4. LAWNMOWER ASSEMBLY

The lawnmower is supplied disassembled. The complete adjustable handle and collection box must be assem-

bled before starting work. Proceed step by step according to the user‘s manual and use the pictures as a guide

so that the assembly process is as easy as possible.

ATTENTION: Do not use any additional equipment, which was not recommended by the manufacturer.

SET UP YOUR LAWNMOWER (see pic. 2)

IMPORTANT: Unfold handle carefully so as not to pinch or damage control cables.

1. Raise handles until lower handle section locks into place in mowing position.

2. Remove protective padding, raise upper handle section into place on lower handle and tighten both han-

dle knobs.

3. Remove handle padding holding operator presence control bar to upper handle.

WHEEL ASSEMBLY (see pic. 3)

Assemble the wheels on the mower as in the pictures.

Make sure that the star nut strong enough.

Instruction for plastic catcher assembly (see pic. 4)

1. Take plastic catcher out of the package.

2. Take the small cover part from packing bag.

3. Press the cover part into catcher as picture shown

4. Fix the plastic jacket in the metal bracket.

5. PUTTING INTO OPERATION

Your new lawn mower has been assembled and tested at the factory.

ATTENTION: This lawn mower is shipped WITHOUT OIL OR GASOLINE in the engine.

OPERATION

Brake lever –must be held down to the handle to start the engine. Release to stop the engine.

Starter handle - used for starting engine.

Drive control lever (self-propelled lawnmower)- used to engage power-propelled forward motion of lawn mower.

Range of application

Cutting the grass (see pic. 5)

Cutting up and depositing the grass on the lawn

Cutting up and collected in the grass catcher

Cutting up and ejecting backwards

Cutting up and ejecting sidewards.

SELF-PROPELLED LAWN MOWER USER‘S MANUA

FZR 3003-B navodA5_14.indd 9FZR 3003-B navodA5_14.indd 9 10.1.12 11:3610.1.12 11:36

EN 10

Putting into operation

Mulching

Installation and removal of the accessories must always be take place with switched off engine.

Please make sure the stability of the attached mulching accessories after installing.

For mulching plate, you only allowed use the accessories from original factory

Always avoid to clear away an excessive quantity grass so that the mower mechanism and the engine are

overloaded.

Reducing the speed of self-propelled will help you to pass excessive grass.

Assembly of accessories

Put the baffle plate and raises, aim at the round hole underside, fax up the auto locking hook engage.

Disassembly of accessories

Press the tightly by thumb in the center, then loose and deflect direction take down the mulching plate.

Hang up the grass catcher

Raise the baffle plate and hang up the grass catcher in the illustration shown.

DRIVE CONTROL (see pic. 2)

Self-propelling is controlled by holding the operator presence control bar down to the handle and pushing the

drive control lever forward until it clicks; then releasing the lever.

Forward motion will stop when the operator presence control bar is released. To stop forward motion without

stopping engine, release the operator presence control bar slightly until the drive control disengages. Hold

operator presence control bar down against handle to continue mowing without self-propelling.

ADJUST CUTTING HEIGHT

Raise wheels for low cut and lower wheels for deepcut, adjust cutting height to suit your requirements. Medium

position is best for most lawns.

BEFORE STARTING ENGINE ADD OIL

Your lawnmower is shipped without oil in the engine.

Before each subsequent use the oil level must be check and if necessary topped up with500ml SAE30

(15W-40) engine oil

For type and grade of oil to use, see „ENGINE“ in the Maintenance section of this manual.

ATTENTION: Do not overfill engine with oil, or it will smoke heavily from the muffler on startup.

1. Be sure lawnmower is level.

2. Remove oil dipstick from oil fill spout.

3. Insert and tighten dipstick.

4. Check oil level before each use. Add oil if needed.

5. Fill to full line on dipstick.

6. Change the oil after every 25 hours of operation or each season.

7. You may need to change the oil more often under dusty, dirty conditions. See „TO CHANGE ENGINE OIL“ in the

Maintenance section of this manual.

Note: Check oil level before each use.

FZR 3004-B/FZR 3007 BS

FZR 3003-B navodA5_14.indd 10FZR 3003-B navodA5_14.indd 10 10.1.12 11:3610.1.12 11:36

Putting into operation

11

EN

ADD GASOLINE (see pic. 7)

Fill fuel tank to bottom of tank filler neck.

Do not overfill.

Use fresh, clean, regular unleaded gasoline.

Do not mix oil with gasoline.

Recommendation: Purchase fuel in quantities that can be used within 30 days to assure fuel fresh.

ATTENTION: Wipe off any spilled oil or fuel. Do not store, spill or use gasoline near an open flame.

Note: Alcohol blended fuels (called gasohol or using ethanol or methane can attract moisture which leads

to separation and for motion of acids during storage. Acidic gas can damage the fuel system of an engine

while in storage.

To avoid engine problems, the fuel system should be emptied before storage of 30 days or longer.

Empty the gas tank, start the engine and let it run until the fuel lines and carburetor are empty.

Use fresh fuel next season.

See Storage Instructions for additional information.

Never use engine or carburetor cleaner products in the fuel tank or permanent damage may occur.

START ENGINE

ATTENTION: Press or release the start switch carefully according to the manufacturer‘s instructions. Make

sure that feet are at a sufficient distance from the cutting mechanism.

To start the engine, first make sure that the spark plug and that the machine is filled with sufficient oil and petrol.

Note: Due to protective coatings on the engine, a small amount of smoke may be present during the initial

use of the product and should be considered normal.

Hold operator presence control bar down to the handle and pull starter handle quickly. Do not allow starter rope

to snap back.

Note: In cooler weather it may be necessary to repeat priming steps.

STOP ENGINE

To stop engine, release operator presence control bar.

ATTENTION: The blade will continue to rotate for a few seconds after the engine has stopped. Disconnect

the spark plug cap if the lawnmower is to be left unattended.

Under certain conditions, such as very tall grass, it may be necessary to raise the height of cut to reduce push-

ing effort and to keep from overloading the engine and leaving clumps of grass clippings. It may also be nec-

essary to reduce ground speed and/or run the lawnmower over the area a second time.

For extremely heavy cutting, reduce the width of cut by overlap ping previously cut path and mow slowly.

SELF-PROPELLED LAWN MOWER USER‘S MANUA
