Инструкция к Материнской Плате ASRock B75 Pro3-M
Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documentation
by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identica-
tion or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specications and information contained in this guide are furnished for informational use
only and subject to change without notice, and should not be constructed as a commit-
ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may
appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or condi-
tions of merchantability or tness for a particular purpose. In no event shall ASRock, its
directors, ofcers, employees, or agents be liable for any indirect, special, incidental, or
consequential damages (including damages for loss of prots, loss of business, loss of
data, interruption of business and the like), even if ASRock has been advised of the pos-
sibility of such damages arising from any defect or error in the guide or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
English
ASRock Website: http://www.asrock.com
Published June 2013
Copyright
©
2013 ASRock INC. All rights reserved.
1
ASRock B75 Pro3-M Motherboard
Motherboard Layout
1 Power Fan Connector (PWR_FAN1)
19
Chassis Speaker Header (SPEAKER1, Black)
2 ATX 12V Power Connector (ATX12V1)
20 System Panel Header (PANEL1, Black)
3 1155-Pin CPU Socket
21 SATA2 Connector (SATA2_3, Black)
4 CPU Fan Connector (CPU_FAN1)
22 USB 2.0 Header (USB10_11, Black)
5 CPU Fan Connector (CPU_FAN2)
23 SATA2 Connector (SATA2_1, Black)
6 2 x 240-pin DDR3 DIMM Slots
24 Consumer Infrared Module Header
(DDR3_A1, DDR3_B1, Black)
(CIR1, Gray)
7 2 x 240-pin DDR3 DIMM Slots
25 USB 2.0 Header (USB8_9, Black)
(DDR3_A2, DDR3_B2, Black)
26 Clear CMOS Jumper (CLRCMOS1)
8 ATX Power Connector (ATXPWR1)
27 Infrared Module Header (IR1)
9 SATA3 Connector (SATA3_A1, Gray)
28 Print Port Header (LPT1)
English
10 SATA3 Connector (SATA3_A0, Gray)
29 COM Port Header (COM1)
11 USB 3.0 Header (USB3_2_3, Black)
30 HDMI_SPDIF Header (HDMI_SPDIF1, Black)
12 Intel B75 Chipset
31 Front Panel Audio Header
13 SPI Flash Memory (64Mb)
(HD_AUDIO1, Black)
14 SATA3 Connector (SATA3_0, Gray)
32 PCI Express 2.0 x16 Slot (PCIE2, Black)
15 SATA2 Connector (SATA2_2, Black)
33 PCI Slot (PCI2, Black)
16 SATA2 Connector (SATA2_4, Black)
34 PCI Slot (PCI1, Black)
17 SATA2 Connector (SATA2_5, Black)
35 PCI Express 3.0 x16 Slot (PCIE1, Black)
18 Chassis Fan Connector (CHA_FAN1)
2
ASRock B75 Pro3-M Motherboard
I/O Panel
1 USB 2.0 Ports (USB01)
8 Microphone (Pink)
2 D-Sub Port (VGA1)
9 Optical SPDIF Out Port
* 3 LAN RJ-45 Port
10 USB 2.0 Ports (USB45)
4 Central / Bass (Orange)
11 USB 3.0 Ports (USB3_01)
5 Rear Speaker (Black)
12 HDMI Port (HDMI1)
6 Line In (Light Blue)
13 DVI-D Port (DVI1)
** 7 Front Speaker (Lime)
14 PS/2 Keyboard Port (Purple)
* There is one LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
LAN Port LED Indications
ACT/LINK
SPEED
LED
LED
Activity/Link LED SPEED LED
Status Description Status Description
Off No Link Off 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
LAN Port
**
If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”.
See the table below for connection details in accordance with the type of speaker you use.
TABLE for Audio Output Connection
Audio Output Channels Front Speaker Rear Speaker Central / Bass Line in
(No. 7) (No. 5) (No. 4) (No. 6)
English
2 V -- -- --
4 V V -- --
6 V V V --
8 V V V V
3
ASRock B75 Pro3-M Motherboard
To enable Multi-Streaming function, you need to connect a front panel audio cable to the front
panel audio header. After restarting your computer, you will nd “Mixer” tool on your system.
