ASRock P67 Extreme4 Gen3: 1. Introduction

5

ASRock  P67 Extreme4 Gen3  Motherboard

1. Introduction

Thank you for purchasing ASRock

P67 Extreme4 Gen3

motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control. It

delivers excellent performance with robust design conforming to ASRock’s commit-

ment to quality and endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found

in the user manual presented in the Support CD.

Because the motherboard speci

fi

 cations and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modi

fi

 cations of this manual occur, the updated version

will be available on ASRock website without further notice. You may

fi

 nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website    http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speci

fi

 c information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock

P67 Extreme4 Gen3

 Motherboard

(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)

ASRock

P67 Extreme4 Gen3

 Quick Installation Guide

ASRock

P67 Extreme4 Gen3

 Support CD

1 x Ribbon Cable for a 3.5-in Floppy Drive

4 x Serial ATA (SATA) Data Cables (Optional)

2 x Serial ATA (SATA) HDD Power Cables (Optional)

1 x I/O Panel Shield

1 x Front USB 3.0 Panel

4 x HDD Screws

6 x Chassis Screws

1 x Rear USB 3.0 Bracket

1 x ASRock SLI_Bridge_2S Card

English

ASRock Reminds You...

To get better performance in Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-

bit, it is recommended to set the BIOS option in Storage Con

fi

 guration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

6

ASRock  P67 Extreme4 Gen3  Motherboard

English

1.2 Specifications

 Platform

- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm

- All Solid Capacitor design (100% Japan-made high-quality

  Conductive Polymer Capacitors)

 CPU

- Supports 2nd Generation Intel

®

 Core

TM

 i7 / i5 / i3 in

  LGA1155 Package

- Advanced V8 + 2 Power Phase Design

- Supports Intel

®

 Turbo Boost 2.0 Technology

- Supports K-Series unlocked CPU

- Supports Hyper-Threading Technology (see

CAUTION 1

)

 Chipset

- Intel

®

 P67

 Memory

- Dual Channel DDR3 Memory Technology (see

CAUTION 2

)

- 4 x DDR3 DIMM slots

- Supports DDR3 2133(OC)/1866(OC)/1600/1333/1066

  non-ECC, un-buffered memory (see

CAUTION 3

)

- Max. capacity of system memory: 32GB (see

CAUTION 4

)

- Supports Intel

®

 Extreme Memory Pro

fi

 le (XMP)

 Expansion Slot

- 2 x PCI Express 3.0 x16 slots (PCIE2/PCIE4: single at x16

  or dual at x8/x8 mode) (PCI Express 3.0 with Intel

®

 Ivy

  Bridge CPU, PCI Express 2.0 with Intel

®

 Sandy Bridge CPU)

- 1 x PCI Express 2.0 x16 slot (PCIE5: x4 mode)

- 2 x PCI Express 2.0 x1 slots

- 2 x PCI slots

- Supports AMD Quad CrossFireX

TM

, 3-Way CrossFireX

TM

  and CrossFireX

TM

- Supports NVIDIA

®

 Quad SLI

TM

 and SLI

TM

 Audio

- 7.1 CH HD Audio with Content Protection

  (Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

- Supports THX TruStudio

TM

 LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Ef

fi

 cient Ethernet 802.3az

- Supports PXE

 Rear Panel I/O

I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Coaxial SPDIF Out Port

7

ASRock  P67 Extreme4 Gen3  Motherboard

English

- 1 x Optical SPDIF Out Port

- 6 x Ready-to-Use USB 2.0 Ports

- 1 x eSATA3 Connector

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

  LED)

- 1 x IEEE 1394 Port

- 1 x Clear CMOS Switch with LED

- HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/

  Line in/Front Speaker/Microphone (see

CAUTION 5

)

 SATA3

- 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

  RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ,

  AHCI and "Hot Plug" functions

- 2 x SATA3 6.0 Gb/s connectors by Marvell SE9120,

  support NCQ, AHCI and "Hot Plug" functions

  (SATA3_M2 connector is shared with eSATA3 port)

 USB3.0

- 2 x Rear USB 3.0 ports by Etron EJ168A, support USB 1.0/

  2.0/3.0 up to 5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports) by

  Etron EJ168A, supports USB 1.0/2.0/3.0 up to 5Gb/s

Connector

- 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

  RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ,

  AHCI and Hot Plug functions

- 4 x SATA3 6.0Gb/s connectors

- 1 x Floppy connector

- 1 x IR header

- 1 x COM port header

- 1 x HDMI_SPDIF header

- 1 x IEEE 1394 header

- 1 x Power LED header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- SLI/XFire power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

- 1 x Dr. Debug (7-Segment Debug LED)

Smart Switch

- 1 x Clear CMOS Switch with LED

- 1 x Power Switch with LED

- 1 x Reset Switch with LED

8

ASRock  P67 Extreme4 Gen3  Motherboard

English

BIOS Feature

- 64Mb AMI BIOS

- AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, PCH, CPU PLL, VTT, VCCSA Voltage

  Multi-adjustment

 Support CD

- Drivers, Utilities, AntiVirus Software (Trial Version),

  CyberLink MediaEspresso 6.5 Trial, ASRock Software Suite

  (CyberLink DVD Suite - OEM and Trial; ASRock MAGIX

  Multimedia Suite - OEM)

 Unique Feature

- ASRock Extreme Tuning Utility (AXTU) (see

CAUTION 6

)

- ASRock Instant Boot

- ASRock Instant Flash (see

CAUTION 7

)

- ASRock APP Charger (see

CAUTION 8

)

- ASRock SmartView (see

CAUTION 9

)

- ASRock XFast USB (see

CAUTION 10

)

- ASRock XFast LAN (see

CAUTION 11

)

- Hybrid Booster:

    - CPU Frequency Stepless Control (see

CAUTION 12

)

    - ASRock U-COP (see

CAUTION 13

)

    - Boot Failure Guard (B.F.G.)

