ASRock FM2A85X Extreme4: 2. Installation

15

ASRock  FM2A85X Extreme4  Motherboard

English

2.  Installation

This is an ATX form factor motherboard. Before you install the motherboard, study

the con

fi

 guration of your chassis to ensure that the motherboard

fi

 ts into it.

Pre-installation Precautions

Take note of the following precautions before you install motherboard

components or change any motherboard settings.

Before you install or remove any component, ensure that the

power is switched off or the power cord is detached from the

power supply. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

1.   Unplug the power cord from the wall socket before touching any

component.

2.   To avoid damaging the motherboard components due to static elec-

tricity, NEVER place your motherboard directly on the carpet or the

like. Also remember to use a grounded wrist strap or touch a safety

grounded object before you handle components.

3.   Hold components by the edges and do not touch the ICs.

4.   Whenever you uninstall any component, place it on a grounded anti-

static pad or in the bag that comes with the component.

5.

When placing screws into the screw holes to secure the mother-

board to the chassis, please do not over-tighten the screws! Doing

so may damage the motherboard.

16

ASRock  FM2A85X Extreme4  Motherboard

English

2.1  CPU Installation

Step 1.  Unlock the socket by lifting the lever up to a 90

o

angle.

Step 2.  Position the CPU directly above the socket such that the CPU corner with

the golden triangle matches the socket corner with a small triangle.

Step 3.  Carefully insert the CPU into the socket until it

fi

 ts in place.

The CPU

fi

 ts only in one correct orientation. DO NOT force the CPU

into the socket to avoid bending of the pins.

Step 4.  When the CPU is in place, press it

fi

 rmly on the socket while you push

down the socket lever to secure the CPU. The lever clicks on the side tab

to indicate that it is locked.

2.2  Installation of CPU Fan and Heatsink

After you install the CPU into this motherboard, it is necessary to install a

larger heatsink and cooling fan to dissipate heat. You also need to spray

thermal grease between the CPU and the heatsink to improve heat dis-

sipation. Make sure that the CPU and the heatsink are securely fastened

and in good contact with each other. Then connect the CPU fan to the

CPU FAN connector (CPU_FAN1, see Page 2, No. 5 or CPU_FAN2, see

Page 2, No. 6).  For proper installation, please kindly refer to the instruc-

tion manuals of the CPU fan and  the heatsink.

STEP 1:

Lift Up The Socket Lever

STEP 2 / STEP 3:

Match The CPU Golden Triangle

To The Socket Corner Small

Triangle

STEP 4:

Push Down And Lock

The Socket Lever

CPU Golden Triangle

Lever  90° Up

Socket Corner Small

Triangle

17

ASRock  FM2A85X Extreme4  Motherboard

English

2.3  Installation of Memory Modules (DIMM)

This motherboard provides four 240-pin DDR3 (Double Data Rate 3) DIMM

slots, and supports Dual Channel Memory Technology. For dual channel con-

fi

 guration, you always need to install

identical

 (the same brand, speed, size

and chip-type) DDR3 DIMM pair in the slots of the same color. In other words,

you have to install

identical

 DDR3 DIMM pair in

Dual Channel A

(DDR3_A1

and DDR3_B1; see p.2 No.7) or

identical

 DDR3 DIMM pair in

Dual Channel

B

(DDR3_A2 and DDR3_B2; see p.2 No.8), so that Dual Channel Memory

Technology can be activated. This motherboard also allows you to install four

DDR3 DIMMs for dual channel con

fi

 guration, and please install

identical

 DDR3

DIMMs in all four slots. You may refer to the Dual Channel Memory Con

fi

 gura-

tion Table below.

Dual Channel Memory Con

fi

 gurations

DDR3_A1

 DDR3_A2

  DDR3_B1    DDR3_B2

(1)

Populated             -

  Populated

   -

(2)

-

 Populated               -               Populated

(3)*

Populated

 Populated

  Populated    Populated

*

  For the con

fi

 guration (3), please install

identical

 DDR3 DIMMs in all four

 slots.

1.  If you want to install two memory modules, for optimal compatibility

and reliability, it is recommended to install them in the slots: DDR3_

A1 and DDR3_B1, or DDR3_A2 and DDR3_B2.

