JVC KD-G441: More about this unit

18

ENGLISH

Disc operations

Caution for DualDisc playback

•  The Non-DVD side of a “DualDisc” does not comply

with the “Compact Disc Digital Audio” standard.

Therefore, the use of Non-DVD side of a DualDisc on

this product may not be recommended.

General

•  This unit has been designed to reproduce

CDs/CD Texts, and CD-Rs (Recordable)/CD-RWs

(Rewritable) in audio CD (CD-DA), MP3 and WMA

formats.

•  MP3 and WMA “tracks” (words “file” and “track” are

used interchangeably) are recorded in “folders.”

•  When a disc is inserted upside down, “PLEASE” and

“EJECT appear alternately on the display. Press

0

 to

eject the disc.

•  While fast-forwarding or reversing on an MP3 or

WMA disc, you can only hear intermittent sounds.

Playing a CD-R or CD-RW

•  Use only “finalized” CD-Rs or CD-RWs.

•  This unit can only play back files of the same type as

those which are detected first if a disc includes both

audio CD (CD-DA) files and MP3/WMA files.

•  This unit can play back multi-session discs; however,

unclosed sessions will be skipped while playing.

•  Some CD-Rs or CD-RWs may not be played back on

this unit because of their disc characteristics, or for

the following reasons:

  – Discs are dirty or scratched.

  – Moisture condensation has occurred on the lens

inside the unit.

  – The pickup lens inside the unit is dirty.

  – The files on the CD-R/CD-RW are written using the

“Packet Write” method.

  – There are improper recording conditions (missing

data, etc.) or media conditions (stained, scratched,

warped, etc.).

•  CD-RWs may require a longer readout time since the

reflectance of CD-RWs is lower than that of regular

CDs.

More about this unit

Basic operations

Turning on the power

•  By pressing SRC or AUX on the unit, you can also turn

on the power. If the source is ready, playback also

starts.

Turning off the power

•  If you turn off the power while listening to a track,

playback will start from where it had been stopped

previously next time you turn on the power.

Tuner operations

Storing stations in memory

•  During SSM search...

  – All previously stored stations are erased and the

stations are stored anew.

  – Received stations are preset in No. 1 (lowest

frequency) to No. 6 (highest frequency).

  – When SSM is over, the station stored in No. 1 will

be automatically tuned in.

•  When storing a station manually, the previously

preset station is erased when a new station is stored

in the same preset number.

FM RDS operations

•  Network-Tracking Reception requires two types of

RDS signals—PI (Programme Identification) and AF

(Alternative Frequency) to work correctly. Without

receiving these data correctly, Network-Tracking

Reception will not operate correctly.

•  If a Traffic Announcement is received by TA Standby

Reception, the volume level automatically changes to

the preset level (TA VOL) if the current level is lower

than the preset level.

•  When Alternative Frequency Reception is activated

(with AF selected), Network-Tracking Reception is

also activated automatically.

•  If you want to know more about RDS, visit

<http://www.rds.org.uk>.

EN18-25_KD-G441_003A_4.indd   18

EN18-25_KD-G441_003A_4.indd   18

10/26/07   5:51:50 PM

10/26/07   5:51:50 PM

ENGLISH

19

•  This unit can recognize a total of 512 files, 255

folders, and 8 hierarchical levels.

•  This unit can play back files recorded in VBR (variable

bit rate).

  Files recorded in VBR have a discrepancy in the

elapsed time display, and do not show the actual

elapsed time. In particular, this difference becomes

noticeable after performing the search function.

•  This unit cannot play back the following files:

  – MP3 files encoded in MP3i and MP3 PRO format.

  – MP3 files encoded in an inappropriate format.

  – MP3 files encoded with Layer 1/2.

  – WMA files encoded in lossless, professional, and

voice format.

  – WMA files not based on Windows Media® Audio.

  – WMA files copy-protected with DRM.

  – Files which have data such as WAVE, ATRAC3, etc.

•  The search function works but search speed is not

constant.

Playing MP3/WMA tracks from a USB device

•  While playing from a USB device, the playback order

may differ from other players.

•  This unit may be unable to play back some USB

devices or some files due to their characteristics or

recording conditions.

•  Depending on the shape of the USB devices and

connection ports, some USB devices may not be

attached properly or the connection might be loose.

•  Connect one USB mass storage class device to the unit

at a time. Do not use a USB hub.

•  If the connected USB device does not have the correct

files, “NO FILE” appears.

