ASRock Fatal1ty Z77 Professional: инструкция

Fatal1ty Story

Who knew that at age 19, I would be a World Champion PC gamer. When I was 13, I

actually played competitive billiards in professional tournaments and won four or five

games off guys who played at the highest level. I actually thought of making a career

of it, but at that young age situations change rapidly. Because I’ve been blessed with

great hand-eye coordination and a grasp of mathematics (an important element in video

gaming) I gravitated to that activity.

GOING PRO

I started professional gaming in 1999 when I entered the CPL (Cyberathlete Professional

League) tournament in Dallas and won $4,000 for coming in third place. Emerging as one

of the top players in the United States, a company interested in sponsoring me ew me

to Sweden to compete against the top 12 players in the world. I won 18 straight games,

lost none, and took rst place, becoming the number one ranked Quake III player in the

world in the process. Two months later I followed that success by traveling to Dallas

and defending my title as the world’s best Quake III player, winning the $40,000 grand

prize. From there I entered competitions all over the world, including Singapore, Korea,

Germany, Australia, Holland and Brazil in addition to Los Angeles, New York and St.

Louis.

WINNING STREAK

I was excited to showcase my true gaming skills when defending my title as CPL

Champion of the year at the CPL Winter 2001 because I would be competing in a totally

different first person shooter (fps) game, Alien vs. Predator II. I won that competition

and walked away with a new car. The next year I won the same title playing Unreal

Tournament 2003, becoming the only three-time CPL champion of the year. And I did it

playing a different game each year, something no one else has ever done and a feat of

which I am extremely proud.

At QuakeCon 2002, I faced off against my rival ZeRo4 in one of the most highly

anticipated matches of the year, winning in a 14 to (-1) killer victory. Competing at

Quakecon 2004, I became the World’s 1st Doom3 Champion by defeating Daler in a

series of very challenging matches and earning $25,000 for the victory.

Since then Fatal1ty has traveled the globe to compete against the best in the world,

winning prizes and acclaim, including the 2005 CPL World Tour Championship in New

York City for a $150,000 rst place triumph. In August 2007, Johnathan was awarded the

English

rst ever Lifetime Achievement Award in the four year history of the eSports-Award for

“showing exceptional sportsmanship, taking part in shaping eSports into what it is today

and for being the prime representative of this young sport. He has become the gurehead

for eSports worldwide”.

1

Fatal1ty Z77 Professional Series Motherboard

LIVIN’ LARGE

Since my rst big tournament wins, I have been a “Professional Cyberathlete”, traveling

the world and livin’ large with lots of International media coverage on outlets such as

MTV, ESPN and a 60 Minutes segment on CBS to name only a few. It's unreal - it's crazy.

I’m living a dream by playing video games for a living. I’ve always been athletic and

took sports like hockey and football very seriously, working out and training hard. This

discipline helps me become a better gamer and my drive to be the best has opened the

doors necessary to become a professional.

A DREAM

Now, another dream is being realized – building the ultimate gaming computer, made

up of the best parts under my own brand. Quality hardware makes a huge difference in

competitions…a couple more frames per second and everything gets really nice. It’s all

about getting the computer processing faster and allowing more uid movement around

the maps.

My vision for Fatal1ty hardware is to allow gamers to focus on the game without worrying

about their equipment, something I’ve preached since I began competing. I don’t want to

worry about my equipment. I want to be there – over and done with - so I can focus on the

game. I want it to be the fastest and most stable computer equipment on the face of the

planet, so quality is what Fatal1ty Brand products represent.

Johnathan “Fatal1ty” Wendel

English

The Fatal1ty name, Fatal1ty logos and the Fatal1ty likeness are registered trademarks of

Fatal1ty, Inc., and are used under license. © 2012 Fatal1ty, Inc. All rights reserved. All other

trademarks are the property of their respective owners.

2

Fatal1ty Z77 Professional Series Motherboard

Copyright Notice:

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by us. We assumes no responsibility for any errors or omissions

that may appear in this manual.

With respect to the contents of this manual, We do not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or

conditions of merchantability or tness for a particular purpose.

In no event shall we, its directors, ofcers, employees, or agents be liable for any

indirect, special, incidental, or consequential damages (including damages for loss

of prots, loss of business, loss of data, interruption of business and the like), even

if we have been advised of the possibility of such damages arising from any defect

or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

The Fatal1ty name, Fatal1ty logos and the Fatal1ty likeness are registered trade-

English

marks of Fatal1ty, Inc., and are used under license. © 2012 Fatal1ty, Inc. All rights

reserved. All other trademarks are the property of their respective owners.

