Contents

Before use

About the Quick Start Guide............... 2

2 WARNING

To prevent injury or fire, take the

Before use .................................................. 2

following precautions:

First step ..................................................... 4

• Stop the car before operating the unit.

Basic Operations ...................................... 5

• To prevent a short circuit, never put or

leave any metallic objects (such as coins

Playing Music (CD/USB/iPod) .............. 6

or metal tools) inside the unit.

Listening to the Radio ........................... 7

¤

CAUTION

Appendix ................................................... 8

• Adjust the volume so that you can hear

sounds outside the car. Driving with the

Installation accessories ......................... 8

volume too high may cause an accident.

Before installation ................................... 9

• Wipe off the dirt on the panel with a dry

silicon or soft cloth.

Connecting Wires to Terminals.........10

Failure to observe this precaution may

Installation/Removing the Unit........12

result in damage to the monitor or unit.”

Condensation

When the car is air-conditioned, moisture

may collect on the laser lens. This may cause

disc read errors. In this case, remove the disc

About the Quick Start

and wait for the moisture to evaporate.

Guide

This Quick Start Guide explains the basic

functions of this unit. For functions

not covered in this Guide, refer to the

Instruction Manual (PDF file) contained in

the included CD-ROM “Instruction Manual”.

To refer to the Instruction Manual contained

in the CD-ROM, a PC loaded with Microsoft®

Windows XP/Vista/7 or Mac OS X® 10.4

or later is required in addition to Adobe®

Reader™ 7.1 or Adobe® Acrobat® 7.1 or later.

The Instruction Manual is subject to

change for modification of specifications

and so forth. You can download the latest

version of the Instruction Manual from

http://manual.kenwood.com/edition/im328.

2

|

Quick Start Guide

B59-2055-00_00_2DIN_E_QSG.indb 2 11/01/19 15:00

Before use

Notes

Handling discs

• If you experience problems during

• Do not touch the recording surface of

installation, consult your Kenwood dealer.

the disc.

• When you purchase optional accessories,

• Do not stick tape etc. on the disc, or use a

check with your Kenwood dealer to make

disc with tape stuck on it.

sure that they work with your model and

• Do not use any accessories for the disc.

in your area.

• Do not use any solvents to clean discs.

• Characters that conform to ISO 8859-1

Use a dry silicon or soft cloth.

can be displayed.

• Clean from the center of the disc and

• Characters that conform to ISO 8859-5

move outward.

or ISO 8859-1 can be displayed. Refer

• When removing discs from this unit, pull

to “Russian”/ “RUSSIAN SET” of <Initial

them out horizontally.

Settings> (page 44)(Instruction Manual).

• Remove the rims from the center hole

• The Radio Data System feature won’t work

and disc edge before inserting a disc.

where the service is not supported by any

How to reset your unit

broadcasting station.

If the unit fails to operate properly, press

• The illustrations of the display and the

the Reset button. The unit returns to factory

panel appearing in this manual are

settings when the Reset button is pressed.

examples used to explain more clearly

how the controls are used. Therefore,

what appears on the display in the

illustrations may differ from what appears

on the display on the actual equipment,

and some of the illustrations on the

display may be inapplicable.

About discs used with this unit

• This unit can only play the CDs with

Reset button

.

• The following discs cannot be used:

- Discs that are not round

- Discs with coloring on the recording

surface or discs that are dirty

- Recordable/Rewritable disc that has

not been finalized (For the finalization

process, refer to your disc writing

software, and your disc recorder

instruction manual.)

- 8 cm (3 inch) disc (Attempt to

insert using an adapter can cause

malfunction.)

English

|

3
