ASRock FM2A85X Extreme6: 2. Installation

2. Installation: ASRock FM2A85X Extreme6

2. Installation

This is an ATX form factor motherboard. Before you install the motherboard, study

the conguration of your chassis to ensure that the motherboard ts into it.

Pre-installation Precautions

Take note of the following precautions before you install motherboard

components or change any motherboard settings.

Before you install or remove any component, ensure that the

power is switched off or the power cord is detached from the

power supply. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

1. Unplug the power cord from the wall socket before touching any

component.

2. To avoid damaging the motherboard components due to static elec-

tricity, NEVER place your motherboard directly on the carpet or the

like. Also remember to use a grounded wrist strap or touch a safety

grounded object before you handle components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded anti-

static pad or in the bag that comes with the component.

5. When placing screws into the screw holes to secure the mother-

board to the chassis, please do not over-tighten the screws! Doing

so may damage the motherboard.

English

ASRock FM2A85X Extreme6 Motherboard

2.1 CPU Installation

Step 1. Unlock the socket by lifting the lever up to a 90

angle.

Step 2. Position the CPU directly above the socket such that the CPU corner with

the golden triangle matches the socket corner with a small triangle.

Step 3. Carefully insert the CPU into the socket until it ts in place.

The CPU ts only in one correct orientation. DO NOT force the CPU

into the socket to avoid bending of the pins.

Step 4. When the CPU is in place, press it rmly on the socket while you push

down the socket lever to secure the CPU. The lever clicks on the side tab

to indicate that it is locked.

Lever 90° Up

CPU Golden Triangle

Socket Corner Small

Triangle

STEP 1:

STEP 2 / STEP 3:

STEP 4:

Lift Up The Socket Lever

Match The CPU Golden Triangle

Push Down And Lock

To The Socket Corner Small

The Socket Lever

Triangle

2.2 Installation of CPU Fan and Heatsink

After you install the CPU into this motherboard, it is necessary to install a

larger heatsink and cooling fan to dissipate heat. You also need to spray

thermal grease between the CPU and the heatsink to improve heat dis-

sipation. Make sure that the CPU and the heatsink are securely fastened

and in good contact with each other. Then connect the CPU fan to the

CPU FAN connector (CPU_FAN1, see Page 2, No. 5 or CPU_FAN2, see

Page 2, No. 6). For proper installation, please kindly refer to the instruc-

tion manuals of the CPU fan and the heatsink.

English

ASRock FM2A85X Extreme6 Motherboard

2.3 Installation of Memory Modules (DIMM)

This motherboard provides four 240-pin DDR3 (Double Data Rate 3) DIMM

slots, and supports Dual Channel Memory Technology. For dual channel con-

guration, you always need to install identical (the same brand, speed, size

and chip-type) DDR3 DIMM pair in the slots of the same color. In other words,

you have to install identical DDR3 DIMM pair in Dual Channel A (DDR3_A1

and DDR3_B1; see p.2 No.7) or identical DDR3 DIMM pair in Dual Channel

B (DDR3_A2 and DDR3_B2; see p.2 No.8), so that Dual Channel Memory

Technology can be activated. This motherboard also allows you to install four

DDR3 DIMMs for dual channel conguration, and please install identical DDR3

DIMMs in all four slots. You may refer to the Dual Channel Memory Congura-

tion Table below.

Dual Channel Memory Congurations

DDR3_A1 DDR3_A2 DDR3_B1 DDR3_B2

(1) Populated - Populated -

(2) - Populated - Populated

(3)* Populated Populated Populated Populated

For the conguration (3), please install identical DDR3 DIMMs in all four

slots.

1. If you want to install two memory modules, for optimal compatibility

and reliability, it is recommended to install them in the slots: DDR3_

A1 and DDR3_B1, or DDR3_A2 and DDR3_B2.

2. If only one memory module or three memory modules are installed

in the DDR3 DIMM slots on this motherboard, it is unable to activate

the Dual Channel Memory Technology.