Please select “Mixer ToolBox” , click “Enable playback multi-streaming”, and click
“ok”. Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek HDA
Primary output” to use Rear Speaker, Central/Bass, and Front Speaker, or select “Realtek HDA
Audio 2nd output” to use front panel audio.
English
4
ASRock B75 Pro3-M Motherboard
1. Introduction
Thank you for purchasing ASRock B75 Pro3-M motherboard, a reliable mother-
board produced under ASRock’s consistently stringent quality control. It delivers
excellent performance with robust design conforming to ASRock’s commitment to
quality and endurance.
This Quick Installation Guide contains introduction of the motherboard and step-by-
step installation guide. More detailed information of the motherboard can be found
in the user manual presented in the Support CD.
Because the motherboard specications and the BIOS software might be
updated, the content of this manual will be subject to change without no-
tice. In case any modications of this manual occur, the updated version
will be available on ASRock website without further notice. You may nd
the latest VGA cards and CPU support lists on ASRock website as well.
ASRock website http://www.asrock.com
If you require technical support related to this motherboard, please visit
our website for specic information about the model you are using.
www.asrock.com/support/index.asp
1.1 Package Contents
ASRock B75 Pro3-M Motherboard
(Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm)
ASRock B75 Pro3-M Quick Installation Guide
ASRock B75 Pro3-M Support CD
2 x Serial ATA (SATA) Data Cables (Optional)
1 x I/O Panel Shield
ASRock Reminds You...
®
TM
TM
To get better performance in Windows
7 / 7 64-bit / Vista
/ Vista
64-
bit, it is recommended to set the BIOS option in Storage Conguration to
AHCI mode. For the BIOS setup, please refer to the “User Manual” in our
support CD for details.
English
5
ASRock B75 Pro3-M Motherboard
1.2 Specifications
Platform - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
- All Solid Capacitor design
rd
nd
®
TM
CPU - Supports 3
and 2
Generation Intel
Core
i7 / i5 / i3 in
LGA1155 Package
- 4 + 2 Power Phase Design
®
- Supports Intel
Turbo Boost 2.0 Technology
®
- Supports Intel
K-Series unlocked CPU (see CAUTION 1)
- Supports Hyper-Threading Technology (see CAUTION 2)
®
- Supports Intel
Rapid Start Technology and Smart Connect
®
Technology with Intel
Ivy Bridge CPU
®
Chipset - Intel
B75
®
- Supports Intel
Small Business Advantage (see CAUTION 3)
Memory - Dual Channel DDR3 Memory Technology (see CAUTION 4)
- 4 x DDR3 DIMM slots
- Supports DDR3 1600/1333/1066 non-ECC, un-buffered
®
memory (DDR3 1600 with Intel
Ivy Bridge CPU, DDR3
®
1333 with Intel
Sandy Bridge CPU)
- Max. capacity of system memory: 32GB (see CAUTION 5)
®
- Supports Intel
Extreme Memory Prole (XMP)1.3/1.2
Expansion Slot - 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)
(see CAUTION 6)
®
* PCIE 3.0 is only supported with Intel
Ivy Bridge CPU. With
®
Intel
Sandy Bridge CPU, it only supports PCIE 2.0.
- 1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode)
- 2 x PCI slots
TM
TM
- Supports AMD Quad CrossFireX
and CrossFireX
®
Graphics * Intel
HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU
integrated.
®
®
- Supports Intel
HD Graphics Built-in Visuals: Intel
Quick
®
TM
®
Sync Video 2.0, Intel
InTru
3D, Intel
Clear Video HD
®
TM
®
English
Technology, Intel
Insider
, Intel
HD Graphics 2500/4000
®
- Pixel Shader 5.0, DirectX 11 with Intel
Ivy Bridge CPU.
