Инструкция к Fieldmann FDV 1002-A

FDV 1002-A

CORDLESS DRILLS

OPERATING INSTRUCTIONS

Contents

Cordless Drill

USER'S MANUAL

Thank you for purchasing this cordless drill. Before you start using it, please, carefully

read this user's manual and save it for possible future use.

CONTENTS

ILLUSTRATED ATTACHMENT .............................................................................................................................. 3

1. GENERAL SAFETY REGULATIONS ................................................................................................................. 6

Important safety notices

Packaging

Operating instructions

2. SYMBOLS ................................................................................................................................................................. 8

3. MACHINE DESCRIPTION AND INCLUDED CONTENTS ........................................................................9

Machine description

Supplied contents

4. PUTTING INTO OPERATION ............................................................................................................................. 9

Charging the machine

Drill chuck

Torque control

Turning on/off

5 INSTRUCTIONS FOR PROPER USE ............................................................................................................... 11

Screwing

Drilling

LED Battery charge level indicator light

Lighting of the working area

Overload

More advice about drilling

6. OPERATING INSTRUCTIONS ......................................................................................................................... 12

Operation

Purpose of use

Instructions for use

Electrical safety

Safety instructions for the battery and charger

7. MAINTENANCE AND STORAGE ................................................................................................................. 16

Maintenance

Storage

8. TECHNICAL SPECIFICATIONS .......................................................................................................................18

9. DISPOSAL ............................................................................................................................................................. 19

10. DECLARATION OF CONFORMITY .............................................................................................................. 20

FDV 1002-A

General safety instructions

1. GENERAL SAFETY INSTRUCTIONS

Important Safety Instructions

Read the Instruction Manual attentively before use.

Carefully remove the tool and any accessories from the box. Do not discard any of the packing materials until

all parts are accounted for.

Keep the product in a dry place.

Read all warnings and instructions attentively. Failure to follow all warnings and instructions listed below

may result in electric shock, fire and/or serious personal injury.

Read operator’s manual carefully. Learn its applications and limitations, as well as the specific potential

hazards related to this power tool. Following this rule will reduce the risk of electric shock, fire, or serious

injury.

Check whether the available power supply parameters correspond to the voltage parameters specified on

the tool.

Check whether the power tool and connections are not damaged.

Connect the power cord to the outlet only when the tool is switched off.

Switch on the tool prior you place it on the workpiece.

Take all safety measures to reduce a risk of electric shock. Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and refrigerators.

Sudden temperature changes may result in water condensation on live parts. Prior to use: Let the power tool

reach the workplace room temperature.

Do not use machines, tools and recommended accessories for any than intended purposes!

Clamp the workpiece safely. Secure the workpiece to be drilled in a vice or with clamps to keep it from turning

as the drill bit rotates.

Dress properly. Do not wear loose clothing or jewellery. Loose clothes, jewellery or long hair can be caught in

moving parts. Wear safety shoes and gloves. Contain long hair.

Should dust, chips and sawdust result from your activity or should you work above your head, always wear

safety goggles and dust mask, where appropriate.

While impact drilling, wear suitable ear protective equipment.

While working on ladders, scaffolding or upper floors, always stand on a firm base.

Do not expose power tools to rain or wet conditions. Do not immerse the tool into water.

When operating a power tool outdoors, use an extension cord and other accessories suitable for outdoor

use.

Do not operate power tools in explosive atmospheres.

When the tool is handed over to the third person, the Instruction Manual shall always be included.

The power tool can be repaired only by a qualified specialist and with the original spare parts.

WARNING!

Do not use a power tool while you are tired or under the influence of drugs, alcohol

or medication. A moment of inattention while operating power tools may result in serious personal injury.

Do not use the power tool in any of the following situations.

CORDLESS DRILLS

OPERATING INSTRUCTIONS

General safety instructions

Keep the power tool out of reach of children.

Store idle power tools in the original package in a safe place and out of reach of children.

Disconnect the power cord from the power outlet before making any adjustments, changing accessories, or

storing power tools.

Do not abuse the cord. Never use the cord to carry the charger. Do not pull the cord to disconnect the power

tool from the power source.

