LKP_EMEA.book Page 31 Wednesday, July 18, 2012 10:36 PM
Making a Phone Call with the One Touch Access
6 Press d to end the call.
Button
OR
Making and Receiving Calls
Press One Touch Access button. If the entry for the One
Procedure:
Touch Access button is empty, a negative indicator tone
1 Press the programmed One Touch Access button to make
sounds.
a Phone Call to the predefined alias or ID.
If the entry for the One Touch Access button is empty, a
7 The display shows Ending Phone Call.
negative indicator tone sounds.
8 If successful:
2 The LED lights up solid green. The Phone Call icon appears
A tone sounds and the display shows Call Ended.
in the top right corner. The first text line shows the
OR
subscriber alias. The second text line displays the call
If unsuccessful:
status.
Your radio returns to the Phone Call screen. Repeat Steps 6
and 7 or wait for the telephone user to end the call.
3 If successful:
You hear the dialing tone of the telephone user. The first text
When the telephone user ends the call, a tone sounds and the
line shows the subscriber alias. The Phone Call icon
display shows Call Ended.
remains in the top right corner.
If the call ends while you are entering the extra digits requested
OR
by the Phone Call, your radio returns to the screen you were on,
If unsuccessful:
prior to initiating the call.
A tone sounds and the display shows Phone Call Failed.
Your radio returns to the Access Code input screen.
During channel access, press
d to dismiss the call attempt
If the access code was preconfigured in the Contacts list,
and a tone sounds.
the radio returns to the screen you were on prior to initiating
the call.
During the call, when you press the One Touch Access button
4 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from
with the deaccess code preconfigured your radio attempts to
your mouth.
end the call.
5 Press the PTT button to talk and release to listen.
The access or deaccess code cannot be more than 10
characters.
31
English
LKP_EMEA.book Page 32 Wednesday, July 18, 2012 10:36 PM
Making a Phone Call with the Programmable
6 Press the PTT button to talk and release to listen.
Phone Button
7 Press d to end the call.
Procedure:
OR
Press One Touch Access button. If the entry for the One
1 Press the programmed Phone button to enter into the
Touch Access button is empty, a negative indicator tone
Phone Entry list.
sounds.
2 < or > to the required subscriber alias or ID, and
8 The display shows Ending Phone Call.
press e to select.
9 If successful:
3 The LED lights up solid green. The Phone Call icon appears
A tone sounds and the display shows Call Ended.
in the top right corner. The first text line shows the
OR
subscriber alias. The second text line displays the call
If unsuccessful:
status.
Your radio returns to the Phone Call screen. Repeat Steps 6
and 7 or wait for the telephone user to end the call.
4 If successful:
You hear the dialing tone of the telephone user. The first text
When you press PTT button while in the Phone Contacts
line shows the subscriber alias. The Phone Call icon
screen, a tone sounds and the display shows
remains in the top right corner.
Press OK to Place Call.
OR
When the telephone user ends the call, a tone sounds and the
If unsuccessful:
A tone sounds and the display shows Phone Call Failed.
display shows Call Ended.
Your radio returns to the Access Code input screen.
If the call ends while you are entering the extra digits requested
If the access code was preconfigured in the Contacts list,
by the Phone Call, your radio returns to the screen you were on
the radio returns to the screen you were on prior to initiating
prior to initiating the call.
the call.
Making and Receiving Calls
5 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from
your mouth.
32
English
LKP_EMEA.book Page 33 Wednesday, July 18, 2012 10:36 PM
During channel access, press d to dismiss the call attempt
is now free.
OR
and a tone sounds.
The radio sounds a negative indicator tone and the display
Making and Receiving Calls
shows Remote Dekey Failed.
During the call, when you press One Touch Access button with
the deaccess code preconfigured your radio attempts to end the
On the interrupted radio, the display shows
call.
Call Interrupted
, and the radio sounds a negative indicator
tone until you release the PTT button, if it is transmitting an
The access or de-access code cannot be more than 10
interruptible call that is stopped via this feature.
characters.