®
Pixel Shader 4.1, DirectX 10.1 with Intel
Sandy Bridge CPU
- Max. shared memory 1760MB (see CAUTION 7)
- Three VGA Output options: D-Sub, DVI-D and HDMI
(see CAUTION 8)
- Supports HDMI 1.4a Technology with max. resolution up to
1920x1200 @ 60Hz
6
ASRock B75 Pro3-M Motherboard
- Supports DVI with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @
75Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required) (see CAUTION 9)
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with DVI and HDMI ports
Audio - 7.1 CH HD Audio with Content Protection
(Realtek ALC892 Audio Codec)
- Premium Blu-ray audio support
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efcient Ethernet 802.3az
- Supports PXE
Rear Panel I/O I/O Panel
- 1 x PS/2 Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 4 x Ready-to-Use USB 2.0 Ports
- 2 x Ready-to-Use USB 3.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front
Speaker/Microphone (see CAUTION 10)
®
SATA3 - 1 x SATA3 6.0 Gb/s connector by Intel
B75, supports NCQ,
AHCI and Hot Plug functions
- 2 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061,
support NCQ, AHCI and Hot Plug functions
USB3.0
- 2 x Rear USB 3.0 ports, support USB 1.0/2.0/3.0 up to 5Gb/s
- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),
supports USB 1.0/2.0/3.0 up to 5Gb/s
English
Connector - 5 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug functions
- 3 x SATA3 6.0Gb/s connectors
7
ASRock B75 Pro3-M Motherboard
- 1 x IR header
- 1 x CIR header
- 1 x Print port header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 1 x USB 3.0 header (supports 2 USB 3.0 ports)
BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support
- Supports “Plug and Play”
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage
Multi-adjustment
Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),
CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX
Multimedia Suite - OEM
Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 11)
- ASRock Instant Boot
- ASRock Instant Flash (see CAUTION 12)
- ASRock APP Charger (see CAUTION 13)
- ASRock SmartView (see CAUTION 14)
- ASRock XFast USB (see CAUTION 15)
- ASRock XFast LAN (see CAUTION 16)
- ASRock XFast RAM (see CAUTION 17)
- ASRock Crashless BIOS (see CAUTION 18)
- ASRock On/Off Play Technology (see CAUTION 19)
- ASRock OMG (Online Management Guard)
(see CAUTION 20)
- ASRock Internet Flash (see CAUTION 21)
English
- Hybrid Booster:
- ASRock U-COP (see CAUTION 22)
- Boot Failure Guard (B.F.G.)
- Combo Cooler Option (C.C.O.) (see CAUTION 23)
- Good Night LED
Hardware - CPU Temperature Sensing
Monitor - Chassis Temperature Sensing
8
ASRock B75 Pro3-M Motherboard
- CPU/Chassis/Power Fan Tachometer
- CPU/Chassis Quiet Fan (Allows Chassis Fan Speed Auto-
Adjust by CPU Temperature)
- CPU/Chassis Fan Multi-Speed Control
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
®
®
TM
TM
OS - Microsoft
Windows
7 / 7 64-bit / Vista
/ Vista
64-bit /
XP / XP 64-bit compliant (see CAUTION 24)
Certications - FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
(see CAUTION 25)
* For detailed product information, please visit our website: http://www.asrock.com
WARNING
Please realize that there is a certain risk involved with overclocking, including
adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using
third-party overclocking tools. Overclocking may affect your system’s stability, or
even cause damage to the components and devices of your system. It should be
done at your own risk and expense. We are not responsible for possible damage
caused by overclocking.
CAUTION!
1. Due to chipset limitations, overclocking is not supported.
2. About the settings of “Hyper Threading Technology”, please check page
50 of the “User Manual” in the support CD.
®
3. Intel
Small Business Advantage is a customizable platform integrated
with IT tools, which helps maximize employee productivity, PC perfor-
mance, and data security. There are applications including Software
Monitor, PC Health Center, Data Backup & Restore, Energy Saver and
USB Blocker.
4. This motherboard supports Dual Channel Memory Technology. Before
you implement Dual Channel Memory Technology, make sure to read the
installation guide of memory modules on page 17 for proper installation.
