5 Play Your Files

" Set your TV’s input to the DMA-1000W’s connection (either HDMI or S-

Video). Remember to change it when you want to use other input.

1 Look at your TV. The DMA-1000W automatically sorts the files on the server into the

MUSIC, VIDEO and PHOTO menus. Files on a USB stick are in the USB menu.

Number of media servers the DMA-1000W detected.

2 Install the remote control’s batteries.

3 Point the remote control at the front of the DMA-1000W.

16

ENGLISH

4 Use the remote control to navigate the menus and play files.

Power switches between

Return to the main

standby and operation

menu.

modes.

Use the 0~9, CLEAR and

INPUT keys to input

numbers (like for

individual scenes or

times).

MUTE turns off the sound.

PAGE up/down scroll up

VOLUME up/down adjust

or down a list to the

the volume.

previous or next page.

AUDIO switches audio

Use the OK, BACK and

output between left, right

arrow buttons to go

and stereo speakers.

through the menus and

play your files.

TOOL opens the TOOL

menu for additional

A-B lets you select start

options (see the User’s

and stop times to repeat

Guide).

an interval.

REPEAT keeps playing

These buttons perform the

(loops) the file.

previous, play, next,

INFO displays details

reverse, stop, fast

about the playing file.

forward, skip, pause and

slow motion functions

SERVER opens a menu

during file playback.

where you select a media

server.

PHOTO opens a menu of

ROTATE turns a photo 90°

picture files to view.

clockwise.

VIDEO opens a menu of

SHUFFLE plays your

video files to play.

playlist (favorites) files in

MUSIC opens a menu of

random order.

music files to play.

OPTION opens the menu

USB opens a menu of files

where you configure the

on your USB device.

DMA-1000W’s settings.

17

ENGLISH

Example of Playing Video Files

1 Press the remote’s VIDEO button to enter the VIDEO menu.

2 The video files are arranged in folders.

The number of the

item currently

selected followed by

the total number of

items in the menu.

Navigation instructions for the menu. In this example, use the arrow and OK buttons to

select a folder to see the video files sorted by that criteria. Or use the BACK button to go

up in the menu structure.

3 In this example, use the

remote’s arrow and OK

buttons to select the All

Videos folder. A list of all the

video files displays on the

right. Information about the

currently selected file

displays on the left.

4 Use the remote’s arrow and

OK buttons to select and play

a video file.

V Files with

unsupported formats

or codecs may not

display properly.

18

ENGLISH

The DMA-1000W supports the following file formats. See the User’s Guide for more

details.

Audio

Dolby Digital, DVD-Audio, MPEG-1 and MPEG-2 Layers I, II and III(MP3), MPEG-

2 BC multi-channel Layers I, II and III, MPEG-2 and MPEG-4 AAC-LC, WMA9.

Video MPEG-1, MPEG-2 MP@ML, MPEG-4 simple and advanced simple profile, MPEG-4 AVI

files and WMV version 9.

Photo TIFF, PNG, GIF, BMP, JPEG and JPEG2000.

Requirements

V If you have trouble installing the media server software, make sure your

computer meets the following requirements.

Microsoft Windows XP Home Edition Service Pack 1 or above, Professional Service Pack 1 or above, or

Media Center Edition 2005 Update Rollup or above.

*You must be logged in as the administrator to install and use the media server.

Software Windows Media Player 9 or above

Microsoft DirectX 9.0 or above

CPU Celeron 1GHz or above, Pentium III or above (Pentium III 1GHz or above

recommended) or compatible

Memory 256MB or above recommended

Peripherals CD-ROM drive

Hard Disk

300MB or above.

Procedure to View a Product’s Certification(s)

1 Go to www.zyxel.com.

2 Select your product from the drop-down list box on

the ZyXEL home page to go to that product's page.

3 Select the certification you wish to view from this

page.