2.  If only one memory module or three memory modules are installed

in the DDR3 DIMM slots on this motherboard, it is unable to activate

the Dual Channel Memory Technology.

3.  If a pair of memory modules is NOT installed in the same Dual

Channel, for example, installing a pair of memory modules in

DDR3_A1 and DDR3_A2, it is unable to activate the Dual Channel

Memory Technology .

4.  It is not allowed to install a DDR or DDR2 memory module into

DDR3 slot; otherwise, this motherboard and DIMM may be dam-

aged.

5.  If you adopt DDR3 2600/2400/2133/1866/1600 memory modules

on this motherboard, it is recommended to install them on DDR3_

A2 and DDR3_B2 slots.

18

ASRock  FM2A85X Extreme4  Motherboard

English

notch

break

notch

break

Installing a DIMM

Please make sure to disconnect power supply before adding or

removing DIMMs or the system components.

Step 1.  Unlock a DIMM slot by pressing the retaining clips outward.

Step 2.  Align a DIMM on the slot such that the notch on the DIMM matches the

break on the slot.

The DIMM only

fi

 ts in one correct orientation. It will cause permanent

damage to the motherboard and the DIMM if you force the DIMM into

the slot at incorrect orientation.

Step 3.  Firmly insert the DIMM into the slot until the retaining clips at both ends

fully snap back in place and the DIMM is properly seated.

19

ASRock  FM2A85X Extreme4  Motherboard

English

2.4  Expansion Slots (PCI and PCI Express Slots)

There are 3 PCI slots and 4 PCI Express slots on this motherboard.

PCI Slots:

  PCI slots are used to install expansion cards that have the 32-bit PCI

 interface.

PCIE Slots:

PCIE1 / PCIE3 (PCIE x1 slot) is used for PCI Express cards with x1

lane width cards, such as Gigabit LAN card and SATA2 card.

PCIE2 (PCIE x16 slot) is used for PCI Express x16 lane width graphics

cards, or used to install PCI Express graphics cards to support CrossFi-

reX

TM

 function.

PCIE4 (PCIE x16 slot) is used for PCI Express x4 lane width cards,

or used to install PCI Express graphics cards to support CrossFireX

TM

function.

1.   In single VGA card mode, it is recommended to install a PCI Ex-

press x16 graphics card on PCIE2 slot.

2.   In  CrossFireX

TM

 mode, please install PCI Express x16 graphics

cards on PCIE2 and PCIE4 slots.

3.  Please connect a chassis fan to motherboard chassis fan connec-

tor (CHA_FAN1, CHA_FAN2 or CHA_FAN3) when using multiple

graphics cards for better thermal environment.

Installing an expansion card

Step 1.

Before installing the expansion card, please make sure that the power

supply is switched off or the power cord is unplugged. Please read the

documentation of the expansion card and make necessary hardware

settings for the card before you start the installation.

Step 2.

Remove the system unit cover (if your motherboard is already installed

in a chassis).

Step 3.

Remove the bracket facing the slot that you intend to use. Keep the

screws for later use.

Step 4.

Align the card connector with the slot and press

fi

 rmly until the card is

completely seated on the slot.

Step 5.

Fasten the card to the chassis with screws.

Step 6.

Replace the system cover.

20

ASRock  FM2A85X Extreme4  Motherboard

English

2.5  CrossFireX

TM

 and Quad CrossFireX

TM

 Operation Guide

This motherboard supports CrossFireX

TM

 and Quad CrossFireX

TM

 feature.

CrossFireX

TM

 technology offers the most advantageous means available of

combining multiple high performance Graphics Processing Units (GPU) in a single

PC. Combining a range of different operating modes with intelligent software design

and an innovative interconnect mechanism, CrossFireX

TM

 enables the highest

possible level of performance and image quality in any 3D application. Please check

AMD website for AMD CrossFireX

TM

 driver updates.

2.5.1  Graphics Card Setup

Different CrossFireX

TM

 cards may require different methods to enable CrossFi-

reX

TM

 feature. For other CrossFireX

TM

 cards that AMD has released or will release

in the future, please refer to AMD graphics card manuals for detailed installation

guide.

Step 1.  Insert one Radeon graphics card into PCIE2 slot and the other Radeon

graphics card to PCIE4 slot. Make sure that the cards are properly seated

on the slots.