3. If a pair of memory modules is NOT installed in the same Dual

Channel, for example, installing a pair of memory modules in

DDR3_A1 and DDR3_A2, it is unable to activate the Dual Channel

Memory Technology .

4. It is not allowed to install a DDR or DDR2 memory module into

DDR3 slot; otherwise, this motherboard and DIMM may be dam-

aged.

English

5. If you adopt DDR3 2600/2400/2133/1866/1600 memory modules

on this motherboard, it is recommended to install them on DDR3_

A2 and DDR3_B2 slots.

ASRock FM2A85X Extreme6 Motherboard

Installing a DIMM

Please make sure to disconnect power supply before adding or

removing DIMMs or the system components.

Step 1. Unlock a DIMM slot by pressing the retaining clips outward.

Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the

break on the slot.

The DIMM only ts in one correct orientation. It will cause permanent

damage to the motherboard and the DIMM if you force the DIMM into

the slot at incorrect orientation.

Step 3. Firmly insert the DIMM into the slot until the retaining clips at both ends

fully snap back in place and the DIMM is properly seated.

English

ASRock FM2A85X Extreme6 Motherboard

2.4 Expansion Slots (PCI and PCI Express Slots)

There are 2 PCI slots and 5 PCI Express slots on this motherboard.

PCI Slots: PCI slots are used to install expansion cards that have the 32-bit PCI

interface.

PCIE Slots:

PCIE1 / PCIE3 (PCIE x1 slot) is used for PCI Express cards with x1

lane width cards, such as Gigabit LAN card and SATA2 card.

PCIE2 / PCIE4 (PCIE x16 slot) is used for PCI Express x16 lane width

graphics cards, or used to install PCI Express graphics cards to support

CrossFireX

function.

PCIE5 (PCIE x16 slot) is used for PCI Express x4 lane width cards, or

used to install PCI Express graphics cards to support 3-Way

CrossFireX

function.

1. In single VGA card mode, it is recommended to install a PCI Ex-

press x16 graphics card on PCIE2 slot.

2. In CrossFireX

mode, please install PCI Express x16 graphics

cards on PCIE2 and PCIE4 slots. Therefore, both these two slots

will work at x8 bandwidth.

3. In 3-Way CrossFireX

mode, please install the PCI Express x16

graphics cards in PCIE2, PCIE4 and PCIE5 slots. PCIE2 and

PCIE4 will work at x8 bandwidth, while PCIE5 works at x4 band-

width.

4. Please connect a chassis fan to motherboard chassis fan connec-

tor (CHA_FAN1, CHA_FAN2 or CHA_FAN3) when using multiple

graphics cards for better thermal environment.

5. When PCIE2 slot is occupied, the DisplayPort cannot be used.

Installing an expansion card

Step 1. Before installing the expansion card, please make sure that the power

supply is switched off or the power cord is unplugged. Please read the

documentation of the expansion card and make necessary hardware

settings for the card before you start the installation.

Step 2. Remove the system unit cover (if your motherboard is already installed

in a chassis).

English

Step 3. Remove the bracket facing the slot that you intend to use. Keep the

screws for later use.

Step 4. Align the card connector with the slot and press rmly until the card is

completely seated on the slot.

Step 5. Fasten the card to the chassis with screws.

Step 6. Replace the system cover.

ASRock FM2A85X Extreme6 Motherboard

2.5 CrossFireX

, 3-Way CrossFireX

and Quad

CrossFireX

Operation Guide

This motherboard supports CrossFireX

, 3-way CrossFireX

and Quad

CrossFireX

feature. CrossFireX

technology offers the most advantageous

means available of combining multiple high performance Graphics Processing

Units (GPU) in a single PC. Combining a range of different operating modes with

intelligent software design and an innovative interconnect mechanism, CrossFireX

enables the highest possible level of performance and image quality in any 3D

application. Please check AMD website for ATI

CrossFireX

driver updates.

