ASRock E35LM1 R2.0: 1. Introduction

4

ASRock  E35LM1 R2.0  Motherboard

English

1. Introduction

Thank you for purchasing ASRock

E35LM1 R2.0

motherboard, a reliable mother-

board produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may

fi

 nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock

E35LM1 R2.0

 Motherboard (Mini-ITX Form Factor)

ASRock

E35LM1 R2.0

 Quick Installation Guide

ASRock

E35LM1 R2.0

 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

/

Vista

TM

 64-bit, it is recommended to set the BIOS option in Storage Con-

fi

 guration to AHCI mode. For the BIOS setup, please refer to the “User

Manual” in our support CD for details.

5

ASRock  E35LM1 R2.0  Motherboard

English

1.2 Speci

fi

 cations

 Platform

- Mini-ITX Form Factor

 CPU

- AMD Zacate E-240 APU

- Supports AMD’s Cool ‘n’ Quiet

TM

 Technology

- UMI 2.5 GT/s

 Chipset

- AMD A50M Chipset

 Memory

- 2 x DDR3 DIMM slots

- Supports DDR3 1333(OC)/1066/800 non-ECC, un-buffered

  memory

- Max. capacity of system memory:

16

GB (see

CAUTION 1

)

 Expansion Slot

- 1 x PCI Express 2.0 x16 slot (PCIE1 @ x4 mode)

 Graphics

- Integrated AMD Radeon HD 6310 graphics

- DX11 class iGPU, Pixel Shader 5.0

- Max. shared memory 512MB

- Supports D-Sub with max. resolution up to 2560x1600 @

  60Hz

 Audio

- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

 LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Keyboard/Mouse Port

- 1 x VGA Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- HD Audio Jack: Line in / Front Speaker / Microphone

 SATA3

- 4 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and

  “Hot Plug” functions

Connector

- 4 x SATA3 6.0Gb/s connectors

- 1 x CIR header

- 1 x COM port header

- 1 x Chassis Intrusion header

- 1 x CPU Fan connector (3-pin)

- 2 x Chassis Fan connectors (1 x 4-pin, 1 x 3-pin)

- 24 pin ATX power connector

- Front panel audio connector

6

ASRock  E35LM1 R2.0  Motherboard

English

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature

- 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, FCH, +1V, +1.8V Voltage Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

  Multimedia Suite - OEM, Google Chrome Browser and

Toolbar

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by

  CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- CASE OPEN detection

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

Windows

®

 8 / 8 64-bit / 7 / 7 64-bit / Vista

TM

/

  Vista

TM

 64-bit / XP / XP 64-bit compliant (see

CAUTION 2

)

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

 * For detailed product information, please visit our website: http://www.asrock.com

 WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

 overclocking.

7

ASRock  E35LM1 R2.0  Motherboard

English

CAUTION!

1.  Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage un-

der Windows

®

 8 / 7 / Vista

TM

 / XP. For Windows

®

 OS with 64-bit

CPU, there is no such limitation.

2.  ASRock XFast RAM is not supported by Microsoft

®

Windows

®

XP 64-bit.

8

ASRock  E35LM1 R2.0  Motherboard

English

1.3 Unique Features

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more ef

fi

 cient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows

®

to shorten boot up time. By calling S3 and S4 at speci

fi

 c timing

during the shutdown and startup process, Instant Boot allows

you to enter your Windows

®

 desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS

fl

 ash utility embedded in Flash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems

fi

 rst like MS-

DOS or Windows

®

. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

save the new BIOS

fi

 le to your USB

fl

 ash  drive,

fl

 oppy disk or

hard drive, then you can update your BIOS only in a few clicks

without preparing an additional

fl

 oppy diskette or other compli-

cated

fl

 ash utility. Please be noted that the USB

fl

 ash drive or

hard drive must use FAT32/16/12

fi

 le system.

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock has

prepared a wonderful solution for you - ASRock APP Charger.