- Combo Cooler Option (C.C.O.) (see

CAUTION 14

)

- Good Night LED

Hardware

- CPU Temperature Sensing

Monitor

- Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed

  Auto-Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

 OS

 -

Microsoft

®

Windows

®

7 / 7 64-bit / Vista

TM

/ Vista

TM

 64-bit

  / XP / XP 64-bit compliant

 Certi

fi

 cations

- FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

  (see

CAUTION 15

)

 * For detailed product information, please visit our website: http://www.asrock.com

9

ASRock  P67 Extreme4 Gen3  Motherboard

English

CAUTION!

1.  About the setting of “Hyper Threading Technology”, please check page

61 of “User Manual” in the support CD.

2.  This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 15 for proper installation.

3.  DDR3 frequency options may depend on the processor. Only K-Series

CPU can support DDR3 overclock to 2133 and 1866.

4.  Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows

®

 7 /

Vista

TM

 / XP. For Windows

®

 OS with 64-bit CPU, there is no such limita-

tion.

5.  For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 3

for proper connection.

6.  ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to

fi

 ne-tune

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In

Hardware Monitor, it shows the major readings of your system. In Fan

Control, it shows the fan speed and temperature for you to adjust. In

Overclocking, you are allowed to overclock CPU frequency for optimal

system performance. In OC DNA, you can save your OC settings as a

pro

fi

 le and share with your friends. Your friends then can load the OC

pro

fi

 le to their own system to get the same OC settings. In IES (Intelligent

Energy Saver), the voltage regulator can reduce the number of output

phases to improve efficiency when the CPU cores are idle without

sacrificing computing performance. Please visit our website for the

operation procedures of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

 WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or

using the third-party overclocking tools. Overclocking may affect your system

stability, or even cause damage to the components and devices of your system.

It should be done at your own risk and expense. We are not responsible for possible

damage caused by overclocking.

10

ASRock  P67 Extreme4 Gen3  Motherboard

English

7.  ASRock Instant Flash is a BIOS

fl

 ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems

fi

 rst like MS-DOS or Windows

®

. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS

fi

 le to your USB

fl

 ash drive,

fl

 oppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional

fl

 oppy diskette or other complicated

fl

 ash utility. Please

be noted that the USB

fl

 ash drive or hard drive must use FAT32/16/12

fi

 le

system.

8.  If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful

solution for you - ASRock APP Charger. Simply installing the APP Char-

ger driver, it makes your iPhone charged much quickly from your com-

puter and up to 40% faster than before. ASRock APP Charger allows you

to quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

9.  SmartView, a new function of internet browser, is the smart start page for

IE that combines your most visited web sites, your history, your Facebook

friends and your real-time newsfeed into an enhanced view for a more

personal Internet experience. ASRock motherboards are exclusively

equipped with the SmartView utility that helps you keep in touch with

friends on-the-go. To use SmartView feature, please make sure your

OS version is Windows

®

 7 / 7 64 bit / Vista

TM

 / Vista

TM

 64 bit, and your

browser version is IE8. ASRock website: http://www.asrock.com/Feature/

SmartView/index.asp

10.  ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

11.  ASRock XFast LAN provides a faster internet access, which includes

below benefits. LAN Application Prioritization: You can configure your

application priority ideally and/or add new programs. Lower Latency in

Game: After setting online game priority higher, it can lower the latency in

game. Traf

fi

 c Shaping: You can watch Youtube HD video and download

fi

 les simultaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are currently

transferring.

12.  Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause the instability of the system or damage the

CPU.

11

ASRock  P67 Extreme4 Gen3  Motherboard

English

13.  While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the

motherboard functions properly and unplug the power cord, then plug it

back again. To improve heat dissipation, remember to spray thermal

grease between the CPU and the heatsink when you install the PC sys-

tem.

14.  Combo Cooler Option (C.C.O.) provides the

fl

 exible option to adopt three

different CPU cooler types, Socket LGA 775, LGA 1155 and LGA 1156.

Please be noticed that not all the 775 and 1156 CPU Fan can be used.

15.  EuP, stands for Energy Using Product, was a provision regulated by Eu-

ropean Union to de

fi

 ne the power consumption for the completed system.

According to EuP, the total AC power of the completed system shall be

under 1.00W in off mode condition. To meet EuP standard, an EuP ready

motherboard and an EuP ready power supply are required. According to

Intel’s suggestion, the EuP ready power supply must meet the standard

of 5v standby power ef

fi

 ciency is higher than 50% under 100 mA current

consumption. For EuP ready power supply selection, we recommend you

checking with the power supply manufacturer for more details.