When working: Do not let the motor stop if the power tool is loaded.

Keep the workplace clean and tidy. A messy workplace increases a risk of injury!

Do not assume unusual body positions while drilling.

Avoid unintentional power tool switching or startup.

Packaging

The product is placed in a package preventing damage during transport. This package is a raw material

therefore it can be handed-over for recycling.

Instructions for use

Before beginning to work with the machine, read the following safety rules and instructions for use. Familiarize

with operating elements and the proper use of the device. Keep the manual in a safe place for future reference.

We recommend keeping the original package including the inner packaging materials, cash voucher and

guarantee card for a period of warranty at minimum. For a case of transportation, pack the machine into the

original box from the manufacturer, thus ensuring a maximum protection of the product during a possible

transport (e.g. moving or sending into a service station).

Note:

If you hand the machine over to next persons, hand it over together with the manual. Adherence to

the attached instructions for use is a precondition for the proper use of the machine. The operation manual

includes also instructions for operation, maintenance and repairs.

The manufacturer does not take any responsibility for accidents or damages resulting from

the failure to adhere to this manual.

FDV 1002-A

Symbols

2. SYMBOLS

OPERATING INSTRUCTIONS

ELECTRICAL ANGLE GRINDER

Symbols

2. SYMBOLS

Double-insulated.

Read the Instruction Manual

attentively prior to use.

The product complies with the applicable

standards and regulations.

Use eyes protective equipment

Use ears protectiove equipment

Thread of jig.

OPERATING INSTRUCTIONS

ELECTRICAL ANGLE GRINDER

Symbols

2. SYMBOLS

Double-insulated.

Read the Instruction Manual

attentively prior to use.

The product complies with the applicable

standards and regulations.

Use eyes protective equipment

Use ears protectiove equipment

Thread of jig.

OPERATING INSTRUCTIONS

ELECTRICAL ANGLE GRINDER

Symbols

2. SYMBOLS

Double-insulated.

Read the Instruction Manual

attentively prior to use.

The product complies with the applicable

standards and regulations.

Use eyes protective equipment

Use ears protectiove equipment

Thread of jig.

CORDLESS DRILLS

OPERATING INSTRUCTIONS

Machine description and included contents | Putting into operation

3. MACHINE DESCRIPTION

AND INCLUDED CONTENTS

Machine description

(see pic. 1)

Keyless chuck

Torque setting ring

Rotation direction switch for movement forward/back and neutral position safety switch

Trigger switch

Handle

Battery charge level LED display and lighting of the working area

Battery

H) 2 speed switch

Machine description

(see pic. 2)

Battery adapter

Charger station with battery charging indicator (point. 3, 4)

Battery

Supplied contents

Carefully take the machine out of the packaging and check whether all the following parts are present:

Cordless drill with battery

Battery charger station

Bit - 1 pc

User's manual

If there are parts missing or they are damaged, please contact the vendor from whom you bought the machine.

4. PUTTING INTO OPERATION

Charging the machine

Proceed step by step according to the user's manual and use the pictures as a guide so that the assembly

process is as easy as possible.

Take the battery out of the machine, press the release button and pull down to remove the battery.

Place the charger on a table near a power socket.

Properly insert the battery into the charger.

Note:

The battery may be inserted into the charger only in one way.

Connect the charger power cord to a power socket. At this time both the red and the green indicator light will

be on.

FDV 1002-A

Putting into operation

As soon as the battery is fully charged, the green indicator light will stay on and the red indicator light will

turn off.

After fully charging, disconnect the charger from the power socket. Before fi rst use the battery must be fully

charged.

For the fi rst charge, it is recommended to charge the batter for 3 -5 hours.

Drill chuck

(see pic. 3)

If you wish to open up the drill chuck, hold the rear part of the chuck and turn the front part of the chuck

anticlockwise. Insert the desired tool into the chuck. When tightening turn the front part of the chuck (while

holding the rear part) clockwise and ensure that the jaws of the chuck fi rmly and evenly clamp the working tool.

