Copyright Notice:

No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documentation

by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identica-

tion or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this guide are furnished for informational use

only and subject to change without notice, and should not be constructed as a commit-

ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may

appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or condi-

tions of merchantability or tness for a particular purpose. In no event shall ASRock, its

directors, ofcers, employees, or agents be liable for any indirect, special, incidental, or

consequential damages (including damages for loss of prots, loss of business, loss of

data, interruption of business and the like), even if ASRock has been advised of the pos-

sibility of such damages arising from any defect or error in the guide or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

English

ASRock Website: http://www.asrock.com

Published March 2012

Copyright

©

2012 ASRock INC. All rights reserved.

1

ASRock Q77M vPro Motherboard

Motherboard Layout

1 Power Fan Connector (PWR_FAN1)

19 SATA2 Connector (SATA2_3, Black)

2 ATX 12V Power Connector (ATX12V1)

20 SATA2 Connector (SATA2_5, Black)

3 1155-Pin CPU Socket

21 Power LED Header (PLED1)

4 CPU Fan Connector (CPU_FAN1)

22 System Panel Header (PANEL1, Black)

5 CPU Fan Connector (CPU_FAN2)

23 Clear CMOS Jumper (CLRCMOS1)

6 2 x 240-pin DDR3 DIMM Slots

24 USB 2.0 Header (USB8_9, Black)

(DDR3_A1, DDR3_B1, Black)

25 USB 2.0 Header (USB6_7, Black)

7 2 x 240-pin DDR3 DIMM Slots

26 Consumer Infrared Module Header

(DDR3_A2, DDR3_B2, Black)

(CIR1, Gray)

8 ATX Power Connector (ATXPWR1)

27 TPM Header (TPM1)

9 USB 3.0 Header (USB3_2_3, Black)

28 Infrared Module Header (IR1)

English

10 Intel Q77 Chipset

29 Print Port Header (LPT1)

11 Chassis Fan Connector (CHA_FAN2)

30 COM Port Header (COM1)

12 SPI Flash Memory (64Mb)

31 Front Panel Audio Header

13 Chassis Fan Connector (CHA_FAN1)

(HD_AUDIO1, Black)

14

Chassis Speaker Header (SPEAKER1, Black)

32 PCI Express 2.0 x16 Slot (PCIE2, Black)

15 SATA2 Connector (SATA2_4, Black)

33 PCI Slot (PCI2, Black)

16 SATA2 Connector (SATA2_2, Black)

34 PCI Slot (PCI1, Black)

17 SATA3 Connector (SATA3_0, Gray)

35 PCI Express 3.0 x16 Slot (PCIE1, Black)

18 SATA3 Connector (SATA3_1, Gray)

2

ASRock Q77M vPro Motherboard

I/O Panel

1 USB 2.0 Ports (USB01)

7 USB 2.0 Ports (USB_45)

2 D-Sub Port (VGA1)

8 USB 3.0 Ports (USB3_0_1)

* 3 LAN RJ-45 Port

9 USB 2.0 Ports (USB2_3)

4 Line In (Light Blue)

10 DVI-D Port (DVI1)

** 5 Front Speaker (Lime)

11 DisplayPort (DISPLAY1)

6 Microphone (Pink)

12 PS/2 Keyboard Port (Purple)

* There are two LEDs next to the LAN port. Please refer to the table below for the LAN port LED

indications.

LAN Port LED Indications

ACT/LINK

SPEED

LED

LED

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection

LAN Port

** To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

panel audio header. Please refer to below steps for the software setting of Multi-Streaming.

®

For Windows

XP:

After restarting your computer, you will nd “Mixer” tool on your system. Please select “Mixer

ToolBox” , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH” or

“4CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker

and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio. Then

reboot your system.

English

®

TM

For Windows

7 / Vista

:

After restarting your computer, please double-click “Realtek HD Audio Manager” on the

system tray. Set “Speaker Conguration” to “Quadraphonic” or “Stereo”. Click “Device

advanced settings”, choose “Make front and rear output devices playbacks two different audio

streams simultaneously”, and click “ok”. Then reboot your system.

