Alexika HB 10: Maintenance and cleaning

16

The device is maintenance-free.

Cleaning

For cleaning disconnect the main

plug.

Only use cleansing agents which have been recommended by

IKA

®

.

To clean the drive use only water with a detergent that contains

tensides, or use isopropylalcohol for stubborn soiling.

Spare parts order

When ordering spare parts, please give:

- Machine type

- Manufacturing number, see type plate

- Item and designation of the spare part,

  see

www.ika.com

, spare parts diagram and spare parts list.

Maintenance and cleaning

Repair

In case of repair the device has to be cleaned and free from any

materials which may constitute a health hazard. For this use the

"certifi cate of compliance" included or download the form from

the

IKA

®

 website

www.ika.com

.

If you require servicing, return the appliance in its original

packaging. Storage packaging is not suffi  cient. Please also use

suitable transport packaging.

Technical Data

Operating voltage range

Vac

  220 - 240 + 10%

  100 - 120 + 10%

Rated voltage

Vac

  115, 230 - 50/60 Hz

Frequence

Hz

  50 / 60

Power input at nominal voltage

W

  1350

Fuses

  220-240 V T 10 A (5x20)

  100-120 V T 16 A (5x20)

Function Heating

Heating output at nominal voltage

W

  1350

Temperature range medium

°C

  ambient temperature - 180 °C

Temperature indication

  LCD-Display

Heating temperature setting

  +1

Setting accuracy heating temperature

K

  +1

Controller deviation (3l water/ 90 °C)

K

+1

Controller deviation (3l silicone oil/ 50 mPas/

K

+2

150 °C)

Adjustable safety circuit

°C

  50-190

Min. volume bath container

l

  1

Max. volume bath container

l

  3

Materials in contact with medium

  stainless steel  1.4404

Safety circuit

°C

  adjustable

Dimension (W x D x H)

mm

  295 x 265 x190

Weight

kg

 2,8

Safety class

  DIN 12877, Class 2

Protection acc. to DIN EN 60529

  IP 21

Perm. ambient temperature

°C

  5 - 40

Perm. humidity

%

  80

Protection class

  I

Overvoltage category

  II

Contamination level

  2

Operation at a terrestrial altitude

m

  max. 2000 about sea level

Subject to technical changes!
