Festool PSB 420 EBQ: Original operating manual1 Symbols 2 Machine features

C A R V E X

13

GB

Original operating manual 1 Symbols 2 Machine features

The specified illustrations appear at the beginning

of the Operating Instructions.

3 Intended use

Jigsaws are designed for sawing wood and similar

materials similar to wood. With the special saw

blades offered by Festool, these machines can also

be used for sawing plastic, steel, aluminium, non-

ferrous metal and ceramic plates.

The user is liable for improper or non-in-

tended use.

4 Technical  data

1

Symbols ................................................

13

2

Machine features..................................

13

3

Intended use.........................................

13

4

Technical data ......................................

13

5

Safety instructions ...............................

14

6

Operation..............................................

15

7

Settings ................................................

15

8

Working with the machine ...................

16

9

Service and maintenance.....................

17

10 Accessories ..........................................

17

11 Environment .........................................

18

12 EU Declaration of Conformity ..............

18

Warning of general danger

Risk of electric shock

Read the Operating Instructions/Notes!

Wear a dust mask.

Wear ear protection.

Wear protective goggles.

Wear protective gloves.

Do not throw in the household waste.

[1-1]

Chip guard

[1-2]

On/Off switch

[1-3]

Variable speed trigger (only PSB 420 EBQ)

[1-4]

Switch lock (only PSB 420 EBQ)

[1-5]

Adjusting wheel for stroke speed control

[1-6]

Swivel plug-it connection (only PS 420

EBQ)

[1-7]

Mains power cable

[1-8]

Extractor connector

[1-9]

Saw table change lever

[1-10]

Saw blade ejection

[1-11]

Replaceable saw table

[1-12]

Pendulum stroke switch

[1-13]

Base runner

Jigsaws

PS 420 EBQ

PSB 420 EBQ

Power

550 W

(110 V version)

400 W

Stroke speed

1500 - 3800 rpm

1000 - 3800 rpm

Stroke length

26 mm

Pendulum stroke

4 steps

max. inclination (only with accessory angle table WT-PS 400)

45° to both sides

max. cutting depth (depending on saw blade)

Wood

120 mm

Aluminium

20 mm

Steel

10 mm

Weight

1,9 kg

Safety class

/II