Talkaround
Stopping a Radio Call
You can continue to communicate when your repeater is not
This feature allows you to stop an ongoing Group or Private Call
operating, or when your radio is out of the repeater’s range but
to free the channel for transmission. For example, when a radio
within talking range of other radios.
experiences a “stuck microphone” condition where the PTT
This is called “talkaround”.
button is inadvertently pressed by the user.
Your radio must be programmed to allow you to use this feature.
NOTE: This feature is not applicable in Capacity Plus and
Linked Capacity Plus.
Procedure:
While on the required channel:
Procedure:
1 Press the programmed Transmit Interrupt Remote Dekey
Press the programmed Repeater/Talkaround button to toggle
button.
between talkaround and repeater modes.
OR
2 The display shows Remote Dekey.
Follow the procedure below.
3 Wait for acknowledgment.
1 c to access the menu.
4 The radio sounds a positive indicator tone and the display
2 < or > to Utilities and press e to select.
shows Remote Dekey Success, indicating that the channel
33
English
LKP_EMEA.book Page 34 Wednesday, July 18, 2012 10:36 PM
3 < or > to Radio Settings and press e to select.
Monitoring Features
4 Press e to enable Talkaround. The display shows 9
beside Enabled.
Monitoring a Channel
OR
Use the Monitor feature to make sure a channel is clear before
Press
e to disable Talkaround. The 9 disappears from
transmitting.
beside Enabled.
NOTE: This feature is not applicable in Capacity Plus and
5 The screen automatically returns to the previous menu.
Linked Capacity Plus.
Procedure:
The Talkaround setting is retained even after powering down.
1 Press and hold the programmed Monitor button and listen
NOTE: At Step 4, you can also use
< or > to change
for activity.
the selected option.
2 The Monitor icon appears on the status bar and the LED
lights up solid yellow.
3 You hear radio activity or total silence, depending on how
your radio is programmed.
4 When you hear “white noise” (that is, the channel is free),
press the PTT button to talk and release it to listen.
Making and Receiving Calls
34
English
LKP_EMEA.book Page 35 Wednesday, July 18, 2012 10:36 PM
Permanent Monitor
Use the Permanent Monitor feature to continuously monitor a
Making and Receiving Calls
selected channel for activity.
NOTE: This feature is not applicable in Capacity Plus and
Linked Capacity Plus.
Procedure:
1 Press the programmed Permanent Monitor button.
2 Radio sounds an alert tone, the LED lights up solid yellow,
and the display shows Permanent Monitor On. The
Monitor icon appears on the status bar.
3 Press the programmed Permanent Monitor button to exit
Permanent Monitor mode.
4 Radio sounds an alert tone, the LED turns off, and display
shows Permanent Monitor Off.
NOTE: Radio users who switch from analog to digital channels
often assume that the lack of static on a digital channel is an
indication that the radio is not working properly. This is not the
case. Digital technology quiets the transmission by removing
the noise from the signal and allowing only the clear voice or
data information to be heard.
35
English
LKP_EMEA.book Page 36 Wednesday, July 18, 2012 10:36 PM
Radio Check
Advanced Features
If enabled, this feature allows you to determine if another radio
Use the navigation guide to learn more about advanced
is active in a system without disturbing the user of that radio. No
features available with your radio:
audible or visual notification is shown on the target radio.
Radio Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 36
This feature is only applicable for subscriber aliases or IDs.
Scan Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 37
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 39
Sending a Radio Check
Vote Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 41
Contacts Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 42
Procedure:
Use the programmed Radio Check button.
Call Indicator Settings . . . . . . . . . . . . . . . . . . . . . . . . . page 44
Call Log Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 47
1 Press the programmed Radio Check button.
Call Alert Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . page 49
2 < or > to the required subscriber alias or ID and
Emergency Operation . . . . . . . . . . . . . . . . . . . . . . . . . page 50
press e to select.
Text Message Features. . . . . . . . . . . . . . . . . . . . . . . . page 55
Analog Status Update . . . . . . . . . . . . . . . . . . . . . . . . . page 62
3 The display shows transitional mini notice, indicating the
Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 63
request is in progress. The LED lights up solid green.
