Mr Handsfree Blue Butterfly II: инструкция

II

m_blue_cover.pmd 08.09.2005, 16:313

Microphone

V

Travel charger

Volume button

Blue LED

MF-button

Headset

DC input

Adapter

DC output

m_blue_ill.pmd 08.09.2005, 16:421

TABLE OF CONTENTS

GETTING STARTED .................................................................. 2

PAIRING THE HEADSET........................................................... 3

MAKING AND ANSWERING / ENDING CALLS........................ 3

TRANSFERRING / SWITCHING CALLS / PUTTING CALLS

ON HOLD.................................................................................... 4

CONNECTING WITH A PC OR PDA.......................................... 4

TROUBLE SHOOTING............................................................... 5

m_blue_gb.pmd 08.09.2005, 16:361

2

GETTING STARTED

CHARGING BATTERY

The mr Handsfree Blue Butterfly headset comes with a rechargeable battery included. For first time use, it

takes about 24 hours to fully charge the battery. Afterwards, it takes about 2 hours to fully charge the battery.

When the battery is fully charged, the talk time is 8 hours, and the stand-by time will be about 200 hours.

Plug the Travel Charger (7) into an AC outlet.  Connect the adapter (6) into the headset (5) as shown in the

picture. Gently press the adapter until it clicks into place.  The blue indicator (4) on the headset will light up.

 When the battery is fully charged, the blue indicator (4) on the headset will turn off.

Note:

1. When you hear 5 short beeps through the speaker of the headset, repeated every 20 seconds, the

headset is running on low battery. Charge the headset for 2 hours until the blue indicator (4) will turn off.

2. The headset has to be recharged every two months, when it is not in use during a long time.

MAIN FUNCTIONS MULTIFUNCTIONAL AND VOLUME BUTTONS & BLUE INDICATOR

MF-Button (3):

 Power on/off

 Answer / end / transfer calls / put calls on hold

 Pairing

Volume Button (2):

 Adjust volume

 Mute-function

Bleu LED indicator (4):

noitcatesdaeH rotacidnieulB

fforewoPffO

edom-gniriaP yltnatsnocpusthgiL

lufseccusgniriaP ylkciuqx01sehsalF

edom-ybdnatS sdnoces5yrevesehsalF

yrettabgnigrahC yltnatsnocpusthgiL

degrahcyrettaBffO

TURNING HEADSET ON/OFF

To turn the headset on:

Press and hold the MF- button (3) for 3 seconds.  You will hear a series of 4 tones (from low to high) and the

blue indicator (4) of the headset flashes 2 times.  The headset is now turned on.

To turn the headset off:

Press and hold the MF-button (3) for 5 seconds.  You will hear a series of 4 tones (from high to low) and the

blue indicator (4) of the headset turns off.  The headset is now turned off.

English
