Kenwood DPX404U: Installation/Removing the Unit

This Product is not installed by the manufacturer

Installation/Removing the Unit

of a vehicle on the production line, nor by the

professional importer of a vehicle into an EU

Member State.

⁄

• The frame can be removed from the top

Information on Disposal of Old

side in the same manner.

Electrical and Electronic Equipment and

Batteries (applicable for EU countries

 When the lower level is removed, remove

that have adopted separate waste

the upper two locations.

collection systems)

Products and batteries with the

Removing the Unit

symbol (crossed-out wheeled bin)

 Remove the hard rubber frame by

cannot be disposed as household

referring to the removal procedure in

waste.

the section <Removing the Hard Rubber

Old electrical and electronic

Frame>.

equipment and batteries should be

recycled at a facility capable of

 Insert the two removal tools 2 deeply

handling these items and their waste

into the slots on each side, as shown.

byproducts.

 Lower the removal tool toward the

Contact your local authority for details

bottom, and pull out the unit halfway

in locating a recycle facility nearest to

while pressing towards the inside.

you.

Removal tool

Proper recycling and waste disposal

(Accessory

2)

will help conserve resources whilst

preventing detrimental effects on our

health and the environment.

Notice: The sign “Pb” below the

symbol for batteries indicates

that this battery contains lead.

The marking of products using lasers

CLASS 1

LASER PRODUCT

¤

The label is attached to the chassis/case and says

• Be careful to avoid injury from the catch

that the component uses laser beams that have

pins on the removal tool.

been classified as Class 1. It means that the unit

is utilizing laser beams that are of a weaker class.

 Pull the unit all the way out with your

There is no danger of hazardous radiation outside

hands, being careful not to drop it.

the unit.

English

|

13