Multi-Site Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . page 64
4 Wait for acknowledgement.
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 66
5 If successful, a positive indicator tone sounds and the
Lone Worker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 68
display shows positive mini notice.
Password Lock Features. . . . . . . . . . . . . . . . . . . . . . . page 69
OR
Notification List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 71
If unsuccessful, a negative indicator tone sounds and the
Auto-Range Transponder System (ARTS) . . . . . . . . . page 72
display shows negative mini notice.
Advanced Features
Over-the-Air Programming (OTAP) . . . . . . . . . . . . . . . page 72
6 Radio returns to the subscriber alias or ID screen.
Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 73
Front Panel Programming (FPP). . . . . . . . . . . . . . . . . page 84
36
English
LKP_EMEA.book Page 37 Wednesday, July 18, 2012 10:36 PM
OR
Scan Lists
Procedure:
Advanced Features
Use the menu.
Scan lists are created and assigned to individual channels/
groups. Your radio scans for voice activity by cycling through the
1 c to access the menu.
channel/group sequence specified in the scan list for the current
channel/group.
2 < or > to Contacts and press e to select.
Your radio can support up to 250 scan lists, with a maximum of
3 < or > to the required subscriber alias or ID and
16 members in a list. Each scan list supports a mixture of both
press e to select.
analog and digital entries.
You can add, delete, or prioritize channels by editing a scan list.
4 < or > to Radio Check and press e to select.
You can attach a new scan list to your radio via Front Panel
5 The display shows transitional mini notice, indicating the
Programming.
request is in progress. The LED lights up solid green.
NOTE: This feature is not applicable in Capacity Plus and
6 Wait for acknowledgement.
Linked Capacity Plus.
7 If successful, a positive indicator tone sounds and the
display shows positive mini notice.
Viewing an Entry in the Scan List
OR
Procedure:
If unsuccessful, a negative indicator tone sounds and the
display shows negative mini notice.
1 c to access the menu.
8 Radio returns to the subscriber alias or ID screen.
2 < or > to Scan and press e to select.
If the d button is pressed when the radio is waiting for
3 < or > to Scan List and press e to select.
acknowledgement, a tone sounds, and the radio terminates all
retries and exits Radio Check mode.
4 Use < or > to view each member on the list.
37
English
LKP_EMEA.book Page 38 Wednesday, July 18, 2012 10:36 PM
The priority icon appears left of the member’s alias, if set, to
8 < or > to Yes and press e to select, to add another
indicate whether the member is on a Priority 1 or Priority 2
entry, and repeat Steps 5 to 8.
channel list. You cannot have multiple Priority 1 or Priority 2
OR
channels in a scan list.
< or > to No and press e to select to save the
There is no priority icon if priority is set to None.
current list.
Editing the Scan List
Deleting an Entry from the Scan List
Procedure:
Adding a New Entry to the Scan List
Procedure:
1 c to access the menu.
1 c to access the menu.
2 < or > to Scan and press e to select.
2 < or > to Scan and press e to select.
3 < or > to Scan List and press e to select.
3 < or > to Scan List and press e to select.
4 < or > to the required alias or ID.
4 < or > to Add Member and press e to select.
5 Press e to select.
5 < or > to the required alias or ID.
6 < or > to Delete and press e to select.
6 < or > to the required priority level and press e to
7 At Delete Entry?, < or > to Yes and press e to
select.
select, to delete the entry. The display shows positive mini
notice.
7 The display shows positive mini notice, followed
OR
immediately by Add Another?.
< or > to No and press e to select to return to the
Advanced Features
previous screen.
38
English
LKP_EMEA.book Page 39 Wednesday, July 18, 2012 10:36 PM
8 Repeat Steps 4 to 9 to delete other entries.
Scan
Advanced Features
After deleting all required aliases or IDs, long press
d to
When you start a scan, your radio cycles through the
return to the Home screen.
programmed scan list for the current channel looking for voice
activity.
