ASRock  H61M-DG3/USB3  Motherboard

English

Copyright Notice:

No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documentation

by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identi

fi

 ca-

tion or explanation and to the owners’ bene

fi

 t, without intent to infringe.

Disclaimer:

Speci

fi

 cations and information contained in this guide are furnished for informational use

only and subject to change without notice, and should not be constructed as a commit-

ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may

appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or condi-

tions of merchantability or

fi

 tness for a particular purpose. In no event shall ASRock, its

directors, of

fi

 cers, employees, or agents be liable for any indirect, special, incidental, or

consequential damages (including damages for loss of pro

fi

 ts, loss of business, loss of

data, interruption of business and the like), even if ASRock has been advised of the pos-

sibility of such damages arising from any defect or error in the guide or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1)  this device may not cause harmful interference, and

(2)  this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Published September 2012

Copyright

©

2012 ASRock INC. All rights reserved.

2

ASRock  H61M-DG3/USB3  Motherboard

Motherboard Layout

English

 1

ATX  12V  Power  Connector  (ATX12V1)

13

Chassis  Speaker  Header  (SPEAKER1)

 2

1155-Pin  CPU  Socket

14

System  Panel  Header  (PANEL1)

 3

CPU  Fan  Connector  (CPU_FAN1)

15

USB 2.0  Header  (USB6_7)

 4

ATX  Power  Connector  (ATXPWR1)

16

USB 2.0  Header  (USB8_9)

 5

2 x 240-pin  DDR3  DIMM  Slots

17

COM  Port  Header  (COM1)

(Dual Channel: DDR3_A1, DDR3_B1)

18

Print  Port  Header  (LPT1)

 6

Intel  H61  Chipset

19

Front  Panel  Audio  Header  (HD_AUDIO1)

 7

32Mb  SPI  Flash

20

PCI  Express  2.0  x1  Slot  (PCIE2)

 8

SATA2  Connector  (SATA2_1)

21

Clear  CMOS  Jumper  (CLRCMOS1)

 9

Chassis  Fan  Connector  (CHA_FAN1)

22

Chassis  Intrusion  Header  (CI1)

10

SATA2  Connector  (SATA2_0)

23

PCI  Express  2.0  x16  Slot  (PCIE1)

11

SATA2  Connector  (SATA2_3)

24

USB 3.0  Header  (USB3_2_3)

12

SATA2  Connector  (SATA2_2)

25

Power  Fan  Connector  (PWR_FAN1)

A

T

XPWR1

DDR3_A1

(64

b

it,

2

40-pin

module)

DDR3_B1

(64

bit,

240-pin

module)

CPU_FAN1

Intel

H61

CMOS

Battery

17.3cm (6.8 in)

22.6cm

(8.9

in)

ErP/EuP

Ready

D

DR3

Front

USB

3.0

32Mb

BIOS

Super

I/O

CHA_FAN1

PWR_FAN1

1

SPEAKER1

PCIE1

PCIE2

1

HD_AUDIO1

COM1

1

1

LPT1

CLRCMOS1

1

HDLED RESET

PLED PWRBTN

PANEL1

1

LAN

PHY

AUDIO

CODEC

USB6_7

1

USB8_9

1

SATA2_2

SATA2_0

SATA2_3

SATA2_1

ATX12V1

PS2

Keyboard

PS2

Mouse

VGA1

Top:

RJ-45

USB 2.0

T: USB4

B: USB5

USB 2.0

T: USB0

B: USB1

T

op:

LINE

IN

Center:

FRONT

Bottom:

MIC

IN

USB 3.0

T: USB0

B: USB1

1

2

3

4

5

6

7

9

10

11

12

8

14 13

15

16

17

18

19

20

21

22

24

RoHS

DVI1

X

Fast

LAN

X

Fast USB

X

Fast RAM

H61M-DG3/USB3

USB3_2_3

1

CI1

23

25

3

ASRock  H61M-DG3/USB3  Motherboard

English

I/O Panel

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

   indications.

LAN Port LED Indications

       Activity/Link LED

SPEED LED

Status        Description            Status           Description

Off           No Link                Off             10Mbps connection

Blinking   Data Activity        Orange      100Mbps connection

On           Link

         Green        1Gbps connection

1

PS/2  Mouse  Port  (Green)

 7

USB 3.0  Ports  (USB3_0_1)

      * 2

LAN  RJ-45  Port                                                         8

USB 2.0  Ports  (USB01)

3

Line  In  (Light  Blue)

 9

DVI-D  Port  (DVI1)

     ** 4

Front  Speaker  (Lime)

10  D-Sub  Port  (VGA1)

5

Microphone  (Pink)

11  PS/2  Keyboard  Port  (Purple)

6

USB 2.0  Ports  (USB45)

LAN Port

ACT/LINK

    LED

SPEED

  LED

6

8

11

1

2

4

3

5

7

9

10

** To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

    panel audio header. Please refer to below steps for the software setting of Multi-Streaming.

    For Windows

®

 XP:

    After restarting your computer, you will

fi

 nd “Mixer” tool on your system. Please select “Mixer

    ToolBox”                , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH” or

    “4CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker

    and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio. Then

    reboot your system.

    For Windows

®

 7 / Vista

TM

:

    After restarting your computer, please double-click “Realtek HD Audio Manager” on the

    system tray. Set “Speaker Con

fi

 guration” to “Quadraphonic” or “Stereo”. Click “Device

    advanced settings”, choose “Make front and rear output devices playbacks two different audio

    streams simultaneously”, and click “ok”. Then reboot your system.