1. If a customer incorrectly congures their system they will not see the

performance benets of CrossFireX

. All three CrossFireX

components, a

CrossFireX

Ready graphics card, a CrossFireX

Ready motherboard and a

CrossFireX

Edition co-processor graphics card, must be installed correctly to

benet from the CrossFireX

multi-GPU platform.

2. If you pair a 12-pipe CrossFireX

Edition card with a 16-pipe card, both cards

will operate as 12-pipe cards while in CrossFireX

mode.

2.5.1 Graphics Card Setup

2.5.1.1 Installing Two CrossFireX

-Ready Graphics Cards

Different CrossFireX

cards may require different methods to enable CrossFireX

feature. For other CrossFireX

cards that AMD has released or will release in the

future, please refer to AMD graphics card manuals for detailed installation guide.

Step 1. Insert one Radeon graphics card into PCIE2 slot and the other Radeon

graphics card to PCIE4 slot. Make sure that the cards are properly seated

on the slots.

English

ASRock FM2A85X Extreme6 Motherboard

Step 2. Connect two Radeon graphics cards by installing CrossFire Bridge on

CrossFire Bridge Interconnects on the top of Radeon graphics cards.

(CrossFire Bridge is provided with the graphics card you purchase, not

bundled with this motherboard. Please refer to your graphics card vendor

for details.)

CrossFire Bridge

Step 3. Connect the DVI monitor cable to the DVI connector on the Radeon

graphics card on PCIE2 slot. (You may use the DVI to D-Sub adapter to

convert the DVI connector to D-Sub interface, and then connect the D-Sub

monitor cable to the DVI to D-Sub adapter.)

English

ASRock FM2A85X Extreme6 Motherboard

2.5.1.2 Installing Three CrossFireX

-Ready Graphics Cards

Step 1. Install the identical 3-Way CrossFireX

-ready graphics cards that are

AMD certied because different types of graphics cards will not work to-

gether properly. (Even the GPU chips version shall be the same.) Insert

one graphics card into PCIE2 slot, another graphics card to PCIE4 slot,

and the other graphics card to PCIE5 slot. Make sure that the cards are

properly seated on the slots.

Step 2. Use one CrossFire

Bridge to connect Radeon graphics cards on PCIE2

and PCIE4 slots, and use the other CrossFire

Bridge to connect Radeon

graphics cards on PCIE4 and PCIE5 slots. (CrossFire

Bridge is provided

with the graphics card you purchase, not bundled with this motherboard.

Please refer to your graphics card vendor for details.)

CrossFire

Bridge

Step 3. Connect the DVI monitor cable to the DVI connector on the Radeon graph-

ics card on PCIE2 slot. (You may use the DVI to D-Sub adapter to convert

the DVI connector to D-Sub interface, and then connect the D-Sub monitor

cable to the DVI to D-Sub adapter.)

English

ASRock FM2A85X Extreme6 Motherboard

2.5.2 Driver Installation and Setup

Step 1. Power on your computer and boot into OS.

Step 2. Remove the ATI

driver if you have any VGA driver installed in your

system.

The Catalyst Uninstaller is an optional download. We recommend using this

utility to uninstall any previously installed Catalyst drivers prior to installation.

Please check AMD website for ATI

driver updates.

Step 3. Install the required drivers to your system.

For Windows

8 / 7 / Vista

OS:

Install the CATALYST Control Center. Please check AMD website for de-

tails.

Step 4. Restart your computer.

Step 5. Install the VGA card drivers to your system, and restart your computer.

Then you will nd “ATI Catalyst Control Center” on your Windows

taskbar.

ATI Catalyst Control Center

Step 6. Double-click “ATI Catalyst Control Center”. Click “View”, select “CrossFi-

reX

”, and then check the item “Enable CrossFireX

”. Select “2 GPUs”

and click “Apply” (if you install two Radeon graphics cards). Select “3

GPUs” and click “OK” (if you install three Radeon graphics cards).

