ASRock B75M R2.0: 1. Introduction

4

ASRock  B75M R2.0  Motherboard

1.  Introduction

Thank you for purchasing ASRock

B75M R2.0

motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may

fi

 nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1  Package Contents

ASRock

B75M R2.0

 Motherboard

(Micro ATX Form Factor: 9.6-in x 8.4-in, 24.4 cm x 21.3 cm)

ASRock

B75M R2.0

 Quick Installation Guide

ASRock

B75M R2.0

 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

English

ASRock Reminds You...

To get better performance in Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-

bit, it is recommended to set the BIOS option in Storage Con

fi

 guration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

5

ASRock  B75M R2.0  Motherboard

English

1.2  Specifications

 Platform

- Micro ATX Form Factor: 9.6-in x 8.4-in, 24.4 cm x 21.3 cm

- All Solid Capacitor design

 CPU

- Supports 3

rd

 and 2

nd

 Generation Intel

®

 Core

TM

 i7 / i5 / i3 in

  LGA1155 Package

- Supports Intel

®

 Turbo Boost 2.0 Technology

- Supports Hyper-Threading Technology (see

CAUTION 1

)

 Chipset

- Intel

®

 B75

- Supports Intel

®

 Small Business Advantage (see

CAUTION 2

)

- Supports Intel

®

 Rapid Start Technology and Smart Connect

Technology

 Memory

- Dual Channel DDR3 Memory Technology (see

CAUTION 3

)

- 2 x DDR3 DIMM slots

- Supports DDR3 1600/1333/1066 non-ECC, un-buffered

  memory (DDR3 1600 with Intel

®

 Ivy Bridge CPU, DDR3

  1333 with Intel

®

 Sandy Bridge CPU)

- Max. capacity of system memory: 16GB (see

CAUTION 4

)

- Supports Intel

®

 Extreme Memory Pro

fi

 le (XMP)1.3/1.2

 Expansion Slot

- 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)

  (see

CAUTION 5

)

  * PCIE 3.0 is only supported with Intel

®

 Ivy Bridge CPU. With

    Intel

®

 Sandy Bridge CPU, it only supports PCIE 2.0.

- 1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode)

- 2 x PCI slots

- Supports AMD Quad CrossFireX

TM

 and CrossFireX

TM

 Graphics

 *

Intel

®

 HD Graphics Built-in Visuals and the VGA outputs can

  be supported only with processors which are GPU

  integrated.

- Supports Intel

®

 HD Graphics Built-in Visuals: Intel

®

 Quick

  Sync Video 2.0, Intel

®

 InTru

TM

 3D, Intel

®

 Clear Video HD

  Technology, Intel

®

 Insider

TM

, Intel

®

 HD Graphics 2500/4000

- Pixel Shader 5.0, DirectX 11 with Intel

®

 Ivy Bridge CPU.

  Pixel Shader 4.1, DirectX 10.1 with Intel

®

 Sandy Bridge CPU

- Max. shared memory 1760MB (see

CAUTION 6

)

- Three VGA Output options: D-Sub, DVI-D and HDMI

(see

CAUTION 7

)

- Supports HDMI 1.4a Technology with max. resolution up to

  1920x1200 @ 60Hz

- Supports DVI with max. resolution up to 1920x1200 @ 60Hz

6

ASRock  B75M R2.0  Motherboard

English

- Supports D-Sub with max. resolution up to 2048x1536 @

  75Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

  HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

  monitor is required) (see

CAUTION 8

)

- Supports HDCP function with DVI and HDMI ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

  with DVI and HDMI ports

Audio

- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

 LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x HDMI Port

- 4 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

 SATA3

- 1 x SATA3 6.0 Gb/s connector by Intel

®

 B75, supports NCQ,

  AHCI and Hot Plug functions

- 2 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061,

  support NCQ, AHCI and Hot Plug functions

 USB3.0

- 2 x Rear USB 3.0 ports, support USB 1.0/2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),

  supports USB 1.0/2.0/3.0 up to 5Gb/s

Connector

- 5 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and

  Hot Plug functions

- 3 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x Print port header

- 1 x COM port header

- 1 x Chassis Intrusion header

7

ASRock  B75M R2.0  Motherboard

English

- 1 x CPU Fan connector (4-pin)

- 1 x Chassis Fan connector (4-pin)

- 1 x Power Fan connector (3-pin)

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS Feature

- 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage

  Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

  Multimedia Suite - OEM

 Unique Feature

- ASRock Extreme Tuning Utility (AXTU) (see

CAUTION 9

)

