ASRock  H61M-DG3/USB3  Motherboard

English

1. Introduction

Thank you for purchasing ASRock

H61M-DG3/USB3

motherboard, a reliable moth-

erboard produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may

fi

 nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock

H61M-DG3/USB3

 Motherboard

(Micro ATX Form Factor: 8.9-in x 6.8-in, 22.6 cm x 17.3 cm)

ASRock

H61M-DG3/USB3

 Quick Installation Guide

ASRock

H61M-DG3/USB3

 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-

bit, it is recommended to set the BIOS option in Storage Con

fi

 guration to

AHCI mode.

5

ASRock  H61M-DG3/USB3  Motherboard

English

1.2 Speci

fi

 cations

 Platform

- Micro ATX Form Factor: 8.9-in x 6.8-in, 22.6 cm x 17.3 cm

- All Solid Capacitor design

 CPU

- Supports 2nd Generation Intel

®

 Core

TM

 i7 / i5 / i3 in

  LGA1155 Package

- Supports Intel

®

 Turbo Boost 2.0 Technology

- Supports K-Series unlocked CPU

 Chipset

- Intel

®

 H61

- Supports Intel

®

 Rapid Start Technology and Smart Connect

Technology

 Memory

- Dual Channel DDR3 Memory Technology

- 2 x DDR3 DIMM slots

- Supports DDR3 1600/1333/1066 non-ECC, un-buffered

  memory (DDR3 1600 with Intel

®

 Ivy Bridge CPU,

  DDR3 1333 with Intel

®

 Sandy Bridge CPU)

- Max. capacity of system memory: 16GB (see

CAUTION 1

)

- Supports Intel

®

 Extreme Memory Pro

fi

 le (XMP) 1.3 / 1.2 with

  Intel

®

 Ivy Bridge CPU

 Expansion Slot

- 1 x PCI Express 3.0 x16 slot

  * PCIE 3.0 is only supported with Intel

®

 Ivy Bridge CPU. With

    Intel

®

 Sandy Bridge CPU, it only supports PCIE 2.0.

- 1 x PCI Express 2.0 x1 slot

 Graphics

 *

Intel

®

 HD Graphics Built-in Visuals and the VGA outputs

  can be supported only with processors which are GPU

  integrated.

- Supports Intel

®

 HD Graphics Built-in Visuals: Intel

®

 Quick

  Sync Video 2.0, Intel

®

 InTru

TM

 3D, Intel

®

 Clear Video HD

  Technology, Intel

®

 Insider

TM

, Intel

®

 HD Graphics 2500/4000

  with Intel

®

 Ivy Bridge CPU

- Supports Intel

®

 HD Graphics Built-in Visuals: Intel

®

 Quick

  Sync Video, Intel

®

 InTru

TM

 3D, Intel

®

 Clear Video HD

  Technology, Intel

®

 HD Graphics 2000/3000, Intel

®

 Advanced

  Vector Extensions (AVX) with Intel

®

 Sandy Bridge CPU

- Pixel Shader 5.0, DirectX 11 with Intel

®

 Ivy Bridge CPU.

  Pixel Shader 4.1, DirectX 10.1 with Intel

®

 Sandy Bridge

  CPU.

- Max. shared memory 1760MB with Intel

®

 Ivy Bridge CPU.

  Max. shared memory 1759MB with Intel

®

 Sandy Bridge

  CPU.

6

ASRock  H61M-DG3/USB3  Motherboard

English

- Dual VGA Output: support DVI-D and D-Sub ports by

  independent display controllers

- Supports DVI with max. resolution up to 1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

  75Hz

- Supports HDCP function with DVI port

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

  with DVI port

 Audio

- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

 LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 4 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

 USB 3.0

- 2 x Rear USB 3.0 ports by Etron EJ188H, support

  USB 1.1/2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header by Etron EJ188H (supports 2

  USB 3.0 ports), supports USB 1.1/2.0/3.0 up to 5Gb/s

Connector

- 4 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

  Hot Plug functions

- 1 x Print Port header

- 1 x COM port header

- 1 x Chassis Intrusion header

- 1 x CPU Fan connector (4-pin)

- 1 x Chassis Fan connector (4-pin)

- 1 x Power Fan connector (3-pin)

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

7

ASRock  H61M-DG3/USB3  Motherboard

English

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS Feature

- 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- IGPU, DRAM, PCH, CPU PLL, VTT, VCCSA Voltage

  Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

  Multimedia Suite - OEM

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed

  Auto-Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- CASE OPEN detection

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-bit

  / XP / XP 64-bit compliant (see

CAUTION 2

)

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

 * For detailed product information, please visit our website: http://www.asrock.com

 WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

 overclocking.

8

ASRock  H61M-DG3/USB3  Motherboard

English

CAUTION!

1.  Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage

under Windows

®

 7 / Vista

TM

 / XP. For Windows

®

 OS with 64-bit

CPU, there is no such limitation. You can use ASRock XFast

RAM to utilize the memory that Win

dows

®

 cannot use.