English

ASRock FM2A85X Extreme6 Motherboard

Although you have selected the option “Enable CrossFire

”, the CrossFireX

function may not work actually. Your computer will automatically reboot. After

restarting your computer, please conrm whether the option “Enable

CrossFire

” in “ATI Catalyst Control Center” is selected or not; if not, please

select it again, and then you are able to enjoy the benet of CrossFireX

feature.

Step 7. You can freely enjoy the benet of CrossFireX

, 3-Way CrossFireX

Quad CrossFireX

feature.

* CrossFireX

appearing here is a registered trademark of ATI

Technologies Inc., and is

used only for identication or explanation and to the owners’ benet, without intent to infringe.

* For further information of ATI

CrossFireX

technology, please check AMD website for

updates and details.

English

ASRock FM2A85X Extreme6 Motherboard

2.6 Jumpers Setup

The illustration shows how jumpers are

setup. When the jumper cap is placed on

pins, the jumper is “Short”. If no jumper cap

is placed on pins, the jumper is “Open”. The

illustration shows a 3-pin jumper whose

pin1 and pin2 are “Short” when jumper cap

is placed on these 2 pins.

Jumper Setting Description

Clear CMOS Jumper

(CLRCMOS1)

(see p.2, No. 24)

Clear CMOSDefault

Note: CLRCMOS1 allows you to clear the data in CMOS. To clear and reset the

system parameters to default setup, please turn off the computer and unplug

the power cord from the power supply. After waiting for 15 seconds, use a

jumper cap to short pin2 and pin3 on CLRCMOS1 for 5 seconds. However,

please do not clear the CMOS right after you update the BIOS. If you need

to clear the CMOS when you just nish updating the BIOS, you must boot

up the system rst, and then shut it down before you do the clear-CMOS ac-

tion. Please be noted that the password, date, time, user default prole, 1394

GUID and MAC address will be cleared only if the CMOS battery is removed.

1. The Clear CMOS Switch has the same function as the Clear CMOS

jumper.

2. If you clear the CMOS, the case open may be detected. Please adjust

the BIOS option “Clear Status” to clear the record of previous chassis

intrusion status.

English

ASRock FM2A85X Extreme6 Motherboard

2.7 Onboard Headers and Connectors

Onboard headers and connectors are NOT jumpers. Do NOT place

jumper caps over these headers and connectors. Placing jumper caps

over the headers and connectors will cause permanent damage of the

motherboard!

Serial ATA3 Connectors These seven Serial ATA3

(SATA3_1_2: see p.2, No. 12)

(SATA3) connectors support

(SATA3_3_4: see p.2, No. 13)

SATA data cables for internal

(SATA3_7_8: see p.2, No. 14)

storage devices. The current

(SATA3_5: see p.2, No. 15)

SATA3 interface allows up to

6.0 Gb/s data transfer rate.

SATA3_8 SATA3_4 SATA3_2

SATA3_7 SATA3_3 SATA3_1

SATA3_5

Serial ATA (SATA) Either end of the SATA data

Data Cable cable can be connected to the

(Optional)

SATA3 hard disk or the SATA3

connector on this motherboard.

USB 2.0 Headers Besides two default USB 2.0

US B_PWR

P- 1

P+ 1

(9-pin USB_0_1)

ports on the I/O panel, there

GN D

DU MMY

(see p.2 No. 26)

are three USB 2.0 headers on

this motherboard. Each USB 2.0

GN D

P+ 0

P- 0

header can support two USB

US B_PWR

(9-pin USB_2_3)

2.0 ports.

U SB_PWR

P-3

(see p.2 No. 27)

P +3

GND

DUMMY

GND

P +2

P-2

U SB_PWR

(9-pin USB_4_5)

(see p.2 No. 28)

English

ASRock FM2A85X Extreme6 Motherboard

USB 3.0 Header Besides four default USB 3.0

VbusVbus

(19-pin USB3_5_6)

ports on the I/O panel, there is

Vbus

IntA_P6_SSRX-

IntA_P5_SSRX-

IntA_P6_SSRX+

(see p.2, No. 10)

one USB 3.0 header on this

IntA_P5_SSRX+

GND

IntA_P6_SSTX-

motherboard. This USB 3.0

IntA_P5_SSTX-

IntA_P6_SSTX+

header can support two USB 3.0

IntA_P5_SSTX+

GND

IntA_P6_D-

ports.