Torque control

(see pic. 4)

1. Torque control is ideal for presetting screwing strength. There are 19 positions + 1 drilling position. These

positions are selected by turning the setting ring. Low values are intended for small screws and soft

materials. High values are intended for large screws and hard materials.

2. If the torque control is used the clutch will work in the preset setting. This is ideal for repeat screwing, when

all screws need to be screwed in at the same distance.

3. It is appropriate to start with the lowest setting and increase the amount of torque until the desired setting is

achieved.

Turning on/off

(see pic. 5)

ATTENTION:

Start or release the start switch carefully according to the manufacturer's instructions.

Turn on the charged machine using the trigger switch (no. 1). The On indicator will appear on the LED display.

Turn off the machine by releasing the switch, the chuck will stop turning.

1. Ensure that a battery is connected to the tool.

2. Start the tool by pressing the trigger switch.

3. The pressure applied to the power trigger switch determines the operating rotation speed of the chuck. The

higher the pressure exerted on the trigger switch, the higher the rotation speed of the chuck.

4. If you want the chuck to rotate forwards, push the forward/back direction switch (no. 2) to the left. If you want

the chuck to rotate backwards, push the forward/back direction switch to the right..

5. If the drill is not being used, set the forward/back direction switch (no. 2) to the neutral position (in the

middle), to prevent accidentally starting the drill.

Ensure that the bit or extension piece is correctly seated.

The bit/extension piece must be placed directly on the workpiece before the drill is turned on. Otherwise the

workpiece or the bit/extension piece will be damaged.

Always check the rotation direction of the bit before using.

The braking system is activated automatically after the trigger switch is released. The drill chuck will

automatically stop rotating.

CORDLESS DRILLS

OPERATING INSTRUCTIONS

Instructions for proper use

5. INSTRUCTIONS FOR PROPER USE

Fully charge the battery before fi rst use. Ensure that the used drill bits and extension pieces are designed for

the given task and that they are securely fastened. Check that the direction switch is set in the position for the

desired rotation direction.

NOTE:

Always ensure that the battery is removed before changing working tools or before performing

adjustments.

ATTENTION:

Dust created during grinding, cutting, drilling and other work tasks may in some

cases contain chemical substances, which are known to cause health problems. Some examples

of these chemical substances are:

a) Lead from lead-containing paints.

b) Cement and other construction products.

c) Chemically treated wood.

Screwing

1. An appropriate opening should be drilled into the workpiece before screws are screwed into wood. This will

prevent the movement of the screw and tool on the surface of the workpiece, which could damage it.

2. We recommend that for screwing you use slow rotation speeds.

3. Insert the screwing bit into the head of the screw and carefully screw it into the opening.

4. We recommend tightening using the lowest torque value and to gradually increase the torque value until the

desired torque level is achieved.

Drilling

1. Do not use the torque control when drilling into wood. Select the standard drilling position.

2. When drilling into wood use wood drilling bits.

3. When drilling into metals or plastics use metal drilling bits.

4. When drilling into soft wood the drill should run at maximum speed.

5. When drilling into hard wood the drill should run at a lower speed.

LED Battery charge level indicator light

(see pic. 6)

The LED indicator light is used to show the battery charge level. When the tool is turned on by the trigger switch

the LED light (no. 2) comes on. If all the LED diodes are on, the battery is suffi ciently charged. If only a single LED

diode is on, the battery is virtually fl at and must be charged immediately.

Lighting of the working area

(see pic. 6)

The LED lighting (no. 1) is turned on when the trigger button is pressed and lights up the area that is being drilled

or screwed. Turning off the trigger switch also turns off the LED lighting of the working area.

FDV 1002-A

Instructions for proper use | Operating instructions

More advice about drilling

1. We recommend to secure the workpiece to the workbench so that you achieve the best results and safely

operate the tool.

2. Use only sharpened drill bits. Blunt drill bits put an unnecessary load on the drill and may cause the motor to

burn.

3. Always ensure that you are using the correct working tool for the task being performed.

4. When performing high precision drilling it is best to use a drill bit with a guiding rod. Non-ferrous materials

like thin metal sheets are very diffi cult to drill. When performing high precision drilling place a piece of wood

underneath the drilled material and then drill an opening through both pieces of material.