2.  ASRock XFast RAM is not supported by Microsoft

®

 Windows

®

XP / XP 64-bit.

9

ASRock  H61M-DG3/USB3  Motherboard

English

1.3  Unique Features

ASRock Extreme Tuning Utility (AXTU)

ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to

ne-tune different system functions in a user-friendly interface,

which includes Hardware Monitor, Fan Control, Overclocking,

OC DNA, IES and XFast RAM. In Hardware Monitor, it shows

the major readings of your system. In Fan Control, it shows the

fan speed and temperature for you to adjust. In Overclocking,

you are allowed to overclock CPU frequency for optimal system

performance. In OC DNA, you can save your OC settings as

a pro

fi

 le and share it with your friends. Your friends then can

load the OC pro

fi

 le to their own system to get the same OC set-

tings. In IES (Intelligent Energy Saver), the voltage regulator

can reduce the number of output phases to improve ef

fi

 ciency

when the CPU cores are idle without sacri

fi

 cing computing per-

formance. In XFast RAM, it fully utilizes the memory space that

cannot be used under Windows

®

 OS 32-bit CPU.

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more ef

fi

 cient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows

®

to shorten boot up time. By calling S3 and S4 at speci

fi

 c timing

during the shutdown and startup process, Instant Boot allows

you to enter your Windows

®

 desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS

fl

 ash utility embedded in Flash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems

fi

 rst like MS-

DOS or Windows

®

. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

save the new BIOS

fi

 le to your USB

fl

 ash  drive,

fl

 oppy disk or

hard drive, then you can update your BIOS only in a few clicks

without preparing an additional

fl

 oppy diskette or other compli-

cated

fl

 ash utility. Please be noted that the USB

fl

 ash drive or

hard drive must use FAT32/16/12

fi

 le system.

10

ASRock  H61M-DG3/USB3  Motherboard

English

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock has

prepared a wonderful solution for you - ASRock APP Charger.

Simply install the APP Charger driver, it makes your iPhone

charge much quickly from your computer and up to 40% faster

than before. ASRock APP Charger allows you to quickly charge

many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1),

Suspend to RAM (S3), hibernation mode (S4) or power off (S5).

With APP Charger driver installed, you can easily enjoy the mar-

velous charging experience.

ASRock XFast USB

ASRock XFast USB can boost USB storage device perfor-

mance. The performance may depend on the properties of the

device.

ASRock XFast LAN

ASRock XFast LAN provides a faster internet access, which

includes the benefits listed below. LAN Application Prioritiza-

tion: You can con

fi

 gure your application’s priority ideally and/or

add new programs. Lower Latency in Game: After setting online

game’s priority higher, it can lower the latency in games. Traf

fi

 c

Shaping: You can watch Youtube HD videos and download si-

multaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are

transferring currently.

ASRock XFast RAM

ASRock XFast RAM is a new function that is included into AS-

Rock Extreme Tuning Utility (AXTU). It fully utilizes the memory

space that cannot be used under Windows

®

 OS 32-bit CPU.

ASRock XFast RAM shortens the loading time of previously

visited websites, making web surfing faster than ever. And it

also boosts the speed of Adobe Photoshop 5 times faster. An-

other advantage of ASRock XFast RAM is that it reduces the

frequency of accessing your SSDs or HDDs in order to extend

their lifespan.

English

11

ASRock  H61M-DG3/USB3  Motherboard

English

ASRock Crashless BIOS

ASRock Crashless BIOS allows users to update their BIOS

without fear of failing. If power loss occurs during the BIOS up-

date process, ASRock Crashless BIOS will automatically

fi

 nish

the BIOS update procedure after regaining power. Please note

that BIOS

fi

 les need to be placed in the root directory of your

USB disk. Only USB2.0 ports support this feature.

ASRock OMG (Online Management Guard)

Administrators are able to establish an internet curfew or restrict

internet access at speci

fi

 ed times via OMG. You may schedule

the starting and ending hours of internet access granted to other

users. In order to prevent users from bypassing OMG, guest

accounts without permission to modify the system time are re-

quired.

ASRock Internet Flash

ASRock Internet Flash searches for available UEFI firmware

updates from our servers. In other words, the system can auto-

detect the latest UEFI from our servers and

fl

 ash them without

entering Windows

®

 OS. Please note that you must be running

on a DHCP con

fi

 gured computer in order to enable this function.

ASRock Fast Boot

With ASRock’s exclusive Fast Boot technology, it takes less

than 1.5 seconds to logon to Windows 8 from a cold boot. No

more waiting! The speedy boot will completely change your user

experience and behavior.

ASRock Combo Cooler Option (C.C.O.)

Combo Cooler Option (C.C.O.) provides the

fl

 exible option to

adopt three different CPU cooler types, Socket LGA 775, LGA

1155 and LGA 1156. Please be noticed that not all the 775 and

1156 CPU Fan can be used.