IntA_P5_D-

IntA_P6_D+

IntA_P5_D+

DUMMY

Infrared Module Header This header supports an

(5-pin IR1)

optional wireless transmitting

(see p.2 No. 23)

and receiving infrared module.

Consumer Infrared Module Header This header can be used to

(4-pin CIR1)

connect the remote

(see p.2 No. 29)

controller receiver.

Front Panel Audio Header This is an interface for the front

GND

P RESENCE#

(9-pin HD_AUDIO1)

M IC_RET

panel audio cable that allows

OUT_RET

(see p.2 No. 33)

convenient connection and

control of audio devices.

O UT2_L

J _SENSE

O UT2_R

M IC2_R

M IC2_L

1. High Denition Audio supports Jack Sensing, but the panel wire on

the chassis must support HDA to function correctly. Please follow the

instruction in our manual and chassis manual to install your system.

2. If you use AC’97 audio panel, please install it to the front panel audio

header as below:

A. Connect Mic_IN (MIC) to MIC2_L.

B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.

C. Connect Ground (GND) to Ground (GND).

D. MIC_RET and OUT_RET are for HD audio panel only. You don’t

need to connect them for AC’97 audio panel.

E. To activate the front mic.

English

For Windows

8 / 8 64-bit / 7 / 7 64-bit / Vista

/ Vista

64-bit OS:

Go to the "FrontMic" Tab in the Realtek Control panel. Adjust

“Recording Volume”.

ASRock FM2A85X Extreme6 Motherboard

System Panel Header This header accommodates

(9-pin PANEL1)

several system front panel

(see p.2 No. 17)

functions.

Connect the power switch, reset switch and system status indicator

on the chassis to this header according to the pin assignments below.

Note the positive and negative pins before connecting the cables.

PWRBTN (Power Switch):

Connect to the power switch on the chassis front panel. You may con-

gure the way to turn off your system using the power switch.

RESET (Reset Switch):

Connect to the reset switch on the chassis front panel. Press the reset

switch to restart the computer if the computer freezes and fails to per-

form a normal restart.

PLED (System Power LED):

Connect to the power status indicator on the chassis front panel. The

LED is on when the system is operating. The LED keeps blinking

when the sys-tem is in S1 sleep state. The LED is off when the system

is in S3/S4 sleep state or powered off (S5).

HDLED (Hard Drive Activity LED):

Connect to the hard drive activity LED on the chassis front panel. The

LED is on when the hard drive is reading or writing data.

The front panel design may differ by chassis. A front panel module

mainly consists of power switch, reset switch, power LED, hard drive

activity LED, speaker and etc. When connecting your chassis front

panel module to this header, make sure the wire assignments and the

pin assign-ments are matched correctly.

Chassis Speaker Header Please connect the chassis

(4-pin SPEAKER 1)

speaker to this header.

(see p.2 No. 21)

Power LED Header Please connect the chassis

(3-pin PLED1)

power LED to this header to

(see p.2 No. 16)

indicate system power status.

English

The LED is on when the system

is operating. The LED keeps

blinking in S1 state. The LED is

off in S3/S4 state or S5 state

(power off).

ASRock FM2A85X Extreme6 Motherboard

Chassis and Power Fan Connectors Please connect the fan cables

(4-pin CHA_FAN1)

to the fan connectors and

(see p.2 No. 22)

match the black wire to the

ground pin. CHA_FAN1/2/3 fan

(3-pin CHA_FAN2)

speed can be controlled through

(see p.2 No. 41)

UEFI or AXTU.

