ASRock  H67M-ITX/HT / H67M-ITX  Motherboard

English

WiFi-802.11n Module and ASRock WiFi 2.4GHz Antenna (H67M-ITX/HT)

WiFi-802.11n module is an easy-to-use wireless local area network (WLAN) adapter

to support WiFi function. With WiFi-802.11n module, you can easily create a

wireless environment and enjoy the convenience of wireless network

connectivity. Therefore, from anywhere within the signal range, you will be able to

play LAN games, connect to the internet, access and share printers, and make

Internet phone calls easily.

WiFi-802.11n Module

Antenna Ports

ASRock WiFi 2.4GHz Antenna

8

ASRock  H67M-ITX/HT / H67M-ITX  Motherboard

English

WiFi-802.11n module supports

Station mode

. You can use the wireless function to

connect the access point (AP), or connect with other stations in the wireless range

instead. There are two choices provided in station mode:

Infrastructure mode

and

Ad-hoc mode

. Please read below introduction for the differences of these two

modes.

Infrastructure Mode

If you have a present access point (AP) in your wireless network environment for

this station to join, you can set up WiFi-802.11n module in Infrastructure mode. In

this mode, WiFi-802.11n module acts as a wireless adapter. In other words, it is

centered on an AP that provides Internet access and LAN communication for the

wireless stations, such as PC, notebook and other devices.

Ad-hoc Mode

If you don’t have a present access point in your wireless network environment, you

can set up WiFi-802.11n module in Ad-hoc mode. The wireless network brings

together workstations, PC, notebook and other devices for wireless communication.

* The transmission speed may vary according to the environment.