Fatal1ty website: www.fatal1ty.com

Published June 2013

3

Fatal1ty Z77 Professional Series Motherboard

Motherboard Layout

1 1155-Pin CPU Socket

23 Dr. Debug

2 ATX 12V Power Connector (ATX12V1)

24 USB 2.0 Header (USB_6_7, Black)

3 CPU Fan Connector (CPU_FAN1)

25 USB 2.0 Header (USB_8_9, Black)

4 CPU Fan Connector (CPU_FAN2)

26 Chassis Fan Connector (CHA_FAN1)

5 2 x 240-pin DDR3 DIMM Slots

27 Clear CMOS Jumper (CLRCMOS1)

(DDR3_A1, DDR3_B1, Red)

28 Front Panel IEEE 1394 Header

6 2 x 240-pin DDR3 DIMM Slots

(FRONT_1394, Red)

(DDR3_A2, DDR3_B2, Black)

29 Infrared Module Header (IR1)

7 ATX Power Connector (ATXPWR1)

30 Floppy Connector (FLOPPY1)

8 Primary IDE Connector (IDE1, Black)

31 COM Port Header (COM1)

9 USB 3.0 Header (USB3_6_7, Black)

32 Front Panel Audio Header

10 Intel Z77 Chipset

(HD_AUDIO1, Black)

11 SATA3 Connectors (SATA3_A3_A4, Red)

33 HDMI_SPDIF Header

English

12 SATA3 Connectors (SATA3_A1_A2, Red)

(HDMI_SPDIF1, Black)

13 SATA3 Connectors (SATA3_0_1, Red)

34 PCI Express 2.0 x16 Slot (PCIE5, Red)

14 SATA2 Connectors (SATA2_2_3, Black)

35 PCI Slot (PCI2, Black)

15 SATA2 Connectors (SATA2_4_5, Black)

36 PCI Express 3.0 x16 Slot (PCIE4, Red)

16 Power Switch (PWRBTN)

37 PCI Express 2.0 x1 Slot (PCIE3, Black)

17 Reset Switch (RSTBTN)

38 PCI Slot (PCI1, Black)

18 SPI Flash Memory (64Mb)

39 PCI Express 3.0 x16 Slot (PCIE2, Red)

19 Power LED Header (PLED1)

40 PCI Express 2.0 x1 Slot (PCIE1, Black)

20 Chassis Speaker Header (SPEAKER1, Black)

41 Power Fan Connector (PWR_FAN1)

21 System Panel Header (PANEL1, Black)

42 Internal Audio Connector: CD1 (Black)

22 Chassis Fan Connector (CHA_FAN3)

43 Chassis Fan Connector (CHA_FAN2)

4

Fatal1ty Z77 Professional Series Motherboard

I/O Panel

1 PS/2 Keyboard/Mouse Port (Purple/Green) ** 12 Front Speaker (Lime)

2 DisplayPort (DP1) 13 Microphone (Pink)

3 USB 2.0 Ports (USB01) 14 USB 3.0 Ports (USB3_45)

* 4 LAN RJ-45 Port 15 IEEE 1394 Port

5 Fatal1ty Mouse Port (USB4) *** 16 eSATA3 Port (ESATA_1)

6 USB 2.0 Port (USB5) 17 USB 3.0 Ports (USB3_23)

* 7 LAN RJ-45 Port 18 Clear CMOS Switch (CLRCBTN)

8 Central / Bass (Orange) 19 USB 2.0 Ports (USB23)

9 Rear Speaker (Black) 20 HDMI Port (HDMI1)

10 Optical SPDIF Out Port 21 USB 3.0 Ports (USB3_01)

11 Line In (Light Blue)

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

indications.

LAN Port LED Indications

ACT/LINK

SPEED

LED

LED

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

LAN Port

**

If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”.

See the table below for connection details in accordance with the type of speaker you use.

TABLE for Audio Output Connection

Audio Output Channels Front Speaker Rear Speaker Central / Bass Line in

(No. 12) (No. 9) (No. 8) (No. 11)

English

2 V -- -- --

4 V V -- --

6 V V V --

8 V V V V

5

Fatal1ty Z77 Professional Series Motherboard

To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

panel audio header. After restarting your computer, you will nd “Mixer” tool on your system.

Please select “Mixer ToolBox” , click “Enable playback multi-streaming”, and click

“ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek HDA

Primary output” to use Rear Speaker, Central/Bass, and Front Speaker, or select “Realtek

HDA Audio 2nd output” to use front panel audio.

*** eSATA3 connector supports SATA Gen3 in cable 1M.

English

6

Fatal1ty Z77 Professional Series Motherboard