(3-pin CHA_FAN3)

(see p.2 No. 43)

(3-pin PWR_FAN1)

(see p.2 No. 4)

CPU Fan Connectors Please connect the CPU fan

FAN_S PEED_CONTROL

CPU_FAN_SPEED

(4-pin CPU_FAN1)

cable to the connector and

+ 12V

(see p.2 No. 5)

GND

match the black wire to the

ground pin.

1 2 3 4

Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin

CPU fan still can work successfully even without the fan speed control function.

If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this

motherboard, please connect it to Pin 1-3.

Pin 1-3 Connected

3-Pin Fan Installation

(3-pin CPU_FAN2)

GND

+ 12V

(see p.2 No. 6)

CPU_FAN_SPEED

ATX Power Connector Please connect an ATX power

(24-pin ATXPWR1)

supply to this connector.

(see p.2 No. 9)

English

Though this motherboard provides 24-pin ATX power connector,

it can still work if you adopt a traditional 20-pin ATX power supply.

To use the 20-pin ATX power supply, please plug your power

supply along with Pin 1 and Pin 13.

20-Pin ATX Power Supply Installation

ASRock FM2A85X Extreme6 Motherboard

ATX 12V Power Connector Please connect an ATX 12V

4 8

(8-pin ATX12V1)

power supply to this connector.

(see p.2 No. 1)

1 5

Though this motherboard provides 8-pin ATX 12V power connector, it can still work

if you adopt a traditional 4-pin ATX 12V power supply. To use the

4 8

4-pin ATX power supply, please plug your power supply along with

Pin 1 and Pin 5.

4-Pin ATX 12V Power Supply Installation

1 5

Serial port Header This COM1 header supports a

(9-pin COM1)

serial port module.

(see p.2 No. 31)

HDMI_SPDIF Header HDMI_SPDIF header, providing

(2-pin HDMI_SPDIF1)

SPDIF audio output to HDMI

(

see p.2 No. 32)

VGA card, allows the system to

connect HDMI Digital TV/

projector/LCD devices. Please

connect the HDMI_SPDIF

connector of HDMI VGA card to

this header.

Chassis Intrusion Header This motherboard supports

(2-pin CI1)

CASE OPEN detection feature

(see p.2, No. 30)

that detects if the chassis cover

has been removed. This feature

requires a chassis with chassis

intrusion detection design.

XFire Power Connector It is not necessary to use this

(4-pin CROSS_FIRE_PWR1)

connector, but please connect it

(see p.2 No. 42)

with a hard disk power

connecor when two graphics

CROSS_FIRE_PWR1

English

cards are plugged to this

motherboard.

ASRock FM2A85X Extreme6 Motherboard

2.8 Smart Switches

This motherboard has three smart switches: power switch, reset switch and clear

CMOS switch, allowing users to quickly turn on/off or reset the system or clear the

CMOS values.

Power Switch Power Switch is a smart switch,

(PWRBTN)

allowing users to quickly turn

(see p.2 No. 18)

on/off the system.

Reset Switch Reset Switch is a smart switch,

(RSTBTN)

allowing users to quickly reset

(see p.2 No. 20)

the system.

Clear CMOS Switch Clear CMOS Switch is a smart

(CLRCBTN)

switch, allowing users to quickly

(see p.3 No. 14)

clear the CMOS values

English

ASRock FM2A85X Extreme6 Motherboard

2.9 Dr. Debug

Dr. Debug is used to provide code information, which makes troubleshooting even

easier. Please see the diagrams below for reading the Dr. Debug codes.

Status Code Description

00 Please check if CPU is installed correctly and then clear CMOS.

0d Problem related to memory, VGA card and other devices.

Please clear CMOS, re-install memory and VGA card, and remove other

USB, PCI devices.

01 - 54 Problem related to memory. Please re-install CPU and memory then clear

(except 0d), CMOS.

5A- 60 If the problem still exists, please install only one memory module or try using

other memory modules.

55 Memory could not be detected. Please re-install memory and CPU.

If the problem still exists, please install only one memory module or try using

other memory modules.