ATTENTION:

When drilling it is not unusual for the drill bit to jam. In such a case there is a large momentum

reaction. Always pay attention to what you are doing and hold the drill fi rmly to prevent possible damage or

injury.

ATTENTION:

Do not hold the trigger button down in the on position using adhesive tape or by other means.

The electrical circuit in the tool would not work correctly, which could lead to overheating and subsequent

damage to the tool.

Overload

If the tool becomes overloaded, the motor may be damaged. Increased pressure on the tool will not result in

speeding up work. The effect of greater pressure on the tool will only lower effectiveness, which may cause the

battery to go fl at prematurely and may also destroy the motor. Non-standard types of work and the effect of

excessive pressure will shorten the operating lifetime of the tool.

6. OPERATING INSTRUCTIONS

Operation

This product must not be used by children and persons with physical or mental impairments or by

inexperienced persons, unless properly trained or schooled in the safe use of the product, or unless they

have been properly supervised by a qualifi ed person who will be responsible for their safety.

Use extra care if the product is used near children. Always keep the appliance out of reach of children.

Children must be supervised to ensure that they do not play with the product.

Never allow children or persons who do not know the contents of this user's manual to work with the device.

Local regulations may set the minimum age of the user. The user is responsible for damages caused to third

parties in the machine's working area as a result of its use.

Do not use the machine if your are tired, under the infl uence of alcohol or narcotics.

If necessary, use personal protection aids (gloves, work footwear, eye protection, respirators, etc.). Personal

protection aids reduce the risk of injury to persons.

Dress appropriately. Do not wear loose clothing or jewellery and make sure that your hair, clothing or gloves

do not come dangerously close to moving parts. Loose clothing, jewellery or long hair may become caught

in the moving parts.

CORDLESS DRILLS

OPERATING INSTRUCTIONS

Operating instructions

Pay constant attention, watch what your are doing and think when working with power tools. Do not use

power tools if you are tired or under the infl uence of drugs, alcohol or medication. A moment of carelessness

when working with power tools may lead to serious injury.

Prevent the situation where the tool is turned on accidentally. Ensure the trigger switch is in the Off position

before connecting the power cord to the power socket. Carrying power tools with the fi nger on the main

trigger switch or connecting the power cord to the power socket when the main trigger switch is in the On

position may cause injury.

Do not get in your own way. When working, always maintain a fi rm posture and balance. This will make it

possible to better control the power tool in unexpected situations.

Use clamps or a vice to fasten the workpiece. It is safer than holding the workpiece in your hand and at the

same time you have both hands free to operate the tool.

Keep the working area tidy and well illuminated. A cluttered and badly lit work area may lead to injury.

Do not work with the power tool in an explosive environment, such as for example areas where there are fl

ammable liquid, gas or powder substances. Sparks are made inside the power tool, which may cause the

ignition of fl ammable powder or vapour.

Do not work with materials containing asbestos. Use a dust mask.

When working with the tool ensure there is a safe distance from children and other persons. Distractions

may lead to a loss of control over the tool.

Purpose of use

This tool is not designed for professional use.

Do not use the product for purposes other than those intended.

For safety reasons the machine must not be used as a drive engine for any other work tools and tool sets,

unless expressly permitted by the manufacturer.

Instructions for use

Turn on and operate the machine as described in the user's manual, carefully follow all instructions.

Before carrying out any kind of inspection, maintenance or repairs disconnect the charger power cable from

the mains power supply.

Use tools in good working condition for tasks for which they are designed.

Work only during good visibility or ensure suffi cient artifi cial lighting.

Work in a clean and tidy working environment.

Make sure that while working you maintain a fi rm and stable stance. Do not forget that falls represent one of

the major causes of injuries during accidents.

When drilling metal sheets use a vice and place a piece of wood underneath the sheet. A rotating metal sheet

presents a serious risk.

Make sure that the drill or screwdriver are not used for work on items under live current, to prevent injury by

electrical shock. Before using this tool, check that you know the location of all electrical conductors or cables

in the wall (use a metal detector for this purpose).

Only store and use the product away from fl ammable or volatile materials and solutions.