- ASRock Instant Boot

- ASRock Instant Flash (see

CAUTION 10

)

- ASRock APP Charger (see

CAUTION 11

)

- ASRock SmartView (see

CAUTION 12

)

- ASRock XFast USB (see

CAUTION 13

)

- ASRock XFast LAN (see

CAUTION 14

)

- ASRock XFast RAM (see

CAUTION 15

)

- ASRock Crashless BIOS (see

CAUTION 16

)

- ASRock OMG (Online Management Guard)

  (see

CAUTION 17

)

- ASRock Internet Flash (see

CAUTION 18

)

- ASRock UEFI System Browser

 -

ASRock

Dehumidi

fi

 er Function (see

CAUTION 19

)

- Hybrid Booster:

    - ASRock U-COP (see

CAUTION 20

)

    - Boot Failure Guard (B.F.G.)

- Combo Cooler Option (C.C.O.) (see

CAUTION 21

)

- Good Night LED

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allows Chassis Fan Speed Auto-

  Adjust by CPU Temperature)

8

ASRock  B75M R2.0  Motherboard

English

- CPU/Chassis Fan Multi-Speed Control

- CASE OPEN detection

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

 Windows

®

 7 / 7 64-bit / Vista

TM

 / Vista

TM

 64-bit /

  XP / XP 64-bit compliant (see

CAUTION 22

)

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

  (see

CAUTION 23

)

 * For detailed product information, please visit our website: http://www.asrock.com

 WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your system. It should be

done at your own risk and expense. We are not responsible for possible damage

caused by overclocking.

CAUTION!

1.  About the settings of “Hyper Threading Technology”, please check page

50 of the “User Manual” in the support CD.

2. Intel

®

 Small Business Advantage is a customizable platform integrated

with IT tools, which helps maximize employee productivity, PC perfor-

mance, and data security. There are applications including Software

Monitor, PC Health Center, Data Backup & Restore, Energy Saver and

USB Blocker.

3.  This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 16 for proper installation.

4.  Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows

®

 7 /

Vista

TM

 / XP. For Windows

®

 OS with 64-bit CPU, there is no such limita-

tion. You can use ASRock XFast RAM to utilize the memory that Win-

dows

®

 cannot use.

5.  Only PCIE1 slot supports Gen 3 speed. To run the PCI Express in Gen

3 speed, please install an Ivy Bridge CPU. If you install a Sandy Bridge

CPU, the PCI Express will run only at PCI Express Gen 2 speed.

6.  The maximum shared memory size is de

fi

 ned by the chipset vendor and

is subject to change. Please check Intel

®

 website for the latest informa-

tion.

9

ASRock  B75M R2.0  Motherboard

English

7.  You can choose to use two of the three monitors only. D-Sub, DVI-D and

HDMI monitors cannot be enabled at the same time. Besides, with the

DVI-to-HDMI adapter, the DVI-D port can support the same features as

the HDMI port.

8.  xvYCC and Deep Color are only supported under Windows

®

 7 64-bit / 7.

Deep Color mode will be enabled only if the display supports 12bpc in

EDID. HBR audio is supported under Windows

®

 7 64-bit / 7 / Vista

TM

 64-

bit / Vista

TM

.

9.  ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to

fi

 ne-tune

different system functions in a user-friendly interface, which includes

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hard-

ware Monitor, it shows the major readings of your system. In Fan Control,

it shows the fan speed and temperature for you to adjust. In Overclock-

ing, you are allowed to overclock CPU frequency for optimal system per-

formance. In OC DNA, you can save your OC settings as a pro

fi

 le  and

share it with your friends. Your friends then can load the OC pro

fi

 le  to

their own system to get the same OC settings. In IES (Intelligent Energy

Saver), the voltage regulator can reduce the number of output phases to

improve ef

fi

 ciency when the CPU cores are idle without sacri

fi

 cing com-

puting performance. Please visit our website for the operation procedures

of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

10.  ASRock Instant Flash is a BIOS

fl

 ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems

fi

 rst like MS-DOS or Windows

®

. With

this utility, you can press the <F6> key during the POST or the <F2>

key to enter into the BIOS setup menu to access ASRock Instant Flash.

Just launch this tool and save the new BIOS

fi

 le to your USB

fl

 ash drive,

fl

 oppy disk or hard drive, then you can update your BIOS only in a few

clicks without preparing an additional

fl

 oppy diskette or other complicated

fl

 ash utility. Please be noted that the USB

fl

 ash drive or hard drive must

use FAT32/16/12

fi

 le system.

