ASRock  AD2700B-ITX / AD2500B-ITX  Motherboard

English

1. Introduction

Thank you for purchasing ASRock

AD2700B-ITX / AD2500B-ITX

motherboard, a

reliable motherboard produced under ASRock’s consistently stringent quality con-

trol. It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may

fi

 nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock

AD2700B-ITX / AD2500B-ITX

 Motherboard

(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm)

ASRock

AD2700B-ITX / AD2500B-ITX

 Quick Installation Guide

ASRock

AD2700B-ITX / AD2500B-ITX

 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

7

ASRock  AD2700B-ITX / AD2500B-ITX  Motherboard

English

1.2 Specifications

 Platform

- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm

- All Solid Capacitor design (AD2700B-ITX)

- Solid Capacitor for CPU power (AD2500B-ITX)

 CPU

 -

Intel

®

 Dual-Core Atom

TM

 Processor D2700 (2.13 GHz)

  (AD2700B-ITX)

 -

Intel

®

 Dual-Core Atom

TM

 Processor D2500 (1.86 GHz)

  (AD2500B-ITX)

- Supports Hyper-Threading Technology (AD2700B-ITX)

  (see

CAUTION 1

)

 Chipset

- Southbridge: Intel

®

 NM10 Express

 Memory

- 2 x DDR3 SO-DIMM slots

- Supports DDR3 1066/800 non-ECC, un-buffered

  memory

- Max. capacity of system memory: 4GB (see

CAUTION 2

)

 Expansion Slot

- 1 x PCI slot

 Graphics

 -

Intel

®

 PowerVR SGX545

- DirectX 9.0, Pixel Shader 3.0

- Supports D-Sub with max. resolution up to 1920x1200 @

  60Hz

 Audio

- 5.1 CH HD Audio (VIA

®

 VT1705 Audio Codec)

 LAN (AD2700B-ITX)

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 LAN (AD2500B-ITX)

- Realtek PCIE x1 LAN RTL8105E

- Speed: 10/100 Ethernet

- Supports Wake-On-LAN

- Supports PXE

 Rear Panel I/O

I/O Panel

(AD2700B-ITX)

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Parallel Port (ECP/EPP Support)

- 1 x Serial Port: COM1

- 1 x VGA Port

- 2 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

8

ASRock  AD2700B-ITX / AD2500B-ITX  Motherboard

English

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

 Rear Panel I/O

I/O Panel

(AD2500B-ITX)

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Parallel Port (ECP/EPP Support)

- 1 x Serial Port: COM1

- 1 x VGA Port

- 4 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

 USB 3.0

- 2 x USB 3.0 ports by ASMedia ASM1042, support USB

(AD2700B-ITX)

  1.0/2.0/3.0 up to 5Gb/s

Connector

- 2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

  Hot Plug functions

- 1 x IR header

- 1 x CIR header

- CPU/Chassis FAN connector

- 24 pin ATX power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

BIOS Feature

- 16Mb AMI BIOS

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial, ASRock Software Suite

  (CyberLink DVD Suite - OEM and Trial; Creative Sound

  Blaster X-Fi MB - Trial; ASRock MAGIX Multimedia Suite -

  OEM)

 Unique Feature

- ASRock Instant Boot

- ASRock Instant Flash (see

CAUTION 3

)

- ASRock APP Charger (see

CAUTION 4

)

- ASRock SmartView (see

CAUTION 5

)

- ASRock XFast USB (see

CAUTION 6

)

- ASRock XFast LAN (see

CAUTION 7

)

9

ASRock  AD2700B-ITX / AD2500B-ITX  Motherboard

English

 WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

- Hybrid Booster:

    - CPU Frequency Stepless Control (see

CAUTION 8

)

    - ASRock U-COP (see

CAUTION 9

)

    - Boot Failure Guard (B.F.G.)

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU/Chassis Quiet Fan

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

Windows

®

7 32-bit compliant

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

  (see

CAUTION 10

)

 * For detailed product information, please visit our website: http://www.asrock.com

10

ASRock  AD2700B-ITX / AD2500B-ITX  Motherboard

English

CAUTION!

1.  About the setting of “Hyper Threading Technology”, please check page

31 of “User Manual” in the support CD.

2.  Due to the chipset limitation, the actual memory size may be less than

4GB for the reservation for system usage under Windows

®

 OS.

computing performance. Please visit our website for the operation

procedures of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

3.  ASRock Instant Flash is a BIOS

fl

 ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems

fi

 rst like MS-DOS or Windows

®

. With

this utility, you can press the <F6> key during the POST or the <F2>

key to enter into the BIOS setup menu to access ASRock Instant Flash.

Just launch this tool and save the new BIOS

fi

 le to your USB

fl

 ash drive,

fl

 oppy disk or hard drive, then you can update your BIOS only in a few

clicks without preparing an additional

fl

 oppy diskette or other complicated

fl

 ash utility. Please be noted that the USB

fl

 ash drive or hard drive must

use FAT32/16/12

fi

 le system.

4.  If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply install the APP Charger

driver, it makes your iPhone charge much quickly from your computer and

up to 40% faster than before. ASRock APP Charger allows you to quickly

charge many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1), Suspend to

RAM (S3), hibernation mode (S4) or power off (S5). With APP Charger

driver installed, you can easily enjoy the marvelous charging experience.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

5.  ASRock SmartView, a new function for internet browsers, is the smart

start page for IE that combines your most visited web sites, your history,

your Facebook friends and your real-time newsfeed into an enhanced

view for a more personal Internet experience. ASRock motherboards are

exclusively equipped with the ASRock SmartView utility that helps you

keep in touch with friends on-the-go. To use ASRock SmartView feature,

please make sure your OS version is Windows

®

 7, and your browser ver-

sion is IE8.

ASRock website: http://www.asrock.com/Feature/SmartView/index.asp

6.  ASRock XFast USB can boost USB storage device performance. The

performance may depend on the properties of the device.

7.  ASRock XFast LAN provides a faster internet access, which includes

the bene

fi

 ts listed below. LAN Application Prioritization: You can con

fi

 g-

ure your application’s priority ideally and/or add new programs. Lower

Latency in Game: After setting online game’s priority higher, it can lower

the latency in games. Traf

fi

 c Shaping: You can watch Youtube HD videos

and download simultaneously. Real-Time Analysis of Your Data: With

the status window, you can easily recognize which data streams you are

transferring currently.

11

ASRock  AD2700B-ITX / AD2500B-ITX  Motherboard

English

8.  Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause instability of the system or damage the CPU.

9.  While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the moth-

erboard functions properly and unplug the power cord, then plug it back

again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

10.  EuP stands for Energy Using Product, was a provision regulated by the

European Union to de

fi

 ne the power consumption for the completed sys-

tem. According to EuP, the total AC power of the completed system

should be under 1.00W in off mode condition. To meet EuP standards,

an EuP ready motherboard and an EuP ready power supply are required.

According to Intel’s suggestion, the EuP ready power supply must meet

the standard of 5v, and the standby power ef

fi

 ciency should be higher

than 50% under 100 mA current consumption. For EuP ready power sup-

ply selection, we recommend you to check with the power supply manu-

facturer for more details.
