again so the display stops blinking.

◆ Repeat this process for each slave unit you are using, giving each one a different ID number.

Master Flash ON/OFF Setting

You can set the Master flash unit firing ON or OFF.

Master Flash unit firing ON

1. Press the MODE button to Select the

mark.

2. Press the

+

or

-

button to indicate the mark.

Master Flash unit firing OFF

1. Press the MODE button to Select the

mark.

2. Press the

+

or

-

button to indicate the mark.

WIRELESS ETTL AUTOFLASH (type A cameras only)

In this Wireless ETTL Autoflash function, the camera automatically calculates the correct exposure.

Wireless ETTL Autoflash with Flash Ratio OFF

If you require an equal power ratio for each flash unit, the slave ID setting is not necessary. You can set 1, 2

or 3 for each Slave Unit in use.

All the Slave flash units will fire at the same flash output and the ETTL autoflash system controls the total

flash amount automatically, to obtain a correct flash exposure.

The instructions below show how to reset the flashgun so no flash ratio is used and therefore equal power

is emmited from each flashgun.

23

◆ Please set the Master Flash unit as follows:

1. Press the MODE button to select the ETTL／

mark.

2. Press the

+

or

-

button to display the mark (Master Flash will fire) or the shows (Master Flash

will not fire) in the LCD display.

3. Press the SEL button several times and confirm that the flash ratio is 1:1.

◆ If the flash ratio is indicated as or , press the

+

or

-

button until 1:1 is displayed.

4. Place the Slave Unit at the desired position.

5. Make sure that the Master Unit and Slave Unit have both been charged.

◆ Master Unit’s Ready Light is lit and Slave Unit’s AF Auxiliary Light is blinking.

6. Focus on the subject and take the picture.

Slave ID, Wireless ETTL Autoflash With Flash Ratio (Two Slave Units)

The Wireless ETTL autoflash system, described as an example, consists of a master unit on the camera,

which will not fire, and two slave units. When you set the flash ratio, the ETTL autoflash system then

controls the total flash amount according to the flash ratio, to obtain a correct exposure.

◆ Only EOS-1V, EOS-3 cameras can use this function.

◆ The flash ratio can be set between 8 : 1 ～ 1 : 1 ～ 1 : 8.

◆ Please set the Slave ID to 1 and 2 for each Slave unit.

Set the Master unit as follow.

1. Please set the Master Flash unit firing mode to OFF (see Mater Flash ON / OFF setting).

2. Press the MODE button to Select the ETTL

／

mark.

3. Press the SEL button several times to make the flash ratio indicator blink.

4. Press the

+

or

-

button and select . (Blinking)

5. Press the SEL button to make flash ratio value blink.

6. Press the

+

or

-

button to set the flash ratio.

7. Press the SEL button to make the Flash Ratio indicator stop blinking.

8. Place the Slave Unit at the desired position.

9.

Confirm that both the master and slave units are charged.

10. Focus on the subject and take the picture.

◆ If you want to change the settings, you can start from step 3.

◆ If you want to cancel the setting, please set the flash ratio 1:1. (refer to step 4)

Slave ID, Wireless ETTL Autoflash With Flash Ratio (Three Slave Units)

The following wireless ETTL autoflash procedure is for a master unit with three (3) slave units. This procedure

sets the flash ratio for two Slave Units and the flash exposure compensation amount for other slave unit.

◆ Only EOS-1V and EOS-3 camera can use this function.

◆ Please set the Slave ID 1, 2 and 3 for each Slave unit (See Slave ID Setting).

Set the Master unit as follow.

1. Please set the Master Flash unit firing mode to OFF (See Master Flash ON / OFF Settings).

2. Press the MODE button to Select the ETTL／ mark.

3. Press the SEL button several times to make the flash ratio indicator display blink.

4. Press the

+

or

-

button to select the 1 2 3. (Blinking)

5. Press the SEL button to make the flash ratio value blink.

6. Press the

+

or

-

button to set the flash ratio.

7. Press the SEL button to make the flash exposure compensation display blink.

8. Press the

+

or

-

button and set the flash exposure compensation amount.

9. Press the SEL button to make the indicator stop blinking.

10. Place the Slave Units at the desired position.

11. Confirm that both the master and slave units are charged.

12. Focus on the subject and take the picture.

◆ If you want to change the settings or cancel the flash ratio settings, you can start from step 3.

Wireless High-Speed Sync (FP Flash)

1. Please set the master flash to Wireless Flash mode. (Refer to Page 21)

2. Press the

+

or

-

button to set to ／ (Master Flash unit firing ON) or ／ (Master Flash

unit firing OFF).
