English

ASRock Website: http://www.asrock.com

Published June 2013

Copyright

©

2013 ASRock INC. All rights reserved.

1

X79 Extreme11 Motherboard

Motherboard Layout

1 Power Fan Connector (PWR_FAN1)

26 USB 2.0 Header (USB_8_9, Black)

2 2 x 240-pin DDR3 DIMM Slots

27 Consumer Infrared Module Header

(DDR3_A1, DDR3_B1, Black)

(CIR1, Gray)

3 2 x 240-pin DDR3 DIMM Slots

28 Reset Switch (RSTBTN1)

(DDR3_A2, DDR3_B2, Black)

29 USB 2.0 Header (USB_10_11, Black)

4 ATX 12V Power Connector (ATX12V2)

30 Power Switch (PWRBTN1)

5 ATX 12V Power Connector (ATX12V1)

31 USB 2.0 Header (USB_12_13, Black)

6 2011-Pin CPU Socket

32 Dr. Debug

7 CPU Fan Connector (CPU_FAN1)

33 Chassis Fan Connector (CHA_FAN2)

8 CPU Fan Connector (CPU_FAN2)

34 Chassis Speaker Header (SPEAKER1)

9 2 x 240-pin DDR3 DIMM Slots

35 Power LED Header (PLED1)

(DDR3_D2, DDR3_C2, Black)

36 System Panel Header (PANEL1, Black)

10 2 x 240-pin DDR3 DIMM Slots

37 SLI / XFIRE Power Connector

(DDR3_D1, DDR3_C1, Black)

(SLI/XFIRE_PWR2)

11 ATX Power Connector (ATXPWR1)

38 Clear CMOS Jumper (CLRCMOS1)

12 USB 3.0 Header (USB3_4_5, Black)

39 Infrared Module Header (IR1)

13 USB 3.0 Header (USB3_6_7, Black)

40 Front Panel IEEE 1394 Header

14 SPI Flash Memory (64Mb)

(FRONT_1394)

English

15 Chassis Fan Connector (CHA_FAN3)

41 Front Panel Audio Header (HD_AUDIO1)

16 SB Fan Connector (SB_FAN1)

42 HDMI_SPDIF Header (HDMI_SPDIF1)

17 SATA3 Connector (SATA3_0_1, Gray)

43 PCI Express 3.0 x16 Slot (PCIE7, Black)

18 SATA2 Connector (SATA2_0_1, Black)

44 PCI Express 3.0 x16 Slot (PCIE6, Black)

19 SATA2 Connector (SATA2_2_3, Black)

45

PCI Express 3.0 x16 Slot (PCIE5, Black)

20 SAS Connector (SAS_0_1, Gray)

46 PCI Express 3.0 x16 Slot (PCIE4, Black)

21 SAS Connector (SAS_2_3, Gray)

47 PCI Express 3.0 x16 Slot (PCIE3, Black)

22 SAS Connector (SAS_4_5, Gray)

48 PCI Express 3.0 x16 Slot (PCIE2, Black)

23 SAS Connector (SAS_6_7, Gray)

49 PCI Express 3.0 x16 Slot (PCIE1, Black)

24 Intel X79 Chipset

50 SLI / XFIRE Power Connector

25 Chassis Fan Connector (CHA_FAN1)

(SLI/XFIRE_PWR1)

2

X79 Extreme11 Motherboard

I/O Panel

1 USB 2.0 Ports (USB01)

** 10 Front Speaker (Lime)

* 2 LAN RJ-45 Port

11 Microphone (Pink)

3 IEEE 1394 Port (IEEE 1394)

*** 12 eSATA Connectors

* 4 LAN RJ-45 Port

13 USB 3.0 Ports (USB3_0_1)

5 USB 3.0 Ports (USB3_23)

14 USB 2.0 Ports (USB3_67)

6 Central / Bass (Orange)

15 USB 2.0 Ports (USB3_4_5)

7 Rear Speaker (Black)

16 USB 2.0 Ports (USB3_2_3)

8 Optical SPDIF Out Port

17 Clear CMOS Switch (CLRCBTN)

9 Line In (Light Blue)

18 PS/2 Keyboard Port (Purple)

* There are two LEDs next to the LAN port. Please refer to the table below for the LAN port LED

indications.

ACT/LINK

SPEED

LAN Port LED Indications

LED

LED

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

LAN Port

**

If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”.

See the table below for connection details in accordance with the type of speaker you use.

