Copyright Notice:

No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documentation

by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identica-

tion or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this guide are furnished for informational use

only and subject to change without notice, and should not be constructed as a commit-

ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may

appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or condi-

tions of merchantability or tness for a particular purpose. In no event shall ASRock, its

directors, ofcers, employees, or agents be liable for any indirect, special, incidental, or

consequential damages (including damages for loss of prots, loss of business, loss of

data, interruption of business and the like), even if ASRock has been advised of the pos-

sibility of such damages arising from any defect or error in the guide or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

English

ASRock Website: http://www.asrock.com

Published July 2013

Copyright

©

2013 ASRock INC. All rights reserved.

1

ASRock FM2A75 Pro4-M Motherboard

Motherboard Layout

2

ASRock FM2A75 Pro4-M Motherboard

1 Power Fan Connector (PWR_FAN1)

18 SATA3 Connector (SATA3_3, Grey)

2

ATX 12V Power Connector (ATX12V1)

19

Chassis Speaker Header (SPEAKER1)

3 CPU Heatsink Retention Module

20 Power LED Header (PLED1)

4 CPU Socket

21 System Panel Header (PANEL1)

5 CPU Fan Connector (CPU_FAN1)

22 USB 2.0 Header (USB5_6, Black)

6 CPU Fan Connector (CPU_FAN2)

23 Clear CMOS Jumper (CLRCMOS1)

7 2 x 240-pin DDR3 DIMM Slots

24 USB 2.0 Header (USB7_8, Black)

(DDR3_A1, DDR3_B1, Black)

25 Consumer Infrared Module Header

8 2 x 240-pin DDR3 DIMM Slots

(CIR1, Gray)

(DDR3_A2, DDR3_B2, Black)

26 USB 2.0 Header (USB9_10, Black)

9 ATX Power Connector (ATXPWR1)

27 Print Port Header (LPT1)

English

10 USB 3.0 Header (USB3_3_4, Black)

28 COM Port Header (COM1)

11 Southbridge Controller

29 Infrared Module Header (IR1)

12

Chassis Fan Connector (CHA_FAN1)

30

Front Panel Audio Header (HD_AUDIO1)

13 SPI Flash Memory (64Mb)

31 PCI Slot (PCI1)

14 SATA3 Connector (SATA3_5, Grey)

32 PCI Express 2.0 x16 Slot (PCIE3)

15 SATA3 Connector (SATA3_4, Grey)

33 Chassis Intrusion Header (CI1)

16 SATA3 Connector (SATA3_1, Grey)

34 PCI Express 2.0 x1 Slot (PCIE2)

17 SATA3 Connector (SATA3_2, Grey)

35 PCI Express 2.0 x16 Slot (PCIE1)

I/O Panel

1

2

3

4

5

8

6

9

7

3

ASRock FM2A75 Pro4-M Motherboard

15

14

13

12

11

1 PS/2 Mouse/Keyboard Port

8 Line In (Light Blue)

(Green/Purple)

** 9 Front Speaker (Lime)

2 D-Sub Port (VGA)

10 Microphone (Pink)

3 USB 2.0 Ports (USB_1_2)

11 USB 2.0 Ports (USB_3_4)

* 4 LAN RJ-45 Port

*** 12 eSATA3 Connector

5 Central / Bass (Orange)

13 HDMI Port

6 Rear Speaker (Black)

14 DVI-D Port

7 Optical SPDIF Out Port

15 USB 3.0 Ports (USB3_1_2)

* There are two LEDs on each LAN port. Please refer to the table below for the LAN

port LED indications.

ACT/LINK

SPEED

LAN Port LED Indications

LED

LED

Activity/Link LED SPEED LED

Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On 100Mbps connection Green 1Gbps connection

LAN Port

English

** If you use a 2-channel speaker, please connect the speaker’s plug into “Front

Speaker Jack”. See the table below for connection details in accordance with the

type of speaker you use.

TABLE for Audio Output Connection

Audio Output

Front Speaker

Rear Speaker

Central / Bass

Line In

Channels

(No. 9)

(No. 6)

(No. 5)

(No. 8)

2 V -- -- --

4 V V -- --

6 V V V --

8 V V V V

To enable Multi-Streaming function, you need to connect a front panel audio cable

to the front panel audio header. After restarting your computer, you will nd “Mixer”

tool on your system. Please select “Mixer ToolBox” , click “Enable play-

back multi-streaming”, and click “ok”.

Choose “2CH”, “4CH”, “6CH”, or “8CH” and then you are allowed to select “Realtek

HDA Primary output” to use Rear Speaker, Central/Bass, and Front Speaker, or

select “Realtek HDA Audio 2nd output” to use front panel audio.