1.   If a customer incorrectly configures their system they will not see the

performance bene

fi

 ts of CrossFireX

TM

. All three CrossFireX

TM

 components, a

CrossFireX

TM

 Ready graphics card, a CrossFireX

TM

 Ready motherboard and a

CrossFireX

TM

 Edition co-processor graphics card, must be installed correctly

to bene

fi

 t from the CrossFireX

TM

 multi-GPU platform.

2.   If you pair a 12-pipe CrossFireX

TM

 Edition card with a 16-pipe card,  both

cards will operate as 12-pipe cards while in CrossFireX

TM

 mode.

21

ASRock  FM2A85X Extreme4  Motherboard

English

Step 2.  Connect two Radeon graphics cards by installing CrossFire Bridge on

CrossFire Bridge Interconnects on the top of Radeon graphics cards.

(CrossFire Bridge is provided with the graphics card you purchase, not

bundled with this motherboard. Please refer to your graphics card vendor

for details.)

CrossFire Bridge

or

Step 3.  Connect the DVI monitor cable to the DVI connector on the Radeon graph-

ics card on PCIE2 slot. (You may use the DVI to D-Sub adapter to convert

the DVI connector to D-Sub interface, and then connect the D-Sub monitor

cable to the DVI to D-Sub adapter.)

22

ASRock  FM2A85X Extreme4  Motherboard

English

 The Catalyst Uninstaller is an optional download. We recommend using this

 utility to uninstall any previously installed Catalyst drivers prior to installation.

 Please check AMD website for AMD driver updates.

Step 3.  Install the required drivers to your system.

 For

Windows

®

 8 / 7 / Vista

TM

 OS:

Install the CATALYST Control Center. Please check AMD website for de-

tails.

Step 4.  Restart your computer.

Step 5.  Install the VGA card drivers to your system, and restart your computer.

Then you will

fi

 nd “ATI Catalyst Control Center” on your Windows

®

 taskbar.

ATI Catalyst Control Center

2.5.2  Driver Installation and Setup

Step 1.  Power on your computer and boot into OS.

Step 2.  Remove the AMD driver if you have any VGA driver installed in your sys-

tem.

Step 6.  Double-click “ATI Catalyst Control Center”. Click “View”, select “CrossFi-

reX

TM

”, and then check the item “Enable CrossFireX

TM

”. Select “2 GPUs”

and click “Apply” (if you install two Radeon graphics cards).

23

ASRock  FM2A85X Extreme4  Motherboard

English

Although you have selected the option “Enable CrossFire

TM

”, the Cross-

FireX

TM

 function may not work actually. Your computer will automatically

reboot. After restarting your computer, please con

fi

 rm whether the option

“Enable CrossFire

TM

” in “ATI Catalyst Control Center” is selected or not;

if not, please select it again, and then you are able to enjoy the bene

fi

 t  of

CrossFireX

TM

feature.

Step 7.  You  can freely enjoy the bene

fi

 t of CrossFireX

TM

 or Quad CrossFireX

TM

feature.

 * CrossFireX

TM

 appearing here is a registered trademark of AMD Technologies Inc., and is

   used only for identi

fi

 cation or explanation and to the owners’ bene

fi

 t, without intent to infringe.

*  For further information of AMD CrossFireX

TM

 technology, please check AMD website for

   updates and details.

24

ASRock  FM2A85X Extreme4  Motherboard

English

2.6 Jumpers Setup

The illustration shows how jumpers are

setup. When the jumper cap is placed on

pins, the jumper is “Short”. If no jumper cap

is placed on pins, the jumper is “Open”. The

illustration shows a 3-pin jumper whose

pin1 and  pin2 are “Short” when jumper cap

is placed on these 2 pins.

Jumper Setting

Description

Clear CMOS Jumper

(CLRCMOS1)

(see p.2,  No. 27)

Note:  CLRCMOS1 allows you to clear the data in CMOS. To clear and reset the

system parameters to default setup, please turn off the computer and unplug

the power cord from the power supply. After waiting for 15 seconds, use a

jumper cap to short pin2 and pin3 on CLRCMOS1 for 5 seconds. However,

please do not clear the CMOS right after you update the BIOS. If you need

to clear the CMOS when you just

fi

 nish updating the BIOS, you must boot

up the system

fi

 rst, and then shut it down before you do the clear-CMOS ac-

tion. Please be noted that the password, date, time, user default pro

fi

 le, 1394

GUID and MAC address will be cleared only if the CMOS battery is removed.