Keep the product away from extreme temperatures, direct sunlight and excessive humidity. Do not use in a

dusty environment.

FDV 1002-A

Operating instructions

Do not place the product near heaters, open fi res or other appliances or equipment that are sourcesof heat.

Do not spray the product with water or any other liquid. Do not pour water or any other liquids into the

appliance. Do not submerge the appliance in water or any other liquid.

Never leave the appliance switched on without supervision.

Do not touch machine parts until they have come to a complete stop.

Allow the motor to cool down before storing the machine in a closed room.

Under no circumstances should you repair or alter the product yourself. Entrust all repairs and adjustments of

this product to an authorised service centre or the vendor. Tampering with the appliance during the warranty

period may void the warranty.

The manufacturer is not responsible for damages caused by incorrect use of this product or its accessories.

Such damages include food spoilage, injuries, burns, scalding, fi re, etc.

Electrical safety

ATTENTION:

Read all the safety warnings and all instructions. If you fail to follow the provided warnings and

instructions an injury caused by electrical shock could occur as well as fi re or serious injuries.

NOTE:

Keep these warnings and instructions for future use. The term "electric power tool" in all warnings

relates to your tool powered from the mains (it has a power cord installed) or cordless tools (without a

power cord).

The charger of the cordless device can be connected to any power plug, preventing discharge, that is

installed according to norms in force.

The plug must be powered at 230V ~50Hz.

Disconnect the charger if you will not be using it for a long time, if you are changing the tool or performing

maintenance on the tool.

The power plug on the tool's charger cord must correspond to the power socket. Never modify the power plug

in any way. Do not use any power plug adapters for tools protected by grounding. Unmodifi ed power plugs

and corresponding power sockets reduce the risk of injury by electrical shock.

Do not touch grounded surfaces such as pipes, heaters, electrical stoves and refrigerators when working

with the machine. When your body is grounded the risk of injury by electrical shock is increased.

Do not expose the electrical tool to rain or a moist environment. The entry of water into the electrical tool

increases the risk of injury by electrical shock.

Handle the power cord with care. Never use the power cord to carry or move the tool and do not pull on it

when you want to disconnect the tool from the power grid. Prevent the tool coming into contact with greasy,

hot and sharp items or moving parts. A damaged or tangled up power cord increases the risk of injury by

electrical shock.

When working with electric power tools in a moist environment, the power circuit must have current

protection installed (RSD - Residual Current Device). The use of a residual current device reduces the risk of

injury by electrical shock.

CORDLESS DRILLS

OPERATING INSTRUCTIONS

Operating instructions

Safety instructions for the battery and charger

Use only the battery and charger supplied with this tool.

Connect the charger only to a mains power socket with a voltage of 230V.

Protect the battery and charger from moisture. Do not use the device in an outdoor environment.

Disconnect the charger from the mains power socket when the charger is not being used, before cleaning the

charger or before performing repairs on it.

Take special care of the battery. Prevent the battery from falling on to a hard surface and do not expose the

battery to the effects of pressure or other excessive mechanical stress. Keep the battery at a safe distance

from excessive heat or cold.

Do not attempt to repair or disassemble the battery or the charger. If any part is damaged, have it repaired by

a qualifi ed technician or send it for repair to an authorised service centre or the vendor.

Charge the battery only when the ambient air temperature is between 10°C and 40°C. A charged battery

may be used to power tools in operating conditions at a temperature between 0°C and 50°C. If the battery is

not being used store it in a dry place at a temperature between 10°C and 30°C.

IMPORTANT! DANGER!

Never short circuit the battery contacts and do not expose the battery to moisture.

Do not store the battery together with metal items and parts, which could cause a short circuit of the battery

contacts. The battery could overheat, catch on fi re or explode.

If any person comes into contact with the electrolyte or another liquid or substance found in the battery, they

must immediately wash this substance away with large amounts of water. If these substances come into

contact with eyes, fl ush the eyes out with large amounts of water and immediately seek medical treatment.

Do not throw rechargeable batteries into a fi re or into water. Otherwise an explosion could occur. A

rechargeable battery should not be thrown out with ordinary household waste, regardless of the fact whether

it has or has not been used. In accordance with valid regulations you should take the battery to a collection

point or put it into the container labelled "Used Batteries" in our store.

