ASRock P75 Pro3: 1. Introduction

4

ASRock  P75 Pro3  Motherboard

1.  Introduction

Thank you for purchasing ASRock

P75 Pro3

motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may

fi

 nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1  Package Contents

ASRock

P75 Pro3

 Motherboard

(ATX Form Factor: 12.0-in x 7.0-in, 30.5 cm x 17.8 cm)

ASRock

P75 Pro3

 Quick Installation Guide

ASRock

P75 Pro3

 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-

bit, it is recommended to set the BIOS option in Storage Con

fi

 guration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

English

5

ASRock  P75 Pro3  Motherboard

English

1.2  Speci

fi

 cations

 Platform

- ATX Form Factor: 12.0-in x 7.0-in, 30.5 cm x 17.8 cm

- All Solid Capacitor design

 CPU

- Supports 3

rd

 and 2

nd

 Generation Intel

®

 Core

TM

 i7 / i5 / i3 in

  LGA1155 Package

- Supports Intel

®

 Turbo Boost 2.0 Technology

 Chipset

- Intel

®

 B75

- Supports Intel

®

 Small Business Advantage (see

CAUTION 1

)

- Supports Intel

®

 Rapid Start Technology and Smart Connect

Technology

 Memory

- Dual Channel DDR3 Memory Technology

- 2 x DDR3 DIMM slots

- Supports DDR3 2200(OC)*/1600/1333/1066 non-ECC,

  un-buffered memory (DDR3 1600 with Intel

®

 Ivy Bridge

  CPU, DDR3 1333 with Intel

®

 Sandy Bridge CPU)

  * DDR3 2200(OC) is only supported with Intel

®

 Core

TM

 i7

    3770K

- Max. capacity of system memory: 16GB (see

CAUTION 2

)

- Supports Intel

®

 Extreme Memory Pro

fi

 le (XMP)1.3/1.2

 Expansion Slot

- 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)

  * PCIE 3.0 is only supported with Intel

®

 Ivy Bridge CPU. With

    Intel

®

 Sandy Bridge CPU, it only supports PCIE 2.0.

- 1 x PCI Express 2.0 x16 slot (PCIE3: x4 mode)

- 2 x PCI Express 2.0 x1 slots

- 2 x PCI slots

- Supports AMD Quad CrossFireX

TM

 and CrossFireX

TM

Audio

- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

  * To con

fi

 gure 7.1 CH audio, please use an HD front panel

    audio module and enable the multi-channel audio feature

    through the audio driver.

 LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Mouse/Keyboard Port

- 1 x Parallel Port (ECP/EPP Support)

- 1 x Serial Port: COM1

6

ASRock  P75 Pro3  Motherboard

English

- 1 x Coaxial SPDIF Out Port

- 4 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

 SATA3

- 1 x SATA3 6.0 Gb/s connector, supports NCQ, AHCI and

  Hot Plug functions

 USB3.0

- 2 x Rear USB 3.0 ports, support USB 1.1/2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),

  supports USB 1.1/2.0/3.0 up to 5Gb/s

Connector

- 5 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

  Hot Plug functions

- 1 x SATA3 6.0Gb/s connector

- 1 x IR header

- 1 x CIR header

- 1 x HDMI_SPDIF header

- 1 x Power LED header

- 1 x Chassis Intrusion header

- 1 x CPU Fan connector (4-pin)

- 2 x Chassis Fan connectors (1 x 4-pin, 1 x 3-pin)

- 1 x Power Fan connector (3-pin)

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS Feature

- 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU Core, DRAM, 1.8V PLL, VTT, VCCSA Voltage

  Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

  Multimedia Suite - OEM

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allows Chassis Fan Speed Auto-

  Adjust by CPU Temperature)

7

ASRock  P75 Pro3  Motherboard

English

- CPU/Chassis Fan Multi-Speed Control

- CASE OPEN detection

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

 Windows

®

 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit /

  XP / XP 64-bit compliant (see

CAUTION 3

)

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

 * For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. Intel

®

 Small Business Advantage is a customizable platform in-

tegrated with IT tools, which helps maximize employee produc-

tivity, PC performance, and data security. There are applications

including Software Monitor, PC Health Center, Data Backup &

Restore, Energy Saver and USB Blocker.

2.  Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage

under Windows

®

 7 / Vista

TM

 / XP. For Windows

®

 OS with 64-bit

CPU, there is no such limitation. You can use ASRock XFast

RAM to utilize the memory that Windows

®

 cannot use.

3.  ASRock XFast RAM is not supported by Microsoft

®

Windows

®

XP / XP 64-bit. Intel

®

 Smart Connect Technology and Intel

®

 USB

3.0 ports are not supported by Microsoft

®

 Windows

®

 Vista

TM

 /

Vista

TM

 64-bit / XP / XP

64-bit.

 WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

 overclocking.

8

ASRock  P75 Pro3  Motherboard

English

1.3  Unique Features

ASRock Extreme Tuning Utility (AXTU)

ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to

ne-tune different system functions in a user-friendly interface,

which includes Hardware Monitor, Fan Control, Overclocking,

OC DNA, IES and XFast RAM. In Hardware Monitor, it shows

the major readings of your system. In Fan Control, it shows the

fan speed and temperature for you to adjust. In Overclocking,

you are allowed to overclock CPU frequency for optimal system

performance. In OC DNA, you can save your OC settings as

a pro

fi

 le and share it with your friends. Your friends then can

load the OC pro

fi

 le to their own system to get the same OC set-

tings. In IES (Intelligent Energy Saver), the voltage regulator

can reduce the number of output phases to improve ef

fi

 ciency

when the CPU cores are idle without sacri

fi

 cing computing per-

formance. In XFast RAM, it fully utilizes the memory space that

cannot be used under Windows

®

 OS 32-bit CPU.