Clear CMOS

Default

The Clear CMOS Switch has the same function as the Clear CMOS

jumper.

25

ASRock  FM2A85X Extreme4  Motherboard

English

2.7  Onboard Headers and Connectors

Onboard headers and connectors are NOT jumpers. Do NOT place

jumper caps over these headers and connectors. Placing jumper caps

over the headers and connectors will cause permanent damage of the

motherboard!

Serial ATA3 Connectors

These seven Serial ATA3

(SATA3_1: see  p.2, No. 13)

(SATA3) connectors support

(SATA3_2: see  p.2, No. 12)

SATA data cables for internal

(SATA3_3: see  p.2, No. 14)

storage devices. The current

(SATA3_4: see  p.2, No. 15)

SATA3 interface allows up to

(SATA3_5: see  p.2, No. 19)

6.0 Gb/s data transfer rate.

(SATA3_6: see  p.2, No. 16)

(SATA3_7: see  p.2, No. 17)

Serial ATA (SATA)

Either end of the SATA data

Data Cable

cable can be connected to the

(Optional)

SATA3 hard disk or the SATA3

connector on this motherboard.

USB 2.0 Headers

Besides two default USB 2.0

(9-pin USB3_4)

ports on the I/O panel, there

(see p.2  No. 30)

are three USB 2.0 headers on

this motherboard. Each USB 2.0

header can support two USB

 2.0

ports.

(9-pin USB5_6)

(see p.2  No. 29)

(9-pin USB7_8)

(see p.2  No. 28)

1

USB_PWR

P-4

P+4

USB_PWR

P-3

P+3

GND

GND

DUMMY

1

USB_PWR

P-6

P+6

USB_PWR

P-5

P+5

GND

GND

DUMMY

1

USB_PWR

P-8

P+8

USB_PWR

P-7

P+7

GND

GND

DUMMY

SA

TA3_6     SA

TA3_3     SA

TA3_1

SA

TA3_7     SA

TA3_4     SA

TA3_2

SATA3_5

26

ASRock  FM2A85X Extreme4  Motherboard

English

Infrared Module Header

This header supports an

(5-pin IR1)

optional wireless transmitting

(see p.2  No. 25)

and receiving infrared module.

Front Panel Audio Header

This is an interface for the front

(9-pin  HD_AUDIO1)

panel audio cable that allows

(see  p.2  No. 34)

convenient connection and

control of audio devices.

Consumer Infrared Module Header

This header can be used to

(4-pin CIR1)

connect the remote

(see  p.2  No. 31)

 controller

receiver.

1

IRTX

+5VSB

DUMMY

IRRX

GND

J_SENSE

OUT2_L

1

MIC_RET

PRESENCE#

GND

OUT2_R

MIC2_R

MIC2_L

OUT_RET

1. High De

fi

 nition Audio supports Jack Sensing, but the panel wire on

    the chassis must support HDA to function correctly. Please follow the

    instruction in our manual and chassis manual to install your system.

2. If you use AC’97 audio panel, please install it to the front panel audio

    header as below:

    A. Connect Mic_IN (MIC) to MIC2_L.

    B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.

    C. Connect Ground (GND) to Ground (GND).

    D. MIC_RET and OUT_RET are for HD audio panel only. You don’t

         need to connect them for AC’97 audio panel.

    E. To activate the front mic.

         For Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit OS:

         Go to the “FrontMic” Tab in the Realtek Control panel. Adjust

         “Recording Volume”.

USB 3.0 Header

Besides six default USB 3.0

(19-pin USB3_7_8)

ports on the I/O panel, there is

(see p.2,  No. 10)

one USB 3.0 header on this

motherboard. This USB 3.0

header can support two USB 3.0

 ports.

IntA_P8_D+

DUMMY

IntA_P8_D-

GND

IntA_P8_SSTX+

GND

IntA_P8_SSTX-

IntA_P8_SSRX+

IntA_P8_SSRX-

Vbus

Vbus

Vbus

IntA_P7_SSRX-

IntA_P7_SSRX+

GND

IntA_P7_SSTX-

IntA_P7_SSTX+

GND

IntA_P7_D-

IntA_P7_D+

27

ASRock  FM2A85X Extreme4  Motherboard

English

Power LED Header

Please connect the chassis

(3-pin PLED1)

power LED to this header to

(see p.2  No. 26)

indicate system power status.