*** eSATA3 connector supports SATA Gen3 in cable 1M.

English

4

ASRock FM2A75 Pro4-M Motherboard

1. Introduction

Thank you for purchasing ASRock FM2A75 Pro4-M motherboard, a reli-

able motherboard produced under ASRock’s consistently stringent quality

control. It delivers excellent performance with robust design conforming to

ASRock’s commitment to quality and endurance.

In this manual, chapter 1 and 2 contains the introduction of the mother-

board and step-by-step hardware installation guide. Chapter 3 and 4 con-

tains the conguration guide of BIOS setup and information of the Support

CD.

Because the motherboard specications and the BIOS software

might be updated, the content of this manual will be subject to

change without notice. In case any modications of this manual

occur, the updated version will be available on ASRock’s web-

site without further notice. You may nd the latest VGA cards

and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com

If you require technical support related to this motherboard,

please visit our website for specic information about the model

you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock FM2A75 Pro4-M Motherboard

(Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm)

ASRock FM2A75 Pro4-M Quick Installation Guide

ASRock FM2A75 Pro4-M Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

English

5

ASRock FM2A75 Pro4-M Motherboard

1.2 Specications

Platform - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x

24.4 cm

- All Solid Capacitor design

CPU - Support for Socket FM2 100W processors

- 4 + 2 Power Phase Design

TM

- Supports AMD’s Cool ‘n’ Quiet

Technology

- UMI-Link GEN2

Chipset - AMD A75 FCH (Hudson-D3)

Memory - Dual Channel DDR3 Memory Technology

- 4 x DDR3 DIMM slots

- Support DDR3 2600+(OC)/2400(OC)/2133(OC)/1866/

1600/1333/1066/800 non-ECC, un-buffered memory

(see CAUTION 1)

- Max. capacity of system memory: 64GB

(see CAUTION 2)

®

- Supports Intel

Extreme Memory Prole (XMP) 1.3 /

1.2

- Supports AMD Memory Prole (AMP)

Expansion Slot - 2 x PCI Express 2.0 x16 slots (PCIE1 @ x16 mode;

PCIE3 @ x4 mode)

- 1 x PCI Express 2.0 x1 slot

- 1 x PCI slot

TM

TM

- Supports AMD Quad CrossFireX

, CrossFireX

and

Dual Graphics

Graphics - AMD Radeon HD 7000 series graphics

- DirectX 11, Pixel Shader 5.0

- Max. shared memory 2GB

- Three VGA Output options: D-Sub, DVI-D and HDMI

English

- Supports HDMI 1.4a Technology with max. resolution

up to 1920x1200 @ 60Hz

- Supports Dual-link DVI with max. resolution up to

2560x1600 @ 75Hz

- Supports D-Sub with max. resolution up to 1920x

1600 @ 60Hz

6

ASRock FM2A75 Pro4-M Motherboard

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC

and HBR (High Bit Rate Audio) with HDMI

(see CAUTION 3)

- Supports Blu-ray Stereoscopic 3D with HDMI 1.4a

TM

- Supports AMD Steady Video

: New video post

processing capability for automatic jutter reduction on

home/online video

- Supports HDCP with DVI and HDMI ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD

playback with DVI and HDMI ports

Audio - 7.1 CH HD Audio with Content Protection

(Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse/Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x HDMI Port

- 1 x Optical SPDIF Out Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x eSATA3 Connector

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and

SPEED LED)

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/

Front Speaker/Microphone

SATA3 - 5 x SATA3 6.0 Gb/s connectors, support RAID (RAID

English

0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug

USB 3.0

- 2 x Rear USB 3.0 ports, support USB 1.1/2.0/3.0 up

to 5Gb/s

7

ASRock FM2A75 Pro4-M Motherboard

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),

supports USB 1.1/2.0/3.0 up to 5Gb/s

Connector - 5 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x Print port header

- 1 x COM port header

- 1 x Power LED header

- 1 x Chassis Intrusion header

- 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)

- 1 x Chassis Fan connector (4-pin)

- 1 x Power Fan connector (3-pin)

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, VDDP, VDDR, SB Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan

- CPU/Chassis Fan Multi-Speed Control

English

- CASE OPEN detection

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

®

®

TM

TM

OS - Microsoft

Windows

7 / 7 64-bit / Vista

/ Vista

64-bit / XP SP3 compliant

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is

required)

8

ASRock FM2A75 Pro4-M Motherboard

* For detailed product information, please visit our website:

http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with

overclocking, including adjusting the setting in the BIOS,

applying Untied Overclocking Technology, or using third-

party overclocking tools. Overclocking may affect your

system’s stability, or even cause damage to the compo-

nents and devices of your system. It should be done at

your own risk and expense. We are not responsible for

possible damage caused by overclocking.

English