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more ef

fi

 cient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows

®

to shorten boot up time. By calling S3 and S4 at speci

fi

 c timing

during the shutdown and startup process, Instant Boot allows

you to enter your Windows

®

 desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS

fl

 ash utility embedded in Flash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems

fi

 rst like MS-

DOS or Windows

®

. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

save the new BIOS

fi

 le to your USB

fl

 ash  drive,

fl

 oppy disk or

hard drive, then you can update your BIOS only in a few clicks

without preparing an additional

fl

 oppy diskette or other compli-

cated

fl

 ash utility. Please be noted that the USB

fl

 ash drive or

hard drive must use FAT32/16/12

fi

 le system.

9

ASRock  P75 Pro3  Motherboard

English

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock has

prepared a wonderful solution for you - ASRock APP Charger.

Simply install the APP Charger driver, it makes your iPhone

charge much quickly from your computer and up to 40% faster

than before. ASRock APP Charger allows you to quickly charge

many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1),

Suspend to RAM (S3), hibernation mode (S4) or power off (S5).

With APP Charger driver installed, you can easily enjoy the mar-

velous charging experience.

ASRock XFast USB

ASRock XFast USB can boost USB storage device perfor-

mance. The performance may depend on the properties of the

device.

ASRock XFast LAN

ASRock XFast LAN provides a faster internet access, which

includes the benefits listed below. LAN Application Prioritiza-

tion: You can con

fi

 gure your application’s priority ideally and/or

add new programs. Lower Latency in Game: After setting online

game’s priority higher, it can lower the latency in games. Traf

fi

 c

Shaping: You can watch Youtube HD videos and download si-

multaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are

transferring currently.

ASRock XFast RAM

ASRock XFast RAM is a new function that is included into AS-

Rock Extreme Tuning Utility (AXTU). It fully utilizes the memory

space that cannot be used under Windows

®

 OS 32-bit CPU.

ASRock XFast RAM shortens the loading time of previously

visited websites, making web surfing faster than ever. And it

also boosts the speed of Adobe Photoshop 5 times faster. An-

other advantage of ASRock XFast RAM is that it reduces the

frequency of accessing your SSDs or HDDs in order to extend

their lifespan.

10

ASRock  P75 Pro3  Motherboard

English

ASRock Crashless BIOS

ASRock Crashless BIOS allows users to update their BIOS

without fear of failing. If power loss occurs during the BIOS up-

date process, ASRock Crashless BIOS will automatically

fi

 nish

the BIOS update procedure after regaining power. Please note

that BIOS

fi

 les need to be placed in the root directory of your

USB disk. Only USB2.0 ports support this feature.

ASRock On/Off Play Technology

ASRock On/Off Play Technology allows users to enjoy the great

audio experience from the portable audio devices, such like

MP3 player or mobile phone to your PC, even when the PC is

turned off (or in ACPI S5 mode)! This motherboard also provides

a free 3.5mm audio cable (optional) that ensures users the most

convenient computing environment.

ASRock OMG (Online Management Guard)

Administrators are able to establish an internet curfew or restrict

internet access at speci

fi

 ed times via OMG. You may schedule

the starting and ending hours of internet access granted to other

users. In order to prevent users from bypassing OMG, guest

accounts without permission to modify the system time are re-

quired.

ASRock Internet Flash

ASRock Internet Flash searches for available UEFI firmware

updates from our servers. In other words, the system can auto-

detect the latest UEFI from our servers and

fl

 ash them without

entering Windows

®

 OS. Please note that you must be running

on a DHCP con

fi

 gured computer in order to enable this function.

ASRock UEFI System Browser

ASRock UEFI system browser is a useful tool included in

graphical UEFI. It can detect the devices and configurations

that users are currently using in their PC. With the UEFI system

browser, you can easily examine the current system con

fi

 gura-

tion in UEFI setup.

11

ASRock  P75 Pro3  Motherboard

English

ASRock Dehumidi

fi

 er Function

Users may prevent motherboard damages due to dampness by

enabling “Dehumidi

fi

 er Function”. When enabling Dehumidi

fi

 er

Function, the computer will power on automatically to dehumidi-

fy the system after entering S4/S5 state.

ASRock Fast Boot

With ASRock’s exclusive Fast Boot technology, it takes less

than 1.5 seconds to logon to Windows

®

 8 from a cold boot. No

more waiting! The speedy boot will completely change your user

experience and behavior.

ASRock Combo Cooler Option (C.C.O.)

Combo Cooler Option (C.C.O.) provides the

fl

 exible option to

adopt three different CPU cooler types, Socket LGA 775, LGA

1155 and LGA 1156. Please be noticed that not all the 775 and

1156 CPU Fan can be used.

ASRock Good Night LED

ASRock Good Night LED technology can offer you a better en-

vironment by extinguishing the unessential LED. By enabling

Good Night LED in BIOS, the Power / HDD / LAN LED will be

switched off when system is on. Not only this, Good night LED

will automatically switch off Power and Keyboard LED when the

system enters into Standby / Hibernation mode as well.
