Festool DF 700 EQ: Original operating manual

12

DF 700 EQ

GB

Original operating manual

The illustrations specified are located at the begin-

ning and end of the operating manual.

1 Symbols 2 Technical  data 3 Machine features 4 Intended use

The machine is intended to create DOMINO dowel

connections in hard and soft wood, chipboard, ply-

wood and fibreboard. All applications beyond this

are regarded as unintended use.

The machine is designed and approved for use by

trained persons or specialists only.

The user is liable for improper or non-in-

tended use.

5 Safety instructions

5.1

General safety instructions

WARNING! Read all safety warnings and all

instructions.

Failure to follow the warnings

and instructions may result in electric shock, fire

and/or serious injury.

Save all warnings and instructions for future ref-

erence.

The term "power tool" in the warnings refers to

your mains-operated (corded) power tool or bat-

tery-operated (cordless) power tool.

1

Symbols................................................

12

2

Technical data ......................................

12

3

Machine features..................................

12

4

Intended use.........................................

12

5

Safety instructions ...............................

12

6

Operation..............................................

13

7

Settings ................................................

13

8

Working with the machine ...................

15

9

Service and maintenance.....................

16

10 Troubleshooting ...................................

16

11 Accessories ..........................................

17

12 Environment .........................................

17

13 EU Declaration of Conformity ..............

17

Warning of general danger

Risk of electric shock

Read the Operating Instructions/Notes!

Wear ear protection.

Wear a dust mask.

Wear protective gloves.

Disconnect from the power supply!

Burning risks from hot surfaces!

Do not throw in the household waste.

Joiner

DF 700 EQ

Power

720 W

Speed (no load) n

0

21000 rpm

Routing depth

15 - 70 mm

Routing width, max.

16,5 mm + Ø cutter

Ø cutter, max.

14 mm

Connecting thread of the drive

shaft

M8 x 1

Weight (excluding cable)

5,2 kg

Safety class

/II

[1-1]

Rubber buffer

[1-2]

Stop pins

[1-3]

Handles

[1-4]

On/Off switch

[1-5]

Display for dowel hole width

[1-6]

Adjusting lever for dowel hole width

[1-7]

Slide for routing depth adjustment

[1-8]

Snap button for routing depth adjustment

[1-9]

Marker for routing depth adjustment

[1-10]

Unlocking of motor unit/guide frame

[1-11]

Selection slide for routing height adjust-

ment

[1-12]

Clamp lever for routing angle adjustment

[1-13]

Button for releasing stop pins

[1-14]

Clamp lever for routing height adjustment

[1-15]

Extractor connector

[1-16]

Spindle lock

[1-17]

Mains power cable
