Fieldmann FZP 2001-E: 12. PUTTING INTO SERVICE

21

ENChain and guide lubrication | Putting into service

Oil refill hole for chain lubrication

The model of your chain saw is equipped with the automatic lubrication system.

Control of automatic lubrication system

To check the automatic lubrication system turn the saw on and hold guide approximately

20 cm from a fixed light object. Let the saw run in the medium revolution range; light oil trace

gets created on the light object.

Oil in the tank is sufficient for about 20 minutes of continuous operation.

If you have doubts on lubrication system functionality and even the next steps do not improve

this state, have the saw repaired in an authorized service facility.

- Check whether there is any oil trace left on guide and if this is the case, wipe the oil.

- Check guide groove and if necessary, clean the rest of oil.

Check whether sprocket at saw tip got fouled up. If necessary, clean and lubricate it.

Chain wear control

ATTENTION! Before cleaning or maintenance works always pull the plug out of mains

socket.

ATTENTION! Examine machine properly.

Before each use check whether the chain:

has any rivets and joints broken

is stiffened

has any rivets and links worn out

has tooth length at least 3 mm (1/8“)

Each of such deficiencies indicates chain wear and it should be replaced.

Control of driving sprocket wheel

ATTENTION! Before cleaning or maintenance works always pull the plug out of mains

socket.

ATTENTION! Examine machine properly.

Check driving sprocket wheel regularly. Once it gets significantly worn out, replace it.

12. PUTTING INTO SERVICE

Saw turn on and off

ATTENTION! When turning the saw on, always take up stable posture on flat and solid

base. Saw chain must not touch anything else that just the currently cut wood.

OPERATING INSTRUCTIONSELECTRICAL CHAIN SAW