5. Due to the operating system limitation, the actual memory size may be
English
®
less than 4GB for the reservation for system usage under Windows
7 /
TM
®
Vista
/ XP. For Windows
OS with 64-bit CPU, there is no such limita-
tion. You can use ASRock XFast RAM to utilize the memory that Win-
®
dows
cannot use.
9
ASRock B75 Pro3-M Motherboard
6. Only PCIE1 slot supports Gen 3 speed. To run the PCI Express in Gen
3 speed, please install an Ivy Bridge CPU. If you install a Sandy Bridge
CPU, the PCI Express will run only at PCI Express Gen 2 speed.
7. The maximum shared memory size is dened by the chipset vendor and
®
is subject to change. Please check Intel
website for the latest informa-
tion.
8. You can choose to use two of the three monitors only. D-Sub, DVI-D and
HDMI monitors cannot be enabled at the same time. Besides, with the
DVI-to-HDMI adapter, the DVI-D port can support the same features as
the HDMI port.
®
9. xvYCC and Deep Color are only supported under Windows
7 64-bit / 7.
Deep Color mode will be enabled only if the display supports 12bpc in
®
TM
EDID. HBR audio is supported under Windows
7 64-bit / 7 / Vista
64-
TM
bit / Vista
.
10. For microphone input, this motherboard supports both stereo and mono
modes. For audio output, this motherboard supports 2-channel, 4-chan-
nel, 6-channel, and 8-channel modes. Please check the table on page 3
for proper connection.
11. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune
different system functions in a user-friendly interface, which includes
Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hard-
ware Monitor, it shows the major readings of your system. In Fan Control,
it shows the fan speed and temperature for you to adjust. In Overclock-
ing, you are allowed to overclock CPU frequency for optimal system per-
formance. In OC DNA, you can save your OC settings as a prole and
share it with your friends. Your friends then can load the OC prole to
their own system to get the same OC settings. In IES (Intelligent Energy
Saver), the voltage regulator can reduce the number of output phases to
improve efciency when the CPU cores are idle without sacricing com-
puting performance. Please visit our website for the operation procedures
of ASRock Extreme Tuning Utility (AXTU).
ASRock website: http://www.asrock.com
12. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.
This convenient BIOS update tool allows you to update system BIOS
®
without entering operating systems rst like MS-DOS or Windows
. With
this utility, you can press the <F6> key during the POST or the <F2>
key to enter into the BIOS setup menu to access ASRock Instant Flash.
Just launch this tool and save the new BIOS le to your USB ash drive,
English
oppy disk or hard drive, then you can update your BIOS only in a few
clicks without preparing an additional oppy diskette or other complicated
ash utility. Please be noted that the USB ash drive or hard drive must
use FAT32/16/12 le system.
13. If you desire a faster, less restricted way of charging your Apple devices,
such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful
solution for you - ASRock APP Charger. Simply install the APP Charger
driver, it makes your iPhone charge much quickly from your computer
10
ASRock B75 Pro3-M Motherboard
and up to 40% faster than before. ASRock APP Charger allows you to
quickly charge many Apple devices simultaneously and even supports
continuous charging when your PC enters into Standby mode (S1), Sus-
pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP
Charger driver installed, you can easily enjoy the marvelous charging
experience.
ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp
14. ASRock SmartView, a new function for internet browsers, is the smart
start page for IE that combines your most visited web sites, your history,
your Facebook friends and your real-time newsfeed into an enhanced
view for a more personal Internet experience. ASRock motherboards are
exclusively equipped with the ASRock SmartView utility that helps you
keep in touch with friends on-the-go. To use ASRock SmartView feature,
®
TM
please make sure your OS version is Windows
7 / 7 64 bit / Vista
/
TM
Vista
64 bit, and your browser version is IE8.
ASRock website: http://www.asrock.com/Feature/SmartView/index.asp
15. ASRock XFast USB can boost USB storage device performance. The
performance may depend on the properties of the device.
