Maintenance and storage | Technical specifi cations

17

EN

Clean the air filter according to the directions.

When, after many years of service, your machine needs to be replaced or is no longer required, we recom-

mended that the machine is returned to your distributor for recycling.

Genuine spare parts are supplied by service workshops and by many dealers. We recommend that you take the

machine to an authorized service station for annual servicing, maintenance and inspection of safety equipment.

For service and spare parts, please contact the dealer where the machine was purchased.

REGULAR SERVICE PERIOD

Before

First

Every 3

Every 6

Every

Every

Correction

REGULAR SERVICE PERIOD

each

Month

Months

Months

Year

Two

use

or

or

or

or

Years

5 Hrs 25 Hrs 50 Hrs 100 Hrs 250 Hrs

Perform at every indicated month or opera-

ting hour interval, whichever comes first

Check o See manual

Engine oil

Replace oo See manual

Check o See manual

Air cleaner

Replace o See manual

Check, adjust o See manual

Spark plug

Replace o See manual

Flywheel brake pad (A types) Check o Service

Fuel tank and filter Clean o Service

Fuel tube Check Every 2 years (Replace if necessary) Service

Valve clearance Check, adjust Service

Combustion chamber Clean After every 200 hours Service

8. TECHNICAL SPECIFICATIONS

Model No. .............................................................................................................................................FZR3004-B / FZR 3007 BS

Petrol engine: ......................................................................................................................................2.7KW / 2.7KW

Engine speed: .....................................................................................................................................2850/min / 2880/min

Cutting width: ......................................................................................................................................508mm / 456mm

Adjustable cutting height: ..............................................................................................................6 positions / 6 positions

Grass collection capacity: .............................................................................................................65 l / 65l

Gross weight .......................................................................................................................................37kg / 33.6kg

Sound Pressure Level ......................................................................................................................83,5 dB (A)/83,5 dB (A)

Guaranteed Sound Power Level ......................................................................................................98 dB (A)/98 dB (A)

Vibration ............................................................................................................................................. ..6,9 m /s / 6,9 m/s

Maintenance of the battery

Please disconnect the battery from the machine after using

Battery capacity 12V 7AH

SELF-PROPELLED LAWN MOWER USER‘S MANUA
