Installation

Connecting the ISO Connector

The pin arrangement for the ISO connectors

depends on the type of vehicle you drive.

Make sure to make the proper connections

to prevent damage to the unit.

The default connection for the wiring

harness is described in 1 below. If the ISO

connector pins are set as described in 2,

make the connection as illustrated.

Please be sure to reconnect the cable as

shown 2 below to install this unit to the

Volkswagen vehicles etc.

Bend the tabs of the mounting sleeve

with a screwdriver or similar utensil

1 (Default setting) The A-7 pin (red) of the

and attach it in place.

vehicle’s ISO connector is linked with

the ignition, and the A-4 pin (yellow) is

⁄

connected to the constant power supply.

• Make sure that the unit is installed

Ignition cable

A-7 Pin

securely in place. If the unit is unstable, it

(Red)

(Red)

may malfunction (for example, the sound

Unit

Vehicle

may skip).

Battery cable

A-4 Pin

Removing the hard rubber frame

(Yellow)

(Yellow)

 Engage the catch pins on the removal

tool 2 and remove the two locks on the

2 The A-7 pin (red) of the vehicle’s ISO

lower level.

connector is connected to the constant

Lower the frame and pull it forward as

power supply, and the A-4 pin (yellow) is

shown in the figure.

linked to the ignition.

Ignition cable

A-7 Pin

(Red)

(Red)

Catch

Lock

Unit

Vehicle

Battery cable

A-4 Pin

(Yellow)

(Yellow)

Removal tool (Accessory

2)