Setting and Editing Priority for an Entry in the Scan
The LED blinks yellow and the scan icon appears on the status
List
bar.
Procedure:
During a dual mode scan, if you are on a digital channel, and
your radio locks onto an analog channel, it automatically
1 c to access the menu.
switches from digital mode to analog mode for the duration of
2 < or > to Scan and press e to select.
the call. This is also true for the reverse.
There are two ways of initiating scan:
3 < or > to Scan List and press e to select.
• Main Channel Scan (Manual): Your radio scans all the
4 < or > to the required alias or ID.
channels/groups in your scan list. On entering scan, your
radio may – depending on the settings – automatically start
5 Press c to select.
on the last scanned “active” channel/group or on the channel
where scan was initiated.
6 < or > to Edit Priority and press e to select.
• Auto Scan (Automatic): Your radio automatically starts
7 < or > to the required priority level and press e to
scanning when you select a channel/group that has Auto
select.
Scan enabled.
8 The display shows positive mini notice before returning to
NOTE: This feature is not applicable in Capacity Plus and
the previous screen.
Linked Capacity Plus.
9 The priority icon appears left of the member’s name.
There is no priority icon if priority is set to None.
39
English
LKP_EMEA.book Page 40 Wednesday, July 18, 2012 10:36 PM
Starting and Stopping Scan
Responding to a Transmission During a Scan
Procedure:
During scanning, your radio stops on a channel/group where
Press the programmed Scan button to start or stop Scan.
activity is detected. The radio stays on that channel for a
OR
programmed time period known as “hang time”.
Follow the procedure below.
Procedure:
1 Use the Channel Selector Knob to select a channel
1 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from
programmed with a scan list.
your mouth.
2 c to access the menu.
If the Channel Free Indication feature is enabled, you
will hear a short alert tone the moment the transmitting radio
3 < or > to Scan and press e to select.
releases the PTT button, indicating the channel is free for
you to respond.
4 < or > to Scan State and press e to select.
2 Press the PTT button during hang time. The LED lights up
5 < or > to required scan state and press e to select.
solid green.
6 The display shows Scan On when scan is enabled. The LED
3 Wait for the Talk Permit Tone to finish (if enabled) and speak
blinks yellow and the scan icon appears.
clearly into the microphone.
OR
OR
The display shows Scan Off if scan is disabled. The LED
Wait for the PTT Sidetone to finish (if enabled) and
turns off and the scan icon disappears.
speak clearly into the microphone.
While scanning, the radio will only accept data (e.g. text
4 Release the PTT button to listen.
message, location, or PC data) if received on its Selected
Channel.
5 If you do not respond within the hang time, the radio returns
to scanning other channels/groups.
Advanced Features
40
English
LKP_EMEA.book Page 41 Wednesday, July 18, 2012 10:36 PM
Deleting a Nuisance Channel
Vote Scan
If a channel continually generates unwanted calls or noise
Advanced Features
Vote Scan provides you with wide area coverage in areas where
(termed a “nuisance” channel), you can temporarily remove the
there are multiple base stations transmitting identical
unwanted channel from the scan list.
information on different analog channels.
This capability does not apply to the channel designated as the
Your radio scans analog channels of multiple base stations and
Selected Channel.
performs a voting process to select the strongest received
Procedure:
signal. Once that is established, your radio unmutes to
1 When your radio “locks on to” an unwanted or nuisance
transmissions from that base station.
channel, press the programmed Nuisance Channel Delete
The LED blinks yellow and the vote scan icon appears on the
button until you hear a tone.
status bar.
2 Release the Nuisance Channel Delete button. The
To respond to a transmission during a Vote Scan, follow the
nuisance channel is deleted.
same procedures as Responding to a Transmission During a
Deleting a “nuisance” channel is only possible through the
Scan on page 40.
programmed Nuisance Channel Delete button. This feature is
not accessible through the menu.
Restoring a Nuisance Channel
Procedure:
To restore the deleted nuisance channel, do one of the
following:
• Turn the radio off and then power it on again, OR
• Stop and restart a scan via the programmed Scan button or
menu, OR
• Change the channel via the Channel Selector Knob.