3

ASRock Q77M vPro Motherboard

1. Introduction

Thank you for purchasing ASRock Q77M vPro motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock Q77M vPro Motherboard

(Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm)

ASRock Q77M vPro Quick Installation Guide

ASRock Q77M vPro Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

®

TM

TM

To get better performance in Windows

7 / 7 64-bit / Vista

/ Vista

64-

bit, it is recommended to set the BIOS option in Storage Conguration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

English

4

ASRock Q77M vPro Motherboard

1.2 Specifications

Platform - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm

- All Solid Capacitor design

rd

nd

®

TM

CPU - Supports 3

and 2

Generation Intel

Core

i7 / i5 / i3 in

LGA1155 Package

- 4 + 2 Power Phase Design

®

- Supports Intel

Turbo Boost 2.0 Technology

®

- Supports Intel

K-Series unlocked CPU (see CAUTION 1)

- Supports Hyper-Threading Technology (see CAUTION 2)

®

Chipset - Intel

Q77

®

TM

- Supports Intel

vPro

Technology (see CAUTION 3)

®

- Supports Intel

Active Management Technology 8.0

(see CAUTION 4)

®

- Supports Intel

Small Business Advantage (see CAUTION 5)

®

- Supports Intel

Rapid Start Technology and Smart Connect

Technology

®

®

TM

* Intel

Small Business Advantage, Intel

vPro

Technology

®

and Intel

Active Management Technology 8.0 can be

®

TM

TM

supported only with Intel

Core

vPro

processor family

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 6)

- 4 x DDR3 DIMM slots

- Supports DDR3 1600/1333/1066 non-ECC, un-buffered

®

memory (DDR3 1600 with Intel

Ivy Bridge CPU, DDR3

®

1333 with Intel

Sandy Bridge CPU)

- Max. capacity of system memory: 32GB (see CAUTION 7)

®

- Supports Intel

Extreme Memory Prole (XMP)1.3/1.2

Expansion Slot - 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)

(see CAUTION 8)

®

* PCIE 3.0 is only supported with Intel

Ivy Bridge CPU. With

®

Intel

Sandy Bridge CPU, it only supports PCIE 2.0.

- 1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode)

- 2 x PCI slots

TM

TM

- Supports AMD Quad CrossFireX

and CrossFireX

®

Graphics * Intel

HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU

English

integrated.

®

®

- Supports Intel

HD Graphics Built-in Visuals: Intel

Quick

®

TM

®

Sync Video 2.0, Intel

InTru

3D, Intel

Clear Video HD

®

TM

®

Technology, Intel

Insider

, Intel

HD Graphics 2500/4000

®

- Pixel Shader 5.0, DirectX 11 with Intel

Ivy Bridge CPU.

5

ASRock Q77M vPro Motherboard

®

Pixel Shader 4.1, DirectX 10.1 with Intel

Sandy Bridge CPU

- Max. shared memory 1760MB (see CAUTION 9)

- Three VGA Output options: D-Sub, DVI-D and DisplayPort

(see CAUTION 10)

- Supports DVI with max. resolution up to 1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

75Hz

- Supports DisplayPort with max. resolution up to 2560x1600

@ 60Hz

- Supports HDCP function with DVI and DisplayPort ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with DVI and DisplayPort ports

Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

TM

- Supports THX TruStudio

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

®

- Intel

82579LM

- Supports Wake-On-LAN

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x DisplayPort

- 6 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

SATA3 - 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and Hot Plug

functions

USB3.0

- 2 x Rear USB 3.0 ports, support USB 1.0/2.0/3.0 up to 5Gb/s

English

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),

supports USB 1.0/2.0/3.0 up to 5Gb/s

Connector - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and Hot Plug

functions

- 2 x SATA3 6.0Gb/s connectors

6

ASRock Q77M vPro Motherboard

- 1 x IR header

- 1 x CIR header

- 1 x Print port header

- 1 x COM port header

- 1 x Power LED header

- 1 x TPM header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage

Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

Multimedia Suite - OEM

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 11)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 12)

- ASRock APP Charger (see CAUTION 13)

- ASRock SmartView (see CAUTION 14)

- ASRock XFast USB (see CAUTION 15)

- ASRock XFast LAN (see CAUTION 16)

- ASRock XFast RAM (see CAUTION 17)

- ASRock Crashless BIOS (see CAUTION 18)

- ASRock OMG (Online Management Guard)

(see CAUTION 19)

- ASRock Internet Flash (see CAUTION 20)

- Hybrid Booster:

- ASRock U-COP (see CAUTION 21)

- Boot Failure Guard (B.F.G.)