TABLE for Audio Output Connection

Audio Output Channels Front Speaker Rear Speaker Central / Bass Line in

(No. 10) (No. 7) (No. 6) (No. 9)

2 V -- -- --

4 -- -- -- --

English

6 V V V --

8 V V V V

3

X79 Extreme11 Motherboard

1. Introduction

Thank you for purchasing X79 Extreme11 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance. This Quick Installation Guide contains introduction of the motherboard

and step-by-step installation guide. More detailed information of the motherboard

can be found in the user manual presented in the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

X79 Extreme11 Motherboard

(CEB Form Factor: 12.0-in x 10.5-in, 30.5 cm x 26.7 cm)

X79 Extreme11 Quick Installation Guide

X79 Extreme11 Support CD

6 x Serial ATA (SATA) Data Cables (Optional)

2 x Serial ATA (SATA) HDD Power Cables (Optional)

1 x I/O Panel Shield

1 x Front USB 3.0 Panel

4 x HDD Screws

6 x Chassis Screws

1 x Rear USB 3.0 Bracket

2 x ASRock SLI_Bridge Cards

1 x ASRock SLI_Bridge_3S Card

1 x ASRock 3-Way SLI Bridge Card

English

ASRock Reminds You...

®

TM

TM

To get better performance in Windows

7 / 7 64-bit / Vista

/ Vista

64-

bit, it is recommended to set the BIOS option in Storage Conguration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

4

X79 Extreme11 Motherboard

1.2 Specifications

Platform - CEB Form Factor: 12.0-in x 10.5-in, 30.5 cm x 26.7 cm

- Premium Gold Capacitor design (100% Japan-made high-

quality Conductive Polymer Capacitors)

®

TM

CPU - Supports Intel

Core

i7 processor family for the LGA 2011

Socket

- Digi Power Design

- 24 + 2 Power Phase Design

- Dual-Stack MOSFET (DSM) (see CAUTION 1)

®

- Supports Intel

Turbo Boost 2.0 Technology

- Supports Hyper-Threading Technology (see CAUTION 2)

- Supports Untied Overclocking Technology

®

Chipset - Intel

X79

Memory - Quad Channel DDR3 Memory Technology (see CAUTION 3)

- 8 x DDR3 DIMM slots

- Supports DDR3 2500+(OC)/2133(OC)/1866(OC)/1600/1333/

1066 non-ECC, un-buffered memory

®

- Supports DDR3 ECC, un-buffered memory with Intel

®

Workstation 1S Xeon

processors E5 16xx/26xx/46xx

series in socket LGA 2011

- Max. capacity of system memory: 64GB (see CAUTION 4)

®

- Supports Intel

Extreme Memory Prole (XMP)1.3/1.2

Expansion Slot - 7 x PCI Express 3.0 x16 slots (PCIE1/PCIE3/PCIE5/PCIE7:

x16/16/16/16 mode; PCIE1/PCIE2/PCIE3/PCIE4/PCIE5/

PCIE6/PCIE7: x16/8/8/8/8/8/8) (see CAUTION 5)

TM

TM

- Supports AMD Quad CrossFireX

, 4-Way CrossFireX

,

TM

TM

3-Way CrossFireX

and CrossFireX

®

TM

TM

TM

- Supports NVIDIA

Quad SLI

, 4-Way SLI

, 3-Way SLI

TM

and SLI

Audio - 7.1 CH HD Audio

- Creative Sound Core3D quad-core sound and voice

processor

- Supports CrystalVoice

- Supports Scout Mode

- Supports EAX1.0 to EAX5.0

- Premium Headset Amplier (PHA) (see CAUTION 6)

English

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Broadcom BCM57781

- Supports Wake-On-LAN

5

X79 Extreme11 Motherboard

- Supports Energy Efcient Ethernet 802.3az

- Supports Dual LAN with Teaming function

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Keyboard Port

- 1 x Optical SPDIF Out Port

- 8 x Ready-to-Use USB 2.0 Ports

- 2 x eSATA Connectors

- 4 x Ready-to-Use USB 3.0 Ports

- 2 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- 1 x IEEE 1394 Port

- 1 x Clear CMOS Switch with LED

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone (see CAUTION 7)

®

SATA3 - 2 x SATA3 6.0 Gb/s connectors by Intel

X79, support RAID

(RAID 0, RAID 1, RAID 5, RAID 10 and Intel Rapid Storage

3.0), NCQ, AHCI and Hot Plug

- 8 x SAS/SATA3 6.0 Gb/s connectors by LSI SAS2308,

support RAID (RAID 0, RAID 1, RAID 1E and RAID10),

NCQ and Hot Plug

®

USB3.0 - 4 x Rear USB 3.0 ports by TI

, support USB 1.0/2.0/3.0 up

to 5Gb/s

®

- 2 x Front USB 3.0 headers (support 4 USB 3.0 ports) by TI

,

support USB 1.0/2.0/3.0 up to 5Gb/s

Connector - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10 and Intel Rapid Storage 3.0),

NCQ, AHCI and Hot Plug

- 2 x SATA3 6.0Gb/s connectors

- 8 x SAS/SATA3 6.0 Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x HDMI_SPDIF header

- 1 x IEEE 1394 header

English

- 1 x Power LED header

- 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)

- 3 x Chassis Fan connectors (1 x 4-pin, 2 x 3-pin)

- 1 x Power Fan connector (3-pin)

- 1 x SB Fan connector (3-pin)