Simply install the APP Charger driver, it makes your iPhone

charge much quickly from your computer and up to 40% faster

than before. ASRock APP Charger allows you to quickly charge

many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1),

Suspend to RAM (S3), hibernation mode (S4) or power off (S5).

With APP Charger driver installed, you can easily enjoy the mar-

velous charging experience.

9

ASRock  E35LM1 R2.0  Motherboard

English

ASRock XFast USB

ASRock XFast USB can boost USB storage device perfor-

mance. The performance may depend on the properties of the

device.

ASRock XFast LAN

ASRock XFast LAN provides a faster internet access, which

includes the benefits listed below. LAN Application Prioritiza-

tion: You can con

fi

 gure your application’s priority ideally and/or

add new programs. Lower Latency in Game: After setting online

game’s priority higher, it can lower the latency in games. Traf

fi

 c

Shaping: You can watch Youtube HD videos and download si-

multaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are

transferring currently.

ASRock XFast RAM

ASRock XFast RAM fully utilizes the memory space that cannot

be used under Windows

®

 OS 32-bit CPU. ASRock XFast RAM

shortens the loading time of previously visited websites, mak-

ing web sur

fi

 ng faster than ever. And it also boosts the speed of

Adobe Photoshop 5 times faster. Another advantage of ASRock

XFast RAM is that it reduces the frequency of accessing your

SSDs or HDDs in order to extend their lifespan.

ASRock Crashless BIOS

ASRock Crashless BIOS allows users to update their BIOS

without fear of failing. If power loss occurs during the BIOS up-

date process, ASRock Crashless BIOS will automatically

fi

 nish

the BIOS update procedure after regaining power. Please note

that BIOS

fi

 les need to be placed in the root directory of your

USB disk. Only USB2.0 ports support this feature.

ASRock OMG (Online Management Guard)

Administrators are able to establish an internet curfew or restrict

internet access at speci

fi

 ed times via OMG. You may schedule

the starting and ending hours of internet access granted to other

users. In order to prevent users from bypassing OMG, guest

accounts without permission to modify the system time are re-

quired.

10

ASRock  E35LM1 R2.0  Motherboard

English

ASRock Internet Flash

ASRock Internet Flash searches for available UEFI firmware

updates from our servers. In other words, the system can auto-

detect the latest UEFI from our servers and

fl

 ash them without

entering Windows

®

 OS. Please note that you must be running

on a DHCP con

fi

 gured computer in order to enable this function.

ASRock UEFI System Browser

ASRock UEFI system browser is a useful tool included in

graphical UEFI. It can detect the devices and configurations

that users are currently using in their PC. With the UEFI system

browser, you can easily examine the current system con

fi

 gura-

tion in UEFI setup.

ASRock Dehumidi

fi

 er Function

Users may prevent motherboard damages due to dampness by

enabling “Dehumidi

fi

 er Function”. When enabling Dehumidi

fi

 er

Function, the computer will power on automatically to dehumidi-

fy the system after entering S4/S5 state.

ASRock Fast Boot

With ASRock’s exclusive Fast Boot technology, it takes less

than 1.5 seconds to logon to Windows

®

 8 from a cold boot. No

more waiting! The speedy boot will completely change your user

experience and behavior.

ASRock Restart to UEFI

 Windows

®

 8 brings the ultimate boot up experience. The light-

ning boot up speed makes it hard to access the UEFI setup. AS-

Rock Restart to UEFI technology is designed for those requiring

frequent UEFI access. It allows users to easily enter the UEFI

automatically when turning on the PC next time. Just simply

enable this function; the PC will be assured to access the UEFI

directly in the very beginning.

ASRock Good Night LED

ASRock Good Night LED technology can offer you a better en-

vironment by extinguishing the unessential LED. By enabling

Good Night LED in BIOS, the Power / HDD / LAN LED will be

switched off when system is on. Not only this, Good night LED

will automatically switch off Power and Keyboard LED when the

system enters into Standby / Hibernation mode as well.