Only charge the battery in a charger designated by the manufacturer. A charger appropriate for one type of

battery creates a fi re hazard when used with another type of battery.

Only use the electric power tool with a battery intended to be used in it. The use of different batteries may lead

to a risk of injury or a fi re hazard.

If you are not using the battery, store it away from metal items, such as paper clips, coins, keys, nails, screws

or other small items, which could lead to the short circuit of the battery contacts. Short circuiting the battery

contacts may cause burns or a fire.

FDV 1002-A

Mainetance and storage

7. MAINTENANCE AND STORAGE

Maintenance

ATTENTION:

Disconnect the charger if you will not be using it for a long time, if you are changing

the tool or performing maintenance on the tool.

This tool does not require any special maintenance. The same applies to the electrical parts of the tool.

Check whether the device is showing signs of wear.

If the charger is damaged (cover, conductors or connector), immediately arrange its replacement at the

vendors service centre.

Regular care for the machine will ensure not only a long lifetime and performance.

Before use always visually check for worn or damaged parts.

Replace damaged or worn parts. To ensure that the machine always remains balanced, always replace the

entire set of the worn or damaged tools.

Worn or damaged machine parts may only be replaced at an authorised service centre or the vendor.

Before cleaning disconnect this product from the power source.

To clean the plastic parts of the product, use a soft cloth dipped in lukewarm water. Do not use aggressive

cleaning products and solvents as this could damage the surface of the appliance.

Do not clean the machine under running water or submerge under water.

After changing the working tool, check that the working tool is secured in its storage position.

Do not use working tools that are not proportioned for placement into the tang in the magazine.

Do not overload the electric power tool. Use the right type of electric power tool for your work. When the

correct electric power tool is used, the work result will be performed better and more safety.

I f it is not possible to turn the main trigger switch on or off, do not work with the tool. All electric power tools

with a trigger switch that do not work are dangerous and must be repaired.

If you are not working with the tool, store it out of the reach of children and prevent persons not informed

about the operation of the tool or this user's manual to work with the tool. An electric power tool in the hands

of an unqualifi ed person is dangerous.

Perform maintenance on the tool. Check for deviation or blockage of the moving parts, damage of individual

parts and other factors which could affect the operation of the tool. If the tool is damaged, have it repaired

before using it. Many accidents are caused by neglected maintenance of a tool. Properly maintained cutting

tools with sharp cutting edges are less prone to jamming in a workpiece and are easier to handle.

Maintain cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less

prone to jamming in a workpiece and are easier to handle.

Use electric power tools, accessories, working tools, etc. according to these instructions in a manner

appropriate for the given type of electric power tool and take into consideration the work conditions and the

type of work that you will be performing.Using electric power tools for purposes other than those for which

they were designed may be dangerous.

Damaged switches must be replaced at an authorised service centre or the vendor. Do not use electric

power tools that cannot be turn on and off.

Do not leave electric power tools turned on without supervision. Always turn the tool off and wait for it to

come to a complete stop before putting it down.

CORDLESS DRILLS

OPERATING INSTRUCTIONS

Mainetance and storage

Use hearing protection. Excessive noise levels may cause hearing damage.

When performing tasks, where the working tools may come into contact with hidden electrical conductors,

hold the electric power tool by the insulated part that is intended to be held. A work tool that comes into

contact with a "live" electrical conductor, will cause the uninsulated parts of the tool to become live and may

subsequently cause injury by electrical shock to the operator.

For repairs contact an authorised service centre or vendor who will use original spare parts. This will ensure

the correct operation of the electric power tool.

ATTENTION:

Using any accessories or tools not recommended in this user's manual may increase the

risk of injury. Always use only original spare parts.

Clean the tool after the completion of every work task.

Do not use worn or damaged drill bits and drilling extension pieces. Such tools may overload the motor and

lower effectiveness.

Take proper care to prevent the motor from damage by oil or water.

Regularly check that the tool has not been damaged during the course of standard operation. Make sure that

all parts are correctly connected and do not use this product if any of its parts has been damaged or lost.