•  This unit can show Tag (Version 1.0, 1.1, 2.2, 2.3, or

2.4) for MP3 files and for WMA files.

•  Do not use the following CD-Rs or CD-RWs:

  – Discs with stickers, labels, or protective seal stuck

to the surface.

  – Discs on which labels can be directly printed by an

ink jet printer.

  Using these discs under high temperature or high

humidity may cause malfunctions or damage to the

unit.

Playing an MP3/WMA disc

•  This unit can play back MP3/WMA files with the

extension code <.mp3> or <.wma> (regardless of

the letter case—upper/lower).

•  This unit can show the names of albums, artists

(performer), and Tag (Version 1.0, 1.1, 2.2, 2.3, or

2.4) for MP3 files and for WMA files.

•  This unit can display only one-byte characters. No

other characters can be correctly displayed.

•  This unit can play back MP3/WMA files meeting the

conditions below:

  – Bit rate: 8 kbps — 320 kbps

  – Sampling frequency:

    48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)

    24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)

    12 kHz, 11.025 kHz, 8 kHz (for MPEG-2.5)

  – Disc format: ISO 9660 Level 1/ Level 2, Romeo,

Joliet, Windows long file name

  – Bit rate of WMA: 16 kbps — 32 kbps

(Sampling frequency: 22.05 kHz)

32 kbps — 320 kbps

(Sampling frequency: 48 kHz,

44.1 kHz, 32 kHz)

•  The maximum number of characters for file/folder

names vary depending on the disc format used

(includes 4 extension characters—<.mp3> or

<.wma>).

  – ISO 9660 Level 1: up to 12 characters

  – ISO 9660 Level 2: up to 31 characters

  – Romeo: up to 128 characters

  – Joliet: up to 64 characters

  – Windows long file name: up to 128 characters

Continued on the next page

EN18-25_KD-G441_003A_4.indd   19

EN18-25_KD-G441_003A_4.indd   19

10/26/07   5:51:51 PM

10/26/07   5:51:51 PM

20

ENGLISH

•  This unit can play back MP3/WMA files meeting the

conditions below:

  – Bit rate of MP3: 16 kbps — 320 kbps

  – Sampling frequency of MP3:

    48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)

    24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)

    12 kHz, 11.025 kHz, 8 kHz (for MPEG-2.5)

  – Bit rate of WMA:

    16 kbps — 32 kbps

(Sampling frequency: 22.05 kHz)

    32 kbps — 320 kbps

(Sampling frequency: 48 kHz, 44.1 kHz, 32 kHz)

•  This unit can play back MP3 files recorded in VBR

(variable bit rate).

•  The maximum number of characters for:

  – Folder names : 25 characters

  – File names : 25 characters

  – MP3 Tag : 128 characters

  – WMA Tag : 64 characters

•  This unit can recognize a total of 2 500 files, 255

folders (999 files per folder), and of 8 hierarchies.

•  This unit does not support SD card reader.

•  This unit cannot recognize a USB device whose rating

is other than 5 V and exceeds 500 mA.

•  USB devices equipped with special functions such as

data security functions cannot be used with the unit.

•  Do not use a USB device with 2 or more partitions.

•  This unit may not recognize a USB device connected

through a USB card reader.

•  This unit may not play back files in a USB device

properly when using a USB extension cord.

•  This unit cannot play back the following files:

  – MP3 files encoded with MP3i and MP3 PRO format.

  – MP3 files encoded in an inappropriate format.

  – MP3 files encoded with Layer 1/2.

  – WMA files encoded in lossless, professional, and

voice format.

  – WMA files not based on Windows Media® Audio.

•  Use a shielded USB cable of less than 1 m in length.

Changing the source

•  If you change the source, playback also stops.

  Next time you select the same source again, playback

starts from where it has been stopped previously.

Ejecting a disc or removing a USB device

•  If the ejected disc is not removed within 15 seconds,

it is automatically inserted into the loading slot again

to protect it from dust.

•  After ejecting a disc or removing a USB device,

“NO DISC” or “NO USB“ appears and you cannot

operate some of the buttons. Insert another disc,

reattach a USB device, or press SRC to select another

playback source.

General settings—PSM

•  If you change the “AMP GAIN” setting from

“HIGH POWER” to “LOW POWER” while the

volume level is set higher than “VOLUME 30,” the

unit automatically changes the volume level to

“VOLUME 30.”