41
English
LKP_EMEA.book Page 42 Wednesday, July 18, 2012 10:36 PM
Contacts Settings
NOTE: You can add, or edit subscriber IDs for the Digital
Contacts list. Deleting subscriber IDs can only be
performed by your dealer.
Contacts provides “address-book” capabilities on your radio.
Each entry corresponds to an alias or ID that you use to initiate
For the Analog Contacts list, you can only view the
a call.
subscriber IDs, edit the subscriber IDs, and initiate a
Each entry, depending on context, associates with one of five
Call Alert. Adding and deleting capabilities can only be
types of calls: Group Call, Private Call, All Call, PC Call or
performed by your dealer.
Dispatch Call.
Making a Group Call from Contacts
PC Call and Dispatch Call are data-related. They are only
available with the applications. Refer to the data applications
Procedure:
documentation for more information.
1 c to access the menu.
NOTE: If the Privacy feature is enabled on a channel, you
2 < or > to Contacts and press e to select.The
can make privacy-enabled Group Call, Private Call,
entries are alphabetically sorted.
and All Call on that channel. Only target radios with
the same Privacy Key OR the same Key Value and
3 < or > to the required group alias or ID.
Key ID as your radio will be able to unscramble the
transmission.
4 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from
See Privacy on page 63 for more information.
your mouth.
5 Press the PTT button to make the call. The LED lights up
Your radio supports two Contacts lists, one for Analog contacts
solid green.
and one for Digital contacts, with a maximum of 500 members
for each Contacts list.
6 Wait for the Talk Permit Tone to finish (if enabled) and speak
clearly into the microphone.
Each entry within Contacts displays the following information:
OR
Advanced Features
• Call Type
Wait for the PTT Sidetone to finish (if enabled) and
• Call Alias
speak clearly into the microphone.
• Call ID
42
English
LKP_EMEA.book Page 43 Wednesday, July 18, 2012 10:36 PM
7 Release the PTT button to listen. When any user in the
7 Wait for the Talk Permit Tone to finish (if enabled) and speak
group responds, the LED blinks green. You see the Group
clearly into the microphone.
Advanced Features
Call icon, the group ID, and that user’s ID on your display.
8 Release the PTT button to listen. When the target radio
8 If the Channel Free Indication feature is enabled, you
responds, the LED blinks green and the display shows the
will hear a short alert tone the moment the target radio
transmitting user's ID.
releases the PTT button, indicating the channel is free for
9 If the Channel Free Indication feature is enabled, you will
you to respond. Press the PTT button to respond.
hear a short alert tone the moment the target radio releases
OR
the PTT button, indicating the channel is free for you to
If there is no voice activity for a programmed period of time,
respond. Press the PTT button to respond.
the call ends.
OR
If there is no voice activity for a programmed period of time,
Making a Private Call from Contacts
the call ends.
Procedure:
10 You hear a short tone. The display shows Call Ended.
1 c to access the menu.
2 < or > to Contacts and press e to select.The
entries are alphabetically sorted.
3 < or > to the required subscriber alias or ID.
4 Press e to select.
5 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from
your mouth.
6 Press the PTT button to make the call. The LED lights up
solid green. The display shows the destination alias.
43
English
LKP_EMEA.book Page 44 Wednesday, July 18, 2012 10:36 PM
Setting Default Contact
Call Indicator Settings
Procedure:
Activating and Deactivating Call Ringers for Call
Follow the procedure below.
Alert
1 c to access the menu.
You can select, or turn on or off ringing tones for a received Call
2 < or > to Contacts and press e to select.
Alert.
3 < or > to the required alias or ID and press e to
Procedure:
select.
1 c to access the menu.
4 < or > to Set as Default and press e to select.
2 < or > to Utilities and press e to select.
5 The radio sounds a positive indicator tone and the display
3 < or > to Radio Settings and press e to select.
shows positive mini notice.