The LED is on when the system

is operating. The LED keeps

blinking in S1 state. The LED is

off in S3/S4 state or S5 state

(power

off).

Chassis Speaker Header

Please connect the chassis

(4-pin SPEAKER 1)

speaker to this header.

(see p.2  No. 23)

1

PLED+

PLED+

PLED-

System Panel Header

This header accommodates

(9-pin PANEL1)

several system front panel

(see p.2  No. 21)

 functions.

Connect the power switch, reset switch and system status indicator

on the chassis to this header according to the pin assignments below.

Note the positive and negative pins before connecting the cables.

PWRBTN (Power Switch):

Connect to the power switch on the chassis front panel. You may con-

fi

 gure the way to turn off your system using the power switch.

RESET (Reset Switch):

Connect to the reset switch on the chassis front panel. Press the reset

switch to restart the computer if the computer freezes and fails to per-

form a normal restart.

PLED (System Power LED):

Connect to the power status indicator on the chassis front panel. The

LED is on when the system is operating. The LED keeps blinking

when the sys-tem is in S1 sleep state. The LED is off when the system

is in S3/S4 sleep state or powered off (S5).

HDLED (Hard Drive Activity LED):

Connect to the hard drive activity LED on the chassis front panel. The

LED is on when the hard drive is reading or writing data.

The front panel design may differ by chassis. A front panel module

mainly consists of power switch, reset switch, power LED, hard drive

activity LED, speaker and etc. When connecting your chassis front

panel module to this header, make sure the wire assignments and the

pin assign-ments are matched correctly.

28

ASRock  FM2A85X Extreme4  Motherboard

English

CPU Fan Connectors

Please connect the CPU fan

(4-pin CPU_FAN1)

cable to the connector and

(see p.2  No. 5)

match the black wire to the

ground

pin.

       Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin

       CPU fan still can work successfully even without the fan speed control function.

       If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this

       motherboard, please connect it to Pin 1-3.

ATX Power Connector

Please connect an ATX power

(24-pin ATXPWR1)

supply to this connector.

(see p.2  No. 9)

12

 1

       Though this motherboard provides 24-pin ATX power connector,

       it can still work if you adopt a traditional 20-pin ATX power supply.

       To use the 20-pin ATX power supply, please plug your power

       supply along with Pin 1 and Pin 13.

(3-pin CPU_FAN2)

(see p.2  No. 6)

20-Pin ATX Power Supply Installation

Pin 1-3 Connected

3-Pin Fan Installation

12

 1

24

13

24

13

GND

+12V

CPU_FAN_SPEED

FAN_SPEED_CONTROL

1  2  3  4

GND

+12V

CPU_FAN_SPEED

Chassis and Power Fan Connectors

Please connect the fan cables

(4-pin CHA_FAN1)

to the fan connectors and

(see p.2  No. 24)

match the black wire to the

ground pin. CHA_FAN1/2/3 fan

(3-pin CHA_FAN2)

speed can be controlled through

(see p.2  No. 43)

UEFI or AXTU.

(3-pin CHA_FAN3)

(see p.2  No. 44)

(3-pin PWR_FAN1)

(see p.2  No. 1)

29

ASRock  FM2A85X Extreme4  Motherboard

English

Serial port Header

This COM1 header supports a

(9-pin COM1)

                                                                   serial port module.

(see p.2  No. 32)

HDMI_SPDIF Header

HDMI_SPDIF header, providing

(2-pin HDMI_SPDIF1)

SPDIF audio output to HDMI

(

see p.2  No. 33)

VGA card, allows the system to

 connect HDMI Digital TV/

projector/LCD devices. Please

connect the HDMI_SPDIF

connector of HDMI VGA card to

this

header.

ATX 12V Power Connector

Please connect an ATX 12V

(8-pin  ATX12V1)

power supply to this connector.

(see p.2  No. 2)

Though this motherboard provides 8-pin ATX 12V power connector, it can still work

if you adopt a traditional 4-pin ATX 12V power supply. To use the

4-pin ATX power supply, please plug your power supply along with

Pin 1 and Pin 5.