11.  If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPad/iPod Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply install the APP Charger driv-

er, it makes your iPhone charge much quickly from your computer and

up to 40% faster than before. ASRock APP Charger allows you to quickly

charge many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1), Suspend to

RAM (S3), hibernation mode (S4) or power off (S5). With APP Charger

driver installed, you can easily enjoy the marvelous charging experience.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

10

ASRock  B75M R2.0  Motherboard

English

12.  ASRock SmartView, a new function for internet browsers, is the smart

start page for IE that combines your most visited web sites, your history,

your Facebook friends and your real-time newsfeed into an enhanced

view for a more personal Internet experience. ASRock motherboards are

exclusively equipped with the ASRock SmartView utility that helps you

keep in touch with friends on-the-go. To use ASRock SmartView feature,

please make sure your OS version is Windows

®

 7 / 7 64 bit / Vista

TM

 /

Vista

TM

 64 bit, and your browser version is IE8.

ASRock website: http://www.asrock.com/Feature/SmartView/index.asp

13.  ASRock XFast USB can boost USB storage device performance. The

performance may depend on the properties of the device.

14.  ASRock XFast LAN provides a faster internet access, which includes

the bene

fi

 ts listed below. LAN Application Prioritization: You can con

fi

 g-

ure your application’s priority ideally and/or add new programs. Lower

Latency in Game: After setting online game’s priority higher, it can lower

the latency in games. Traf

fi

 c Shaping: You can watch Youtube HD videos

and download simultaneously. Real-Time Analysis of Your Data: With

the status window, you can easily recognize which data streams you are

transferring currently.

15.  ASRock XFast RAM is a new function that is included into ASRock Ex-

treme Tuning Utility (AXTU). It fully utilizes the memory space that cannot

be used under Windows

®

 32-bit OS. ASRock XFast RAM shortens the

loading time of previously visited websites, making web surfing faster

than ever. And it also boosts the speed of Adobe Photoshop 5 times

faster. Another advantage of ASRock XFast RAM is that it reduces the

frequency of accessing your SSDs or HDDs in order to extend their lifes-

pan.

16.  ASRock Crashless BIOS allows users to update their BIOS without fear

of failing. If power loss occurs during the BIOS update process, ASRock

Crashless BIOS will automatically

fi

 nish the BIOS update procedure after

regaining power. Please note that BIOS

fi

 les need to be placed in the

root directory of your USB disk. Only USB2.0 ports support this feature.

17.  Administrators are able to establish an internet curfew or restrict internet

access at speci

fi

 ed times via OMG. You may schedule the starting and

ending hours of internet access granted to other users. In order to pre-

vent users from bypassing OMG, guest accounts without permission to

modify the system time are required.

18.  Internet Flash searches for available UEFI

fi

 rmware updates from our

servers. In other words, the system can auto-detect the latest UEFI from

our servers and

fl

 ash them without entering Windows OS. Please note

that you must be running on a DHCP con

fi

 gured computer in order to en-

able this function.

11

ASRock  B75M R2.0  Motherboard

English

19.  Users may prevent motherboard damages due to dampness by enabling

“Dehumidi

fi

 er Function”. When enabling Dehumidi

fi

 er Function, the com-

puter will power on automatically to dehumidify the system after entering

S4/S5 state.

20.  While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the moth-

erboard functions properly and unplug the power cord, then plug it back

again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

21.  Combo Cooler Option (C.C.O.) provides the

fl

 exible option to adopt three

different CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156.

Please be noticed that not all the 775 and 1156 CPU Fan can be used.

22.  ASRock XFast RAM is not supported by Microsoft

®

Windows

®

 XP / XP

64-bit. Intel

®

 Smart Connect Technology and Intel

®

 USB 3.0 ports are not

supported by Microsoft

®

 Windows

®

 Vista

TM

 / Vista

TM

 64-bit / XP / XP

64-bit.

23.  EuP stands for Energy Using Product, was a provision regulated by the

European Union to define the power consumption for the completed

system. According to EuP, the total AC power of the completed system

should be under 1.00W in off mode condition. To meet EuP standards,

an EuP ready motherboard and an EuP ready power supply are required.

According to Intel’s suggestion, the EuP ready power supply must meet

the standard of 5v, and the standby power ef

fi

 ciency should be higher

than 50% under 100 mA current consumption. For EuP ready power sup-

ply selection, we recommend you to check with the power supply manu-

facturer for more details.
