when under load.

Temperature cut-out

The machine power supply is limited and the speed

reduced if the motor exceeds a certain tempera-

ture. The machine continues operating at reduced

power to allow the ventilator to cool the motor

quickly. If the machine temperature exceeds the

maximum permitted value for longer periods, the

machine switches off completely after approx. 40

seconds and can only be switched on again once the

motor has cooled sufficiently.

Restart protection

The integral restart protection prevents the ma-

chine from automatically starting up again after an

interruption in power when the machine is used in

continuous operating mode. In this case the ma-

chine must be switched off and then switched back

on again.

7.2

Changing tools

Removing the tool



Lift the unlocking device

[3-2]

until it audibly

disengages using the open-ended spanner

[3-

3]

 supplied (SW 12).



Separate the motor unit

[3-5]

 from the guide

frame

[3-4]

.



Press and hold the spindle lock

[4-1]

.



Loosen the cutter

[4-3]

 using the open-ended

spanner

[4-2]

 and remove.



Release the spindle lock

[4-1]

.

Inserting the tool



Press and hold the spindle lock

[4-1]

.



Use the open-ended spanner

[4-2]

 to screw on

the cutter

[4-3]

.



Release the spindle lock

[4-1]

.



Slide the guide frame

[3-4]

 onto the motor unit

[3-5]

 until it audibly engages.

7.3

Setting the Mortise Depth



Press one or two snap buttons

[1-8]

.



Set the slide for the routing depth setting

[1-

7]

to the desired routing depth (15 - 70 mm).



Release the snap buttons

[1-8]

.



Check whether the slide

[1-7]

 has engaged cor-

rectly.



With the two markers

[1-9]

, you can mark two

routing depths and switch easily between them

using the slide

[1-7]

(e.g. for asymmetric DOMI-

NO dowel depth distribution).

7.4

Setting the Fence Height



The alignment of the clamp levers

[1-12]

 and

[1-14]

 can be aligned by raising the levers.

When tightened, the levers should not protrude

beyond the contact surface.

a) with selection slide



Loosen the clamp lever for the routing height

adjustment

[5-1]

.



Using the front handle

[5-2]

 raise the front part

of the guide frame.



Use the selection switch to set

[5-6]

the desired

routing height

h

 (10 mm; 15 mm; 20 mm;

25 mm; 30 mm; 40 mm).



Press the front section of the guide frame down-

wards as far as the stop.



Close the clamp lever

[5-1]

.

b) freely selectable



Loosen the clamp lever for the routing height

adjustment

[5-1]

.



Using the front handle

[5-2]

 raise the front sec-

tion of the guide frame.



Pull the selection slide

[5-6]

 as far as the stop

in the direction of the motor unit.



Set the desired routing height

h

 using the scale

[5-3]

 by moving the front section of the guide

frame vertically.



Close the clamp lever

[5-1]

.

CAUTION

Hot and sharp tools

Risk of injury



Wear protective gloves.

WARNING

Risk of injury



Before inserting a new cutter ensure that the

machine, the guide frame and the guides

[3-1]

and

[3-6]

 are clean.



Remove any contamination that may be present.



Only use sharp, undamaged and clean tools.

WARNING

Cutter can come out at the rear side of the work-

piece.

Risk of injury



Set the routing depth at least 5 mm less than the

workpiece thickness.