4-Pin ATX 12V Power Supply Installation

4                8

1                5

4                         8

1                         5

30

ASRock  FM2A85X Extreme4  Motherboard

English

2.8  Smart Switches

This motherboard has three smart switches: power switch, reset switch and clear

CMOS switch, allowing users to quickly turn on/off or reset the system or clear the

CMOS values.

Power Switch

Power Switch is a smart switch,

(PWRBTN)

allowing users to quickly turn

(see p.2  No. 22)

on/off the system.

Reset Switch

Reset Switch is a smart switch,

(RSTBTN)

allowing users to quickly reset

(see p.2  No. 20)

the

system.

Clear CMOS Switch

Clear CMOS Switch is a smart

(CLRCBTN)

switch, allowing users to quickly

(see p.3  No. 14)

clear the CMOS values

31

ASRock  FM2A85X Extreme4  Motherboard

English

2.9  Dr. Debug

Dr. Debug is used to provide code information, which makes troubleshooting even

easier. Please see the diagrams below for reading the Dr. Debug codes.

 Status Code

Description

 00

Please check if CPU is installed correctly and then clear CMOS.

 0d

Problem related to memory, VGA card and other devices.

Please clear CMOS, re-install memory and VGA card, and remove other

USB, PCI devices.

 01 - 54

Problem related to memory. Please re-install CPU and memory then clear

 (except 0d),

CMOS.

 5A- 60

If the problem still exists, please install only one memory module or try using

other memory modules.

 55

Memory could not be detected. Please re-install memory and CPU.

If the problem still exists, please install only one memory module or try using

other memory modules.

 61 - 91

Chipset initialization error. Please press reset or clear CMOS.

 92 - 99

Problem related to PCI-E devices. Please re-install PCI-E devices or try

installing them in other slots.

If the problem still exists, please remove all PCI-E devices or try using

another VGA card.

 A0 - A7

Problem related to IDE or SATA devices. Please re-install IDE and SATA

 devices.

If the problem still exists, please clear CMOS and try removing all SATA

 devices.

 b0

Problem related to memory. Please re-install CPU and memory.

If the problem still exists, please install only one memory module or try using

other memory modules.

* For X79 models, please try installing memory to DDR3_A1, B1, C1 and D1

  slots.

 b4

Problem related to USB devices. Please try removing all USB devices.

 b7

Problem related to memory. Please re-install CPU and memory then clear

 CMOS.

If the problem still exists, please install only one memory module or try using

other memory modules.

 d6

VGA could not be recognized. Please clear CMOS and try re-installing the

 VGA

card.

If the problem still exists, please try installing the VGA card in other slots or

using other VGA cards.

 d7

Keyboard and mouse could not be recognized. Please try re-installing

keyboard and mouse.

 d8

Invalid Password.

 FF

Please check if CPU is installed correctly and then clear CMOS.

32

ASRock  FM2A85X Extreme4  Motherboard

English

2.10  Driver Installation Guide

To install the drivers to your system, please insert the support CD to your optical

drive

fi

 rst. Then, the drivers compatible to your system can be auto-detected and

listed on the support CD driver page. Please follow the order from up to bottom side

to install those required drivers. Therefore, the drivers you install can work properly.

STEP 1: Set up UEFI.

A.

Enter UEFI SETUP UTILITY    Advanced screen     Storage

 Con

fi

 guration.

B.

Set the “SATA Mode” option to [IDE].

STEP 2: Install Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit OS on

your system.

Using SATA3 HDDs without NCQ and Hot Plug functions (IDE mode)

2.12  Installing Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

 /

         Vista

TM

 64-bit Without RAID Functions

If you want to install Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit on

your SATA3 HDDs without RAID functions, please follow below steps.

Using SATA3 HDDs with NCQ and Hot Plug functions (AHCI mode)

STEP 1: Set up UEFI.

A.

Enter UEFI SETUP UTILITY    Advanced screen     Storage

 Con

fi

 guration.

B.

Set the “SATA Mode” option to [AHCI].

STEP 2: Install Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit OS on

your system.

2.11  Installing Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

 /

         Vista

TM

 64-bit With RAID Functions

If you want to install Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit

on your SATA3 HDDs with RAID functions, please refer to the document at the

following path in the Support CD for detailed procedures:

..\ RAID Installation Guide