6 A 9 appears beside the selected default alias or ID.
4 < or > to Tones/Alerts and press e to select.
5 < or > to Call Ringers and press e to select.
6 < or > to Call Alert and press e to select. The
current tone is indicated by a 9.
7 < or > to the required tone and press e to select. 9
appears beside selected tone.
NOTE: At Step 6, you can also use
< or > to change the
Advanced Features
selected option.
44
English
LKP_EMEA.book Page 45 Wednesday, July 18, 2012 10:36 PM
Activating and Deactivating Call Ringers for
Activating and Deactivating Call Ringers for
Private Calls
Selective Call
Advanced Features
You can turn on or off the ringing tones for a received Private
You can select, or turn on or off ringing tones for a received
Call.
Selective Call.
Procedure:
Procedure:
1 c to access the menu.
1 c to access the menu.
2 < or > to Utilities and press e to select.
2 < or > to Utilities and press e to select.
3 < or > to Radio Settings and press e to select.
3 < or > to Radio Settings and press e to select.
4 < or > to Tones/Alerts and press e to select.
4 < or > to Tones/Alerts and press e to select.
5 < or > to Call Ringers and press e to select.
5 < or > to Call Ringers and press e to select.
6 < or > to Private Call.
6 < or > to Selective Call and press e to select.
The current tone is indicated by a 9.
7 Press e to enable Private Call ringing tones. The display
shows 9 beside Enabled.
7 < or > to the required tone and press e to select. 9
OR
appears beside selected tone.
Press
e to disable Private Call ringing tones. The 9
disappears from beside Enabled.
NOTE: At Step 6, you can also use
< or > to change the
selected option.
NOTE: At Step 6, you can also use < or > to change the
selected option.
45
English
LKP_EMEA.book Page 46 Wednesday, July 18, 2012 10:36 PM
Activating and Deactivating Call Ringers for Text
Assigning Ring Styles
Message
You can program your radio to sound one of ten predefined
ringing tones when receiving a Call Alert or a Text Message
You can select, or turn on or off the ringing tones for a received
from a particular contact.
Text Message.
Procedure:
Procedure:
1 c to access the menu.
1 c to access the menu.
2 < or > to Contacts and press e to select.The
2 < or > to Utilities and press e to select.
entries are alphabetically sorted.
3 < or > to Radio Settings and press e to select.
3 < or > to the required alias or ID and press e to
4 < or > to Tones/Alerts and press e to select.
select.
5 < or > to Call Ringers and press e to select.
4 < or > to Edit and press e to select.
6 < or > to Messages and press e to select. The
5 Press c until display shows Edit Ringtone menu.
current tone is indicated by a 9.
6 A 9 indicates the current selected tone.
7 < or > to the required tone and press e to select. 9
7 < or > to the required tone and press e to select. 9
appears beside selected tone.
appears beside selected tone.
NOTE: At Step 6, you can also use
< or > to change the
8 The display shows a positive mini notice.
selected option.
The radio sounds out each ring style as you navigate through
the list.
Advanced Features
46
English
LKP_EMEA.book Page 47 Wednesday, July 18, 2012 10:36 PM
Escalating Alarm Tone Volume
Call Log Features
You can program your radio to continually alert you when a
Advanced Features
Your radio keeps track of all recent outgoing, answered, and
radio call remains unanswered. This is done by automatically
missed Private Calls. Use the call log feature to view and
increasing the alarm tone volume over time. This feature is
manage recent calls.
known as Escalert.
You can perform the following tasks in each of your call lists:
Procedure:
• Delete
1 c to access the menu.
• View Details
2 < or > to Utilities and press e to select.
3 < or > to Radio Settings and press e to select.
Viewing Recent Calls
The lists are Missed, Answered, and Outgoing.
4 < or > to Tones/Alerts and press e to select.
Procedure:
5 < or > to Escalert.
1 c to access the menu.
6 Press e to enable Escalert. The display shows 9 beside
2 < or > to Call Log and press e to select.
Enabled.
OR
3 < or > to required list and press e to select.