16. ASRock XFast LAN provides a faster internet access, which includes
the benets listed below. LAN Application Prioritization: You can cong-
ure your application’s priority ideally and/or add new programs. Lower
Latency in Game: After setting online game’s priority higher, it can lower
the latency in games. Trafc Shaping: You can watch Youtube HD videos
and download simultaneously. Real-Time Analysis of Your Data: With
the status window, you can easily recognize which data streams you are
transferring currently.
17. ASRock XFast RAM is a new function that is included into ASRock Ex-
treme Tuning Utility (AXTU). It fully utilizes the memory space that cannot
®
be used under Windows
32-bit OS. ASRock XFast RAM shortens the
loading time of previously visited websites, making web surfing faster
than ever. And it also boosts the speed of Adobe Photoshop 5 times
faster. Another advantage of ASRock XFast RAM is that it reduces the
frequency of accessing your SSDs or HDDs in order to extend their lifes-
pan.
18. ASRock Crashless BIOS allows users to update their BIOS without fear
of failing. If power loss occurs during the BIOS update process, ASRock
Crashless BIOS will automatically nish the BIOS update procedure after
regaining power. Please note that BIOS les need to be placed in the
root directory of your USB disk. Only USB2.0 ports support this feature.
19. ASRock On/Off Play Technology allows users to enjoy the great audio
experience from portable audio devices, such as MP3 players or mobile
phones to your PC, even when the PC is turned off (or in ACPI S5 mode)!
English
This motherboard also provides a free 3.5mm audio cable (optional) that
ensures users the most convenient computing environment.
20. Administrators are able to establish an internet curfew or restrict internet
access at specied times via OMG. You may choose from [Everyday], [Day
11
ASRock B75 Pro3-M Motherboard
of the week] or [Weekdays and weekends], then schedule the starting
and ending hours of internet access granted to other users. In order to
prevent users from bypassing OMG, guest accounts without permission
to modify the system time are required.
21. Internet Flash searches for available UEFI rmware updates from our
servers. In other words, the system can auto-detect the latest UEFI from
our servers and ash them without entering Windows OS. Please note
that you must be running on a DHCP congured computer in order to en-
able this function.
22. While CPU overheat is detected, the system will automatically shutdown.
Before you resume the system, please check if the CPU fan on the moth-
erboard functions properly and unplug the power cord, then plug it back
again. To improve heat dissipation, remember to spray thermal grease
between the CPU and the heatsink when you install the PC system.
23. Combo Cooler Option (C.C.O.) provides the exible option to adopt three
different CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156.
Please be noticed that not all the 775 and 1156 CPU Fan can be used.
®
®
24. ASRock XFast RAM is not supported by Microsoft
Windows
XP / XP
®
®
64-bit. Intel
Smart Connect Technology and Intel
USB 3.0 ports are not
®
®
TM
TM
supported by Microsoft
Windows
Vista
/ Vista
64-bit / XP / XP 64-
bit.
25. EuP stands for Energy Using Product, was a provision regulated by the
European Union to define the power consumption for the completed
system. According to EuP, the total AC power of the completed system
should be under 1.00W in off mode condition. To meet EuP standards,
an EuP ready motherboard and an EuP ready power supply are required.
According to Intel’s suggestion, the EuP ready power supply must meet
the standard of 5v, and the standby power efciency should be higher
than 50% under 100 mA current consumption. For EuP ready power sup-
ply selection, we recommend you to check with the power supply manu-
facturer for more details.
English
12
ASRock B75 Pro3-M Motherboard
Оглавление
- 1. Introduction
- Chapter 2: Installation
- 3. BIOS Information
- 1. Einführung
- 2. BIOS-Information
- 1. Introduction
- 2. Informations sur le BIOS
- 1. Introduzione
- 2. Informazioni sul BIOS
- 1. Introducción
- 2. BIOS Información
- 1. Введение
- 2. Информация о BIOS
- 1. Introdução
- 2. Informações da BIOS
- 1. Giriş
- 2. BIOS Bilgileri
- 1. 제품소개
- 2. 시스템 바이오스 정보
- 1. 主板簡介
- 2. BIOS 信息
- 1. 主機板簡介
- 2. BIOS 訊息
- 1. Penjelasan
- Installing OS on a HDD Larger Than 2TB