When inserting the battery into the charger, ensure that the battery is inserted in the correct manner and that

there are no materials between the battery contacts, e.g. soils.

The battery and the charger should be protected from heat and the sun. Do not expose these products to

extreme temperatures.

Do not use the device in an outdoor environment.

Use only the charger supplied with this tool.

If the product is damaged or malfunctions, contact an authorised service centre or the vendor.

Storage

Store the tool in a dry location at a suffi cient distance from heat sources or dangerous vapours.

Do not place any other items on the machine.

FDV 1002-A

Disposal

8. TECHNICAL SPECIFICATIONS

Cordless Drill:

Nominal voltage

14.4V

Idling speed

0 - 400 / 0 - 1400rpm

Battery

1.3Ah, Li-ion

Torque

19 positions + 1 drilling position

Max. diameter

Ø13mm

Level of acoustic pressure

68.23dB, K = 3dB

Level of acoustic power

79.23dB, K = 3dB

Charger:

Input voltage

230V

Frequency

50Hz

Charging time

1 - 1.5hours

Amendments to text and technical parameters are reserved.

Changes in the text, design and technical specifi cations may change without prior notice and we reserve the

right to make these changes.keep it from turning as the drill bit rotates.

CORDLESS DRILLS

OPERATING INSTRUCTIONS

Technical specifications

9. DISPOSAL

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING

MATERIALS

Dispose of packaging material at a public waste disposal site.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES

The meaning of the symbol on the product, its accessory or packaging indicates that this

product shall not be treated as household waste. Please, dispose of this product at your

applicable collection point for the recycling of electrical & electronic equipment waste.

Alternatively in some states of the European Union or other European states you may return

your products to your local retailer when buying an equivalent new product. The correct

disposal of this product will help save valuable natural resources and help in preventing the

potential negative impact on the environment and human health, which could be caused as a

result of improper liquidation of waste. Please ask your local authorities or the nearest waste

collection centre for further details. The improper disposal of this type of waste may fall subject

to national regulations for fines.

For business entities in the European Union

If you wish to dispose of an electrical or electronic device, request the necessary information

from your seller or supplier.

Disposal in other countries outside the European Union

If you wish to dispose of this product, request the necessary information about the correct

disposal method from local government departments or from your seller.

This product meets all the basic EU regulation requirements that relate to it.

Changes to the text, design and technical specifi cations may occur without prior notice and we reserve the

right to make these changes.

FDV 1002-A

Declaration of conformity

10. DECLARATION OF CONFORMITY

Product / Name:

CORDLESS DRILL / FIELDMANN

Type / Model:

FDV 1001-A / FDV 1002 - A .....................................................................................14.4V DC / 1300mAh

The product complies with the following directives:

The Directive of the European Parliament and the Council No. 2006/95/EC dated 12 December 2006 on the

harmonisation of the laws of Member States relating to electrical equipment designed for use within certain

voltage limits.

The Directive of the European Parliament and the Council No. 2004/108/EC dated 15 December 2004 on

the harmonisation of the laws of the Member States relating to electromagnetic compatibility and repealing

Directive No. 89/336/EEC.

The Directive of the European Parliament and the Council No. 2006/42/EC dated 17 May 2006 on machinery,

and amending Directive No. 95/16/EC.

The Directive of the European Parliament and the Council No. 2002/95/EC dated 27 January 2003 on the

restriction of the use of certain hazardous substances in electrical and electronic equipment.

and standards:

EN 60745-1:2006

EN 60745-2-2:2007

EN 60745-2-1:2007

EN 55014 -1:2006

EN 55014-2:1997/+A1:2001-1:2006

EN 6000-6-3:2007-1:2006

CE Certification

...............................................................................................................................................................

FAST ČR, a.s. is authorised to act on behalf of the manufacturer.

Manufacturer:

FAST ČR, a.s.

Černokostelecká 2111, 100 00 Praha 10, Czech Republic

Tax ID:: CZ26726548

In Prague, 23 May 2013

Name: Zdeněk Pech

Chairman of Board

Signature and Stamps