English

- Combo Cooler Option (C.C.O.) (see CAUTION 22)

- Good Night LED

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

7

ASRock Q77M vPro Motherboard

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allows Chassis Fan Speed Auto-

Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

®

®

TM

TM

OS - Microsoft

Windows

7 / 7 64-bit / Vista

/ Vista

64-bit /

XP / XP 64-bit compliant (see CAUTION 23)

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 24)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your system. It should be

done at your own risk and expense. We are not responsible for possible damage

caused by overclocking.

CAUTION!

1. Due to chipset limitations, overclocking is not supported.

2. About the settings of “Hyper Threading Technology”, please check page

52 of the “User Manual” in the support CD.

®

TM

3. Intel

vPro

Technology is a set of IT capabilities, including manageabil-

ity, security and power management, all embedded into the hardware of

®

TM

TM

PCs with Intel

Core

vPro

processors. The capabilities are built into

the hardware, so they are available virtually anytime, even if the OS is

inoperable, PC’s power is off, or the hard drive has failed.

®

®

TM

4. Intel

Active Management Technology 8.0 is a feature of Intel

vPro

English

Technology. Using built-in platform capabilities, popular third-party man-

agement and security applications, it allows IT to better discover, heal,

and protect their networked computing assets.

®

5. Intel

Small Business Advantage is a customizable platform integrated

with IT tools, which helps maximize employee productivity, PC perfor-

mance, and data security. There are applications including Software

Monitor, PC Health Center, Data Backup & Restore, Energy Saver and

USB Blocker.

8

ASRock Q77M vPro Motherboard

6. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 16 for proper installation.

7. Due to the operating system limitation, the actual memory size may be

®

less than 4GB for the reservation for system usage under Windows

7 /

TM

®

Vista

/ XP. For Windows

OS with 64-bit CPU, there is no such limita-

tion. You can use ASRock XFast RAM to utilize the memory that Win-

®

dows

cannot use.

8. Only PCIE1 slot supports Gen 3 speed. To run the PCI Express in Gen

3 speed, please install an Ivy Bridge CPU. If you install a Sandy Bridge

CPU, the PCI Express will run only at PCI Express Gen 2 speed.

9. The maximum shared memory size is dened by the chipset vendor and

®

is subject to change. Please check Intel

website for the latest informa-

tion.

10. You can choose to use two of the three monitors only. D-Sub, DVI-D and

DisplayPort cannot be enabled at the same time. Besides, with the DVI-

to-HDMI adapter, the DVI-D port can support the same features as the

HDMI port.

11. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune

different system functions in a user-friendly interface, which includes

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hard-

ware Monitor, it shows the major readings of your system. In Fan Control,

it shows the fan speed and temperature for you to adjust. In Overclock-

ing, you are allowed to overclock CPU frequency for optimal system per-

formance. In OC DNA, you can save your OC settings as a prole and

share it with your friends. Your friends then can load the OC prole to

their own system to get the same OC settings. In IES (Intelligent Energy

Saver), the voltage regulator can reduce the number of output phases to

improve efciency when the CPU cores are idle without sacricing com-

puting performance. Please visit our website for the operation procedures

of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

12. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

®

without entering operating systems rst like MS-DOS or Windows

. With

this utility, you can press the <F6> key during the POST or the <F2>

key to enter into the BIOS setup menu to access ASRock Instant Flash.

Just launch this tool and save the new BIOS le to your USB ash drive,

oppy disk or hard drive, then you can update your BIOS only in a few

clicks without preparing an additional oppy diskette or other complicated

ash utility. Please be noted that the USB ash drive or hard drive must

use FAT32/16/12 le system.

English

13. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful

solution for you - ASRock APP Charger. Simply install the APP Charger

driver, it makes your iPhone charge much quickly from your computer

9

ASRock Q77M vPro Motherboard