- 24 pin ATX power connector

- 2 x 8 pin 12V power connectors

6

X79 Extreme11 Motherboard

- 2 x SLI/XFire power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

- 2 x USB 3.0 header (supports 4 USB 3.0 ports)

- 1 x Dr. Debug with LED

- 1 x Power Switch with LED

- 1 x Reset Switch with LED

- 1 x Clear CMOS Switch with LED

BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU, VCCSA, DRAM, VTT, CPU PLL, PCH1.1V, PCH1.5V

Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 8)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 9)

- ASRock APP Charger (see CAUTION 10)

- ASRock XFast USB (see CAUTION 11)

- ASRock XFast LAN (see CAUTION 12)

- ASRock XFast RAM (see CAUTION 13)

- ASRock X-FAN (see CAUTION 14)

- ASRock Crashless BIOS (see CAUTION 15)

- ASRock OMG (Online Management Guard)

(see CAUTION 16)

- ASRock Internet Flash (see CAUTION 17)

- ASRock UEFI System Browser

- ASRock Easy RAID Installer

- ASRock Interactive UEFI

- Hybrid Booster:

- CPU Frequency Stepless Control (see CAUTION 18)

- ASRock U-COP (see CAUTION 19)

- Boot Failure Guard (B.F.G.)

- Good Night LED

English

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

7

X79 Extreme11 Motherboard

- CPU/Chassis/Power/SB Fan Tachometer

- CPU/Chassis Quiet Fan (Allows Chassis Fan Speed Auto-

Adjust by CPU Temperature)

- CPU/Chassis/SB Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

®

®

TM

TM

OS - Microsoft

Windows

7 / 7 64-bit / Vista

/ Vista

64-bit

compliant

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 20)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your system. It should be

done at your own risk and expense. We are not responsible for possible damage

caused by overclocking.

CAUTION!

1. Dual-Stack MOSFET (DSM) is an innovative new design of MOSFETs.

The silicon die area is increased by stacking two dies into a MOSFET.

The larger the die area, the lower Rds(on). Compared to traditional dis-

crete MOSFET, DSM can provide larger die area and lower Rds(on), so

the power supply for CPU Vcore is more efcient.

2. About the setting of “Hyper Threading Technology”, please check page

80 of the User Manual.

3. This motherboard supports Quad Channel Memory Technology. Before

English

you implement Quad Channel Memory Technology, make sure to read

the installation guide of memory modules on page 16 for proper installa-

tion.

4. Due to the operating system limitation, the actual memory size may be

®

less than 4GB for the reservation for system usage under Windows

7

TM

®

/ Vista

. For Windows

OS with 64-bit CPU, there is no such limitation.

®

You can use ASRock XFast RAM to utilize the memory that Windows

cannot use.

8

X79 Extreme11 Motherboard

®

5. Currently Intel

Socket 2011 Sandy Bridge-E Processor doesn’t support

PCIE 3.0, but this motherboard is already PCIE 3.0 hardware ready. It

depends on Intel’s CPU to enable PCIE 3.0. Please check Intel’s website

for information on future CPU updates and releases.

6. For serious gamers and enthusiasts who cannot tolerate mediocre audio,

Premium Headset Amplier (PHA) provides wider bandwidth, higher slew

rate with lower noise and distortion. It also supports up to 250 Ohm high-

end headsets, which delivers crisper audio into the users ears.

7. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 6-chan-

nel, and 8-channel modes. Please check the table on page 3 for proper

connection.

8. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune dif-

ferent system functions in a user-friendly interface, which includes Hard-

ware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hardware

Monitor, it shows the major readings of your system. In Fan Control, it

shows the fan speed and temperature for you to adjust. In Overclocking,

you are allowed to overclock CPU frequency for optimal system per-

formance. In OC DNA, you can save your OC settings as a prole and

share it with your friends. Your friends then can load the OC prole to

their own system to get the same OC settings. In IES (Intelligent Energy

Saver), the voltage regulator can reduce the number of output phases to

improve efciency when the CPU cores are idle without sacricing com-

puting performance. Please visit our website for the operation procedures

of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

9. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

®

without entering operating systems rst like MS-DOS or Windows

. With

this utility, you can press the <F6> key during the POST or the <F2>

key to enter into the BIOS setup menu to access ASRock Instant Flash.

Just launch this tool and save the new BIOS le to your USB ash drive,

oppy disk or hard drive, then you can update your BIOS only in a few

clicks without preparing an additional oppy diskette or other complicated

ash utility. Please be noted that the USB ash drive or hard drive must

use FAT32/16/12 le system.

10. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply install the APP Charger driv-

er, it makes your iPhone charge much quickly from your computer and

up to 40% faster than before. ASRock APP Charger allows you to quickly

charge many Apple devices simultaneously and even supports continu-

English

ous charging when your PC enters into Standby mode (S1), Suspend to

RAM (S3), hibernation mode (S4) or power off (S5). With APP Charger

driver installed, you can easily enjoy the marvelous charging experience.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

9

X79 Extreme11 Motherboard