61 - 91 Chipset initialization error. Please press reset or clear CMOS.

92 - 99 Problem related to PCI-E devices. Please re-install PCI-E devices or try

installing them in other slots.

If the problem still exists, please remove all PCI-E devices or try using

another VGA card.

A0 - A7 Problem related to IDE or SATA devices. Please re-install IDE and SATA

devices.

If the problem still exists, please clear CMOS and try removing all SATA

devices.

b0 Problem related to memory. Please re-install CPU and memory.

If the problem still exists, please install only one memory module or try using

other memory modules.

* For X79 models, please try installing memory to DDR3_A1, B1, C1 and D1

slots.

b4 Problem related to USB devices. Please try removing all USB devices.

b7 Problem related to memory. Please re-install CPU and memory then clear

CMOS.

If the problem still exists, please install only one memory module or try using

other memory modules.

d6 VGA could not be recognized. Please clear CMOS and try re-installing the

VGA card.

If the problem still exists, please try installing the VGA card in other slots or

using other VGA cards.

d7 Keyboard and mouse could not be recognized. Please try re-installing

keyboard and mouse.

d8 Invalid Password.

English

FF Please check if CPU is installed correctly and then clear CMOS.

ASRock FM2A85X Extreme6 Motherboard

2.10 Driver Installation Guide

To install the drivers to your system, please insert the support CD to your optical

drive rst. Then, the drivers compatible to your system can be auto-detected and

listed on the support CD driver page. Please follow the order from up to bottom side

to install those required drivers. Therefore, the drivers you install can work properly.

2.11 Installing Windows

8 / 8 64-bit / 7 / 7 64-bit / Vista

Vista

64-bit With RAID Functions

If you want to install Windows

8 / 8 64-bit / 7 / 7 64-bit / Vista

/ Vista

64-bit

on your SATA3 HDDs with RAID functions, please refer to the document at the

following path in the Support CD for detailed procedures:

..\ RAID Installation Guide

2.12 Installing Windows

8 / 8 64-bit / 7 / 7 64-bit / Vista

Vista

64-bit Without RAID Functions

If you want to install Windows

8 / 8 64-bit / 7 / 7 64-bit / Vista

/ Vista

64-bit on

your SATA3 HDDs without RAID functions, please follow below steps.

Using SATA3 HDDs without NCQ and Hot Plug functions (IDE mode)

STEP 1: Set up UEFI.

A. Enter UEFI SETUP UTILITY Advanced screen Storage

Conguration.

B. Set the “SATA Mode” option to [IDE].

STEP 2: Install Windows

8 / 8 64-bit / 7 / 7 64-bit / Vista

/ Vista

64-bit OS on

your system.

Using SATA3 HDDs with NCQ and Hot Plug functions (AHCI mode)

English

STEP 1: Set up UEFI.

A. Enter UEFI SETUP UTILITY Advanced screen Storage

Conguration.

B. Set the “SATA Mode” option to [AHCI].

STEP 2: Install Windows

8 / 8 64-bit / 7 / 7 64-bit / Vista

/ Vista

64-bit OS on

your system.

ASRock FM2A85X Extreme6 Motherboard

Топ 10 инструкций

100.00

MB QUART DSG 213

99.98

Skil 0790 RA

99.98

Bosch KGN39VW21

99.97

Sony CDX-CA750X RU

99.97

Braun 310 Series 3

99.96

Asus P3-PE5

99.96

Siemens MQ 5 N 298

99.96

YUKON EXTEND LRS-1000

99.96

Bosch GWS 22-230 JH Professional

99.96

Philips Lunettes 3D Active

К рейтингу инструкций и мануалов →

Другие инструкции

ASRock FM2A85X Extreme4-M

Asus P4S800-MX SE

Asus V6-P5G31E

ASRock FM2A85X-ITX

ASRock FM2A85X Extreme6: 2. Installation

2. Installation: ASRock FM2A85X Extreme6

2. Installation

Оглавление

Топ 10 инструкций

Другие инструкции