Press
e to disable Escalert. The 9 disappears from beside
4 The display shows the most recent entry at the top of the
Enabled.
list.
NOTE: At Step 5, you can also use < or > to change the
5 < or > to view the list.
selected option.
Press the PTT button to start a Private Call with the current
selected alias or ID.
47
English
LKP_EMEA.book Page 48 Wednesday, July 18, 2012 10:36 PM
Deleting a Call from a Call List
Viewing Details from a Call List
Procedure:
Procedure:
1 c to access the menu.
1 c to access the menu.
2 < or > to Call Log and press e to select.
2 < or > to Call Log and press e to select.
3 < or > to the required list and press e to select.
3 < or > to the required list and press e to select.
4 < or > to the required alias or ID and press e to
4 < or > to the required alias or ID and press e to
select.
select.
5 < or > to Delete and press e to select.
5 < or > to View Details and press e to select.
Display shows details.
6 Press e to select Yes to delete the entry. The display
shows positive mini notice.
OR
< or > to No to return to the previous screen.
When you select a call list and it contains no entries, the display
shows
List Empty
,.
Advanced Features
48
English
LKP_EMEA.book Page 49 Wednesday, July 18, 2012 10:36 PM
Call Alert Operation
Making a Call Alert from the Contacts List
Procedure:
Advanced Features
Call Alert paging enables you to alert a specific radio user to call
you back when they are able to do so.
1 c to access the menu.
This feature is applicable for subscriber aliases or IDs only and
2 < or > to Contacts and press e to select.
is accessible through the menu via Contacts.
3 < or > to the required subscriber alias or ID and
Receiving and Responding to a Call Alert
press e to select.
When you receive a Call Alert page, you see the notification list
4 < or > to Call Alert and press e to select.
listing a Call Alert with the alias or ID of the calling radio on the
display.
5 The display shows Call Alert and the subscriber alias or
Procedure:
ID, indicating that the Call Alert has been sent.
1 You hear a repetitive tone. The LED blinks yellow.
6 The LED lights up solid green when your radio is sending
the Call Alert.
2 Press the PTT button while the display still shows the Call
Alert in the Notification List to respond with a Private Call.
7 If the Call Alert acknowledgement is received, the display
OR
shows positive mini notice.
OR
Press d to exit the Notification List. The alert is moved to
If the Call Alert acknowledgement is not received, the
the Missed Call Log.
display shows negative mini notice.
See Notification List on page 71 for details about the
Notification List.
See Call Log Features on page 47 for details about the Missed
Call List.
49
English
LKP_EMEA.book Page 50 Wednesday, July 18, 2012 10:36 PM
Making a Call Alert with the One Touch Access
Emergency Operation
Button
An Emergency Alarm is used to indicate a critical situation. You
Procedure:
are able to initiate an Emergency at any time on any screen
1 Press the programmed One Touch Access button to make
display even when there is activity on the current channel.
a Call Alert to the predefined alias or ID.
Your dealer can set the duration of a button press for the
2 The display shows Call Alert and the subscriber alias or
programmed Emergency button, except for long press, which is
ID, indicating that the Call Alert has been sent.
similar with all other buttons:
3 The LED lights up solid green when your radio is sending
• Short press – Between 0.05 seconds and 0.75 seconds
the Call Alert.
• Long press – Between 1.00 second and 3.75 seconds
4 If the Call Alert acknowledgement is received, the display
The programmed Emergency button is assigned with the
shows positive mini notice.
Emergency On/Off feature. Check with your dealer for the
OR
assigned operation of the Emergency button.
If the Call Alert acknowledgement is not received, the
If short press the programmed Emergency button is assigned
display shows negative mini notice.
to turn on the Emergency mode, then long press the
programmed Emergency button is assigned to exit the
Emergency mode.
If long press the programmed Emergency button is assigned to
turn on the Emergency mode, then short press the programmed
Emergency button is assigned to exit the Emergency mode.
NOTE: Side Button 1 or Side Button 2 can be programmed as
the Emergency Button.
Advanced Features
50
English
